5915-01-062-2000
Band Pass Filter
5915010622000 010622000 243B990A01
An item designed to pass frequencies within a specified range (band) and to suppress frequencies outside the range (band). Excludes a single inductance, or a single capacitance, or a single resistance. See COIL (as modified); REACTOR; CAPACITOR (as modified); and RESISTOR (as modified). View more Band Pass Filter
May 2023
4
Marketplace 5915-01-062-2000
Request a Quotation from participating marketplace vendors
Related Documents 5915-01-062-2000 2+ Documents (More...)
Day 5915-01-062-2000 RQST NE Related Documents 5915-01-062-2000 1+ Documents ( More... ) https//www.nsnlookup.com
/fsg-59/fsc-5915/us 5915-01-062-2000 Band Pass Filter 5915010622000010622000 Photo 1/2 NSN 5915-01-062
Restrictions 5915-01-062-2000
5915-01-062-2000 is a Band Pass Filter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item has been confirmed as a Critical Munitions List Item or a Sensitive Commerce Control List Item and cannot be in the possession of any party anywhere in the World who is not an authorized NATO Government. Any other possessor of this item should mutilate it now as possession violates international and local laws. This item is a confirmed Commerce Control List Item (CCLI). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5915-01-062-2000
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5915-01-062-2000
- US Air Force (FXGX)
- Effective Date:
- 1 Jul 2005
- United States of America (ZZ)
Approved Sources 5915-01-062-2000
- Part Number
- Manufacturer
- Status
- 243B990A01
- Manufacturer
- 97942 - Northrop Grumman Systems Corporation (Active)
- Primary Buy
- Primary Buy
Datasheet 5915-01-062-2000
- Characteristic
- Specifications
- FIIG
- Specifications
- A047B0
- Body Height [ADAU]
- 3.630 Inches Nominal
- Body Length [ADAQ]
- 3.813 Inches Nominal
- Body Material [CQRG]
- Metal
- Body Width [ADAT]
- 0.880 Inches Nominal
- Discrimination At Specified Frequencies Per Function In Decibels [CRBC]
- 23.0 Minimum Blank And 1.0 Maximum Blank And 1.0 Maximum Blank And 23.0 Minimum Blank
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Length [AEBY]
- 2.980 Inches Nominal
- Frequency Band Width Per Function [CRBB]
- 9.20 Kilohertz Blank And 10.80 Kilohertz Blank
- Functional Terminal Type And Quantity [CQDW]
- 1 Tab, Solder Lug Input 1St Function
- Functional Terminal Type And Quantity [CQDW]
- 1 Tab, Solder Lug Ground 3Rd Function
- Functional Terminal Type And Quantity [CQDW]
- 1 Tab, Solder Lug Output 2Nd Function
- Mounting Facility Screw Thread Series Designator [AKEJ]
- Unc
- Mounting Facility Type And Quantity [AXHR]
- 4 Threaded Hole
- Nominal Thread Size [CQJX]
- 0.112 Inches
- Operating Temp Range [AFGA]
- -40.0/+85.0 Deg Celsius
- Output Impedance Per Function W/Source Across Input [AHAV]
- 1.0 Kilohms Blank
- Inclosure Type [AKNA]
- Encased
- Input Impedance Per Function W/Load [AHAU]
- 1.0 Kilohms Blank
- Insertion Loss At Reference Frequency Per Function In Decibels [CQDR]
- 3.0 Blank
- Reference Frequency Per Function [AHAJ]
- 10.0 Kilohertz Blank
- Overall Height [ABKW]
- 4.010 Inches Nominal
- Specified Frequencies Of Discrimination Per Function [CQFC]
- 5.00 Kilohertz Blank And 9.20 Kilohertz Blank And 10.80 Kilohertz Blank And 15.00 Kilohertz Blank
- Style Designator [STYL]
- Rectangular Terminal/Terminals On One Surface
Weapon Systems (WSDC) 5915-01-062-2000
DLA Procurement Analysis 5915-01-062-2000
Management Data 5915-01-062-2000
Similar Supply Items to 5915-01-062-2000
Freight Information 5915-01-062-2000
5915-01-062-2000 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061990. A Sub NMFC of X. It has a NMFC Description of ELECTRICAL EQUIP:FILTERS. 5915-01-062-2000 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58500 which rates the freight between FCL and LCL. 5915-01-062-2000 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 593 for ocean manifesting and military sealift. 5915-01-062-2000 is not classified as a special type of cargo when transported by water. 5915-01-062-2000 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5915-01-062-2000 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- K
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
