5920-00-057-3152
Cartridge Fuse
5920000573152 000573152 MIL-PRF-15160/15 F15G1R00B F15BR250V1A MIL-F-15160/15 F15B250V1A
A fuse in which the element is inclosed in a cylindrical body. The element may be renewable. The terminals may be of varying types. It may contain a visual indication that the fusible element is severed, and may also provide an audible alarm through auxiliary circuitry. For noncylindrical items, see FUSE, INCLOSED LINK. View more Cartridge Fuse
Managed by United States
NSN Created on 1 Jan 1963
Data Last Changed
November 2023
November 2023
NATO Update Count
32
32
NATO Data Quality
Marketplace 5920-00-057-3152
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
MIL-F-1516015 FUSE,CARTRIDGE 26 EA NS
MIL-PRF-1516015 FUSE,CARTRIDGE 6 EA NS
MILF15160-15 FUSE,CARTRIDGE 134 EA NS
Updated Every Day 5920-00-057-3152 RQST NE
Updated Every Day 5920-00-057-3152 RQST
Updated Every Day 5920-00-057-3152 RQST NE
Related Documents 5920-00-057-3152 5+ Documents (More...)
https//www.nsnlookup.com
/fsg-59/fsc-5920/us
/fsg-59/fsc-5920/us
5920-00-057-3152 Cartridge Fuse 5920000573152 000573152
MIL-PRF-15160/15 F15G1R00B F15BR250V1A MIL-F-15160/15 F15B250V1A A fuse in which the element is inclosed
Photo 1/4 5920-00-057-3152 Photo 2/4 5920-00-057-3152 Photo 3/4 NSN 5920-00-057-3152 (Identification
F15B250V1A FUSE,CARTRIDGE 89 EA NS Request Quotation Updated Every Day 5920-00-057-3152 RQST NE Updated
Photo 1/4 5920-00-057-3152 Photo 2/4 5920-00-057-3152 Photo 3/4 NSN 5920-00-057-3152 (Identification
F15B250V1A FUSE,CARTRIDGE 89 EA NS Request Quotation Updated Every Day 5920-00-057-3152 RQST NE Updated
https//www.nsnlookup.com
/fsg-59/fsc-5920/us
/fsg-59/fsc-5920/us
5920-00-981-5787 Cartridge Fuse 5920009815787 009815787
A-13931 F15A250V3A3 F15A250V3AS MIL-F-15160/15 A fuse in which the element is inclosed in a cylindrical
MIL-PRF-15160/15 FUSE,CARTRIDGE 138 EA NS Request Quotation Subscribe to View Vendor Details...
A fuse in which the element is inclosed in a cylindrical MIL-PRF-15160/15 FUSE,CARTRIDGE 138 EA NS
MIL-PRF-15160/15 FUSE,CARTRIDGE 138 EA NS Request Quotation Subscribe to View Vendor Details...
A fuse in which the element is inclosed in a cylindrical MIL-PRF-15160/15 FUSE,CARTRIDGE 138 EA NS
https//www.nsnlookup.com
/fsg-59/fsc-5920/us
/fsg-59/fsc-5920/us
5920-00-281-0221 Cartridge Fuse 5920002810221 002810221
FRN-32/10 F15B250V3-2/10A MIL-F-15160/15 A fuse in which the element is inclosed in a cylindrical
MIL-PRF-15160/15 FUSE,CARTRIDGE 138 EA NS Request Quotation Subscribe to View Vendor Details...
F15B250V4AS F15BR250V4AS MIL-F-15160/15 A fuse in which the element is inclosed in a cylindrical
MIL-PRF-15160/15 FUSE,CARTRIDGE 138 EA NS Request Quotation Subscribe to View Vendor Details...
F15B250V4AS F15BR250V4AS MIL-F-15160/15 A fuse in which the element is inclosed in a cylindrical
https//www.nsnlookup.com
/fsg-59/fsc-5920/us
/fsg-59/fsc-5920/us
5920-00-240-3874 Cartridge Fuse 5920002403874 002403874
$1 a day Upgrade your Account Upgrade 5920-00-240-3874Cartridge Fuse5920002403874 002403874 MIL-PRF-15160/15
F15B250V2 1/2A MIL-F-15160/15 A fuse in which the element is inclosed in a cylindrical body.
MIL-PRF-15160/15 FUSE,CARTRIDGE 138 EA NS Request Quotation Subscribe to View Vendor Details...
F15B250V2 1/2A MIL-F-15160/15 A fuse in which the element is inclosed in a cylindrical body.
