5915-00-238-2584
Radio Frequency Interference Filter
5915002382584 002382584 G138-281-001 RF03418 RF3418
An item designed to suppress undesired (interfering) frequencies and have a minimal effect on the desired frequencies when inserted in an electrical power circuit. Excludes items which consist of a single capacitor, inductor, resistor, or devices consisting of only two or more circuit elements of the same basic name. Excludes FILTER, LOW PASS and SUPPRESSOR, IGNITION INTERFERENCE. For items designed to be inserted in a line which is primarily intended to carry high frequency waves modulated with signals, such as antenna lead-in, see FILTER, BAND SUPPRESSION and FILTER, BAND PASS. See also LIMITER, ELECTRICAL NOISE. View more Radio Frequency Interference Filter
May 2023
3
Marketplace 5915-00-238-2584
Request a Quotation from participating marketplace vendors
Related Documents 5915-00-238-2584 5+ Documents (More...)
Photo 1/2 NSN 5915-00-238-2584 (Identification) 2/2 - - 1.
United States (US) 4. 5915-00-238-2584 Marketplace Restrictions Approved Sources Datasheet Management
Restrictions 5915-00-238-2584
5915-00-238-2584 is a Radio Frequency Interference Filter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5915-00-238-2584
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5915-00-238-2584
- US Navy (N9BN)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- KE
Approved Sources 5915-00-238-2584
- Part Number
- Manufacturer
- Status
- G138-281-001
- Manufacturer
- 0D0D0 - Bae Systems Information And (Active)
- Primary Buy
- Primary Buy
- RF03418
- 13619 - Ems Development Corporation (Active)
- Secondary Buy
- Secondary Buy
- G138-281-001
- 88818 - Kearfott Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- RF3418
- 13619 - Ems Development Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5915-00-238-2584
- Characteristic
- Specifications
- FIIG
- Specifications
- A047B0
- Body Height [ADAU]
- 5.000 Inches Nominal
- Body Length [ADAQ]
- 3.000 Inches Nominal
- Body Width [ADAT]
- 1.620 Inches Nominal
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Length [AEBY]
- 3.500 Inches Nominal
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Width [AEHA]
- 1.130 Inches Nominal
- Functional Terminal Type And Quantity [CQDW]
- 1 Connector, Receptacle Input 1St Function
- Functional Terminal Type And Quantity [CQDW]
- 1 Tab, Solder Lug Ground 3Rd Function
- Functional Terminal Type And Quantity [CQDW]
- 2 Tab, Solder Lug Output 2Nd Function
- Mounting Facility Type And Quantity [AXHR]
- 4 Threaded Hole
- Mounting Facility Screw Thread Series Designator [AKEJ]
- Unc
- Nominal Thread Size [CQJX]
- 0.164 Inches
- Operating Current Rating Per Function In Amps [AHBC]
- 3.0 Blank
- Operating Temp Range [AFGA]
- +0.0/+70.0 Deg Celsius
- Operating Voltage Rating And Type Per Function [CQGC]
- 115.0 Volts Ac Blank
- Inclosure Type [AKNA]
- Encased
- Input Terminal Manufacturer Code [AHBN]
- 96906
- Input Terminal Identification [AHBP]
- Ms3113h12-3P
- Load Impedance Per Function [AHAS]
- 50.0 Ohms Blank
- Power Line Frequency Rating Per Function In Hertz [AHBB]
- 400.0 Blank
- Source Impedance Rating Per Function [AHAQ]
- 50.0 Ohms Blank
- Overall Height [ABKW]
- 5.755 Inches Nominal
- Special Features [FEAT]
- Flange Mounted
- Vibration Resistance Range In Hertz [AECR]
- +10.0/+500.0
- Style Designator [STYL]
- Rectangular Terminal/Terminals On One Surface
Weapon Systems (WSDC) 5915-00-238-2584
DLA Procurement Analysis 5915-00-238-2584
Management Data 5915-00-238-2584
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5915-00-238-2584
Freight Information 5915-00-238-2584
5915-00-238-2584 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061990. A Sub NMFC of X. It has a NMFC Description of ELECTRICAL EQUIP:FILTERS. 5915-00-238-2584 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 58500 which rates the freight between FCL and LCL. 5915-00-238-2584 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5915-00-238-2584 is not classified as a special type of cargo when transported by water. 5915-00-238-2584 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5915-00-238-2584
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- A-A-1898, Grade II, Water Resistant Cellulosic Cushioning
- --
- PPP-B-566 or PPP-B-676, Folding or Setup Box
- No special marking
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 5915-00-238-2584 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
