5915-01-064-0514
Radio Frequency Interference Filter
5915010640514 010640514 906920 RF08415 A-2494B 906920-1 RF8415 A-2494
An item designed to suppress undesired (interfering) frequencies and have a minimal effect on the desired frequencies when inserted in an electrical power circuit. Excludes items which consist of a single capacitor, inductor, resistor, or devices consisting of only two or more circuit elements of the same basic name. Excludes FILTER, LOW PASS and SUPPRESSOR, IGNITION INTERFERENCE. For items designed to be inserted in a line which is primarily intended to carry high frequency waves modulated with signals, such as antenna lead-in, see FILTER, BAND SUPPRESSION and FILTER, BAND PASS. See also LIMITER, ELECTRICAL NOISE. View more Radio Frequency Interference Filter
May 2023
19
Marketplace 5915-01-064-0514
Request a Quotation from participating marketplace vendors
Related Documents 5915-01-064-0514 5+ Documents (More...)
FILTER,RADIO FREQUENCY INTERFERENCE 1 EA NS Request Quotation Subscribe to View Vendor Details... 906920
RF8415 FILTER,RADIO FREQUENCY INTERFERENCE 3 EA NS Request Quotation Updated Every Day 5915-01-064-0514
RF08415 A-2494B 906920 https//www.nsnlookup.com /fsg-59/fsc-5915/us 5915-01-064-0514 Radio Frequency
010640514 RF08415 A-2494B 906920 -1 RF8415 906920 A-2494 An item designed to suppress undesired (interfering
your web browser . 6150-99-811-3704Electrical Special Purpose Cable Assembly6150998113704 998113704 906920
Radio Frequency Interference Filter,RF08415 Upgrade 5915-01-064-0514Radio Frequency Interference
RF08415 A-2494B 906920 https//www.nsnlookup.com /fsg-66/fsc-6645/fr 6645-14-362-7181 Sequential Timer
14 https//www.nsnlookup.com /fsg-61/fsc-6150/uk https//www.nsnlookup.com /fsg-59/fsc-5915/us 5915-01-064-0514
-1 DUCT,WING CENTER 2 EA NS Request Quotation Subscribe to View Vendor Details... 906920-1 DUCT,WING
Filter5915010640514 010640514 RF08415 A-2494B 906920-1 FILTER,RADIO FREQUENCY INTERFERENCE 1 EA NS Request
Restrictions 5915-01-064-0514
5915-01-064-0514 is a Radio Frequency Interference Filter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5915-01-064-0514
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5915-01-064-0514
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- GTHD
- Poland (WP01)
- Effective Date:
- 1 Nov 2003
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Jul 2005
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5915-01-064-0514
- Part Number
- Manufacturer
- Status
- 906920
- Manufacturer
- 3B150 - Raytheon Company (Active)
- Primary Buy
- Primary Buy
- 906920-1
- 3B150 - Raytheon Company (Active)
- Secondary Buy
- Secondary Buy
- RF08415
- 13619 - Ems Development Corporation (Active)
- Secondary Buy
- Secondary Buy
- 906920-1
- 54X10 - Raytheon Company (Active)
- Secondary Buy
- Secondary Buy
- A-2494B
- 23939 - The Captor Corporation (Active)
- Secondary Buy
- Secondary Buy
- 906920
- 54X10 - Raytheon Company (Active)
- Secondary Buy
- Secondary Buy
- 906920-1
- 49956 - Raytheon Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- RF8415
- 13619 - Ems Development Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- A-2494
- 23939 - The Captor Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 906920
- 49956 - Raytheon Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5915-01-064-0514
- Characteristic
- Specifications
- FIIG
- Specifications
- A047B0
- Body Height [ADAU]
- 3.000 Inches Nominal
- Body Length [ADAQ]
- 6.000 Inches Nominal
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Length [AEBY]
