5915-00-789-7937
Radio Frequency Interference Filter
5915007897937 007897937 9100-2818 9110-0082 9110-0081 JN10-1912A1 JN10-1991A1 F-10073 9100-2482 2337-0319
An item designed to suppress undesired (interfering) frequencies and have a minimal effect on the desired frequencies when inserted in an electrical power circuit. Excludes items which consist of a single capacitor, inductor, resistor, or devices consisting of only two or more circuit elements of the same basic name. Excludes FILTER, LOW PASS and SUPPRESSOR, IGNITION INTERFERENCE. For items designed to be inserted in a line which is primarily intended to carry high frequency waves modulated with signals, such as antenna lead-in, see FILTER, BAND SUPPRESSION and FILTER, BAND PASS. See also LIMITER, ELECTRICAL NOISE. View more Radio Frequency Interference Filter
November 2023
23
Marketplace 5915-00-789-7937
Request a Quotation from participating marketplace vendors
Related Documents 5915-00-789-7937 5+ Documents (More...)
RQST NE Updated Every Day 5915-00-789-7937 RQST Updated Every Day 5915-00-789-7937 RQST NE Related Documents
5915-00-789-7937 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5915/us 5915-00-789-7937
Restrictions 5915-00-789-7937
5915-00-789-7937 is a Radio Frequency Interference Filter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5915-00-789-7937
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5915-00-789-7937
- US Army (A918)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- A196
- US Air Force (FXGX)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- FXTX
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- GTHD
- Brazil (YA01)
- Effective Date:
- 1 Jan 2002
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Malaysia (YW01)
- Effective Date:
- 1 Mar 2011
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 May 1998
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5915-00-789-7937
- Part Number
- Manufacturer
- Status
- 9100-2482
- Manufacturer
- 7ZXR5 - Keysight Technologies Inc (Active)
- Primary Buy
- Primary Buy
- 9100-2482
- 1LQK8 - Keysight Technologies, Inc. (Replaced)
- Original Design
- Original Design
- JN10-1912A1
- 56289 - Sprague Electric Co World Hqs (Active)
- Secondary Buy
- Secondary Buy
- JN10-1991A1
- 56289 - Sprague Electric Co World Hqs (Active)
- Secondary Buy
- Secondary Buy
- F-10073
- 0AM43 - Lcr Electronics, Inc (Active)
- Secondary Buy
- Secondary Buy
- 2337-0319
- K0216 - Thales Uk Limited Dba Thales Uk Ltd (Active)
- Secondary Buy
- Secondary Buy
- 9100-2482
- 28480 - Hewlett-Packard Company (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 2337-0319
- U1746 - Thales Optronics (Taunton) Ltd (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
- 9100-2818
- 28480 - Hewlett-Packard Company (Active)
- Advisory Reference
- Advisory Reference
- 9110-0082
- 28480 - Hewlett-Packard Company (Active)
- Advisory Reference
- Advisory Reference
- 9110-0081
- 81755 - Lockheed Martin Corporation (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5915-00-789-7937
- Characteristic
- Specifications
- FIIG
- Specifications
- A047B0
- Body Height [ADAU]
- 1.375 Inches Nominal
- Body Length [ADAQ]
- 1.375 Inches Nominal
- Body Material [CQRG]
- Metal
- Body Width [ADAT]
- 1.156 Inches Nominal
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Width [AEHA]
- 1.500 Inches Nominal
- Functional Terminal Type And Quantity [CQDW]
- 2 Pin Input 1St Function2 Tab, Solder Lug Output 2Nd Function1 Pin Ground 3Rd Function And 1 Tab, Solder Lug Ground 3Rd Function
- Maximum Voltage Drop Per Function [AHBE]
- 2.3 Volts Ac 1St Radio Interference2.3 Volts Ac 2Nd Radio Interference
- Mounting Facility Type And Quantity [AXHR]
- 2 Unthreaded Hole
- Operating Current Rating Per Function In Amps [AHBC]
- 4.0 1St Radio Interference4.0 2Nd Radio Interference
- Operating Temp Range [AFGA]
- -55.0/+85.0 Deg Celsius
- Operating Voltage Rating And Type Per Function [CQGC]
- 230.0 Volts Ac 1St Radio Interference 1St Function230.0 Volts Ac 2Nd Radio Interference 2Nd Function
- Inclosure Type [AKNA]
- Hermetically Sealed
- Load Impedance Per Function [AHAS]
- 50.0 Ohms 1St Radio Interference50.0 Ohms 2Nd Radio Interference
- Power Line Frequency Rating Per Function In Hertz [AHBB]
- 400.0 1St Radio Interference400.0 2Nd Radio Interference
- Principal Circuitry Type Per Function [AHBL]
- Inductance-Capacitance 1St Radio Interference Inductance-Capacitance 2Nd Radio Interference
- Source Impedance Rating Per Function [AHAQ]
- 50.0 Ohms 1St Radio Interference50.0 Ohms 2Nd Radio Interference
- Overall Length [ABHP]
- 2.125 Inches Nominal
- Special Features [FEAT]
- Two Filtered Functions
- Unthreaded Mounting Hole Diameter [AEBV]
- 0.156 Inches Nominal
- Style Designator [STYL]
- Rectangular Terminal/Terminals On Opposite Surfaces
Weapon Systems (WSDC) 5915-00-789-7937
DLA Procurement Analysis 5915-00-789-7937
- Last Stock Position:
- 2 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5915-00-789-7937
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5915-00-789-7937
Freight Information 5915-00-789-7937
5915-00-789-7937 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061990. A Sub NMFC of X. It has a NMFC Description of ELECTRICAL EQUIP:FILTERS. 5915-00-789-7937 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58500 which rates the freight between FCL and LCL. 5915-00-789-7937 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5915-00-789-7937 is not classified as a special type of cargo when transported by water. 5915-00-789-7937 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5915-00-789-7937
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- --
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