MIL-PRF-15160/15 FUSE,CARTRIDGE 138 EA NS Request Quotation Subscribe to View Vendor Details...
https//www.nsnlookup.com
/fsg-59/fsc-5920/us
/fsg-59/fsc-5920/us
5920-00-033-8023 Cartridge Fuse 5920000338023 000338023
F15B240V1AS F15BR250V1AS F15B250V1AS MIL-F-15160/15 A fuse in which the element is inclosed in a
MIL-PRF-15160/15 FUSE,CARTRIDGE 138 EA NS Request Quotation Subscribe to View Vendor Details... https
F15B250V4AS F15BR250V4AS MIL-F-15160/15 A fuse in which the element is inclosed in a cylindrical
MIL-PRF-15160/15 FUSE,CARTRIDGE 138 EA NS Request Quotation Subscribe to View Vendor Details... https
F15B250V4AS F15BR250V4AS MIL-F-15160/15 A fuse in which the element is inclosed in a cylindrical
Restrictions 5920-00-057-3152
5920-00-057-3152 is a Cartridge Fuse that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5920-00-057-3152
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5920-00-057-3152
- US Army (A918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A196
- Supplementary Receivers:
- CL
- US Coast Guard (C911)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- C007
- US Air Force (FXGX)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXTX
- NASA (G26X)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- G26E
- NASA (G860)
- Effective Date:
- 1 Apr 1991
- NASA (G900)
- Effective Date:
- 1 Apr 1991
- US Marine Corps (MC49)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- MC13
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- NIND
- Supplementary Collaborators:
- GTHD
- Brazil (YA01)
- Effective Date:
- 1 Dec 1999
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Jun 1996
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Dec 1995
Approved Sources 5920-00-057-3152
- Part Number
- Manufacturer
- Status
- F15BR250V1A
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-15160/15
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-F-15160/15
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- F15B250V1A
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- F15G1R00B
- 71400 - Cooper Bussmann, Llc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5920-00-057-3152
- Characteristic
- Specifications
- FIIG
- Specifications
- A01700
- Body Style [AAQL]
- Tube Type
- Case Material [ADTV]
- Fiber
- Circuit Over-Current Interruption Delay Time In Seconds [CQPB]
- 12.0 200 Pct Of Current Rating
- Circuit Over-Current Interruption Type [AFXF]
- Time Delay
- Continuous Current Rating In Amps [AEBJ]
- 1.000
- Features Provided [CBBL]
- Nonrenewable Fusible Element
- Maximum Voltage Rating In Volts [AFXE]
- 250.0 Ac And 250.0 Dc
- Interruption Indicator Method [AFXH]
- Opaque Body
- Short-Circuit/Interrupt Current Rating In Amps [CSQN]
- 10000.0
- Overall Diameter [ADAV]
- 0.556 Inches Minimum And 0.568 Inches Maximum
- Overall Length [ABHP]
- 1.969 Inches Minimum And 2.031 Inches Maximum
- Specification/Standard Data [ZZZK]
- 81349-Mil-Prf-15160/15 Government Specification
- Terminal Material [ABDM]
- Brass
- Terminal Surface Treatment [ABDN]
- Nickel
- Test Data Document [TEST]
- 81349-Mil-Prf-15160 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
DLA Procurement Analysis 5920-00-057-3152
- Last Stock Position:
- 2 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5920-00-057-3152
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- EH
- ELECTRONIC COMPONENTS
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
NATO Stock Numbers Related to 5920-00-057-3152
5920-37-523-3757 5920-99-955-7400 5920-66-069-3822 5920-12-137-2389 5920-99-444-4985 5920-99-870-1472 5920-12-330-1412 5920-12-389-9153 5920-12-322-2308 5920-99-667-9477 5920-12-360-5826 5920-99-471-2163 5920-98-105-0952 5920-66-143-1797 5920-99-541-3500 5920-99-856-4177 5920-12-324-0258 5920-99-222-7353
Freight Information 5920-00-057-3152
5920-00-057-3152 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062060. A Sub NMFC of Z. It has a NMFC Description of FUSES NOI IN BOXES. 5920-00-057-3152 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34740 which rates the freight between FCL and LCL. 5920-00-057-3152 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5920-00-057-3152 is not classified as a special type of cargo when transported by water. 5920-00-057-3152 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5920-00-057-3152
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- --
- --
- --
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Vendor's Setup or Folding Box
Contracting Technical Data File (CTDF) 5920-00-057-3152 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