- 6.995 Inches Minimum And 7.005 Inches Maximum
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Width [AEHA]
- 6.870 Inches Minimum And 6.880 Inches Maximum
- Functional Terminal Type And Quantity [CQDW]
- 4 Threaded Stud Output 2Nd Function
- Functional Terminal Type And Quantity [CQDW]
- 1 Connector, Receptacle Input 1St Function
- Maximum Voltage Drop Per Function [AHBE]
- 484.0 Millivolts Ac 1St Radio Interference
- Maximum Voltage Drop Per Function [AHBE]
- 484.0 Millivolts Ac 2Nd Radio Interference
- Maximum Voltage Drop Per Function [AHBE]
- 484.0 Millivolts Ac 3Rd Radio Interference
- Mounting Facility Type And Quantity [AXHR]
- 6 Unthreaded Hole
- Operating Current Rating Per Function In Amps [AHBC]
- 10.5 1St Radio Interference
- Operating Current Rating Per Function In Amps [AHBC]
- 10.5 2Nd Radio Interference
- Operating Current Rating Per Function In Amps [AHBC]
- 10.5 3Rd Radio Interference
- Operating Voltage Rating And Type Per Function [CQGC]
- 484.0 Volts Ac 3Rd Radio Interference 3Rd Function
- Operating Voltage Rating And Type Per Function [CQGC]
- 484.0 Volts Ac 1St Radio Interference 1St Function
- Operating Voltage Rating And Type Per Function [CQGC]
- 484.0 Volts Ac 2Nd Radio Interference 2Nd Function
- Inclosure Type [AKNA]
- Encased
- Load Impedance Per Function [AHAS]
- 50.0 Ohms 1St Radio Interference
- Load Impedance Per Function [AHAS]
- 50.0 Ohms 2Nd Radio Interference
- Load Impedance Per Function [AHAS]
- 50.0 Ohms 3Rd Radio Interference
- Power Line Frequency Rating Per Function In Hertz [AHBB]
- 60.0 1St Radio Interference
- Power Line Frequency Rating Per Function In Hertz [AHBB]
- 60.0 2Nd Radio Interference
- Power Line Frequency Rating Per Function In Hertz [AHBB]
- 60.0 3Rd Radio Interference
- Source Impedance Rating Per Function [AHAQ]
- 50.0 Ohms 1St Radio Interference
- Source Impedance Rating Per Function [AHAQ]
- 50.0 Ohms 2Nd Radio Interference
- Source Impedance Rating Per Function [AHAQ]
- 50.0 Ohms 3Rd Radio Interference
- Overall Height [ABKW]
- 4.840 Inches Nominal
- Overall Length [ABHP]
- 8.000 Inches Nominal
- Unthreaded Mounting Hole Diameter [AEBV]
- 0.224 Inches Minimum And 0.228 Inches Maximum
- Style Designator [STYL]
- Rectangular Terminal/Terminals On Opposite Surfaces
Weapon Systems (WSDC) 5915-01-064-0514
DLA Procurement Analysis 5915-01-064-0514
Management Data 5915-01-064-0514
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5915-01-064-0514
Freight Information 5915-01-064-0514
5915-01-064-0514 has freight characteristics managed by the Food and Drug Administration (FDA).It has a National Motor Freight Classification (NMFC) of 061990. A Sub NMFC of X. It has a NMFC Description of ELECTRICAL EQUIP:FILTERS. 5915-01-064-0514 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58500 which rates the freight between FCL and LCL. 5915-01-064-0514 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5915-01-064-0514 is not classified as a special type of cargo when transported by water. 5915-01-064-0514 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5915-01-064-0514
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- PPP-C-795, Cellular Plastic Film Cushioning; or A-A-3129, Open Cell Plastic Cushioning; or PPP-C-1797, Polypropylene Foam Cushioning; or A-A-59136, Polyethylene Foam Cushioning
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- No special marking
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 5915-01-064-0514 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Z
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
