5915-00-504-7440
Radio Frequency Interference Filter
5915005047440 005047440 EA162
An item designed to suppress undesired (interfering) frequencies and have a minimal effect on the desired frequencies when inserted in an electrical power circuit. Excludes items which consist of a single capacitor, inductor, resistor, or devices consisting of only two or more circuit elements of the same basic name. Excludes FILTER, LOW PASS and SUPPRESSOR, IGNITION INTERFERENCE. For items designed to be inserted in a line which is primarily intended to carry high frequency waves modulated with signals, such as antenna lead-in, see FILTER, BAND SUPPRESSION and FILTER, BAND PASS. See also LIMITER, ELECTRICAL NOISE. View more Radio Frequency Interference Filter
May 2023
5
Marketplace 5915-00-504-7440
Request a Quotation from participating marketplace vendors
Related Documents 5915-00-504-7440 5+ Documents (More...)
Radio Frequency Interference Filter,EA162 RQST NE Updated Every Day 5915-00-504-7440 RQST Updated Every
/fsg-59/fsc-5915/us 5915-00-504-7440 Radio Frequency Interference Filter,EA162 RQST NE Updated Every
/fsg-59/fsc-5915/us
Restrictions 5915-00-504-7440
5915-00-504-7440 is a Radio Frequency Interference Filter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5915-00-504-7440
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5915-00-504-7440
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5915-00-504-7440
- Part Number
- Manufacturer
- Status
- EA162
- Manufacturer
- 77992 - Solar Mfg Corp (Obsolete)
- Original Design
- Original Design
Datasheet 5915-00-504-7440
- Characteristic
- Specifications
- FIIG
- Specifications
- A047B0
- Body Height [ADAU]
- 2.875 Inches Nominal
- Body Length [ADAQ]
- 5.032 Inches Minimum And 5.219 Inches Maximum
- Body Width [ADAT]
- 2.215 Inches Nominal
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Length [AEBY]
- 3.688 Inches Nominal
- Mounting Facility Type And Quantity [AXHR]
- 1 Unthreaded Hole
- Operating Current Rating Per Function In Amps [AHBC]
- 50.0 Blank
- Operating Voltage Rating And Type Per Function [CQGC]
- 30.0 Volts Dc Blank
- Inclosure Type [AKNA]
- Uninclosed
- Unthreaded Mounting Hole Diameter [AEBV]
- 0.201 Inches Nominal
Similar Supply Items to 5915-00-504-7440
Freight Information 5915-00-504-7440
5915-00-504-7440 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5915-00-504-7440 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5915-00-504-7440 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5915-00-504-7440 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5915-00-504-7440 is not classified as a special type of cargo when transported by water. 5915-00-504-7440 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
