5910-01-271-0878

Electrolytic Fixed Capacitor

5910012710878 012710878 MIL-PRF-39003/1 63A6A14-14REVY 16758319-145 150D474X5015A2 M39003/01-8183 150D474X0015A2 M39003-01+5274 M39003/01-5674 MILC39003-1 M39003-01-5074 M39003-01-5274 MIL-C-39003/1

A capacitor, whose capacitance value cannot be adjusted or varied, having a chemically formed film as the dielectric. It may be a single unit, or consist of two or more fixed units which cannot be separated. View more Electrolytic Fixed Capacitor

5910-01-271-0878 CAPACITOR,FIXED,ELECTROLYTIC 5910012710878 012710878

Managed by United States
NSN Created on 17 Jan 1988
Data Last Changed
September 2025
NATO Update Count
27
NATO Data Quality
5910-01-271-0878 CAPACITOR,FIXED,ELECTROLYTIC 5910012710878 012710878 1/3
5910-01-271-0878 Photo 1/3
AAQL Style 26B for 5910-01-271-0878 2/3
NSN 5910-01-271-0878 (Identification) 2/3
AEBZ Style 3C for 5910-01-271-0878 3/3
NSN 5910-01-271-0878 (Identification) 3/3

5910-01-271-0878 Stock and Availability Marketplace 5910-01-271-0878

Need Help?
Request a Quotation from participating marketplace vendors
eBay Updated Every Day
5910-01-271-0878 RQST NE eBay
eBay Updated Every Day
5910-01-271-0878 RQST eBay
Amazon Updated Every Day
5910-01-271-0878 RQST NE Amazon

5910-01-271-0878 Related Documents Related Documents 5910-01-271-0878 5+ Documents (More...)

MIL-PRF-39003/1 63A6A14-14REVY 16758319-145 150D474X5015A2 M39003/01-8183 150D474X0015A2 M39003-01+5274
M39003/01-5674 MILC39003-1 M39003-01-5074 M39003-01-5274 MIL-C-39003/1 A capacitor, whose capacitance
Photo 1/3 NSN 5910-01-271-0878 (Identification) 2/3 NSN 5910-01-271-0878 (Identification) 3/3 -
M39003-01-5274 A capacitor, whose capacitance value cannot be adjusted or varied, having a chemically
M39003/01-5274 CAPACITOR,FIXED,ELECTROLYTIC 778 EA NS Request Quotation Subscribe to View Vendor Details
Electrolytic Fixed Capacitor 5910012710878 M39003/01-5674 MILC39003-1 M39003-01-5074 M39003-01-
M39003/01-5074 CAPACITOR,FIXED,ELECTROLYTIC 1 EA NS Request Quotation Subscribe to View Vendor Details
M39003/01-5274 CAPACITOR,FIXED,ELECTROLYTIC 778 EA NS Request Quotation Subscribe to View Vendor Details
M39003-01-5674 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS Request Quotation Subscribe to View Vendor Details
M39003/01-5074 CAPACITOR,FIXED,ELECTROLYTIC 1 EA NS Request Quotation Subscribe to View Vendor Details
M39003/01-5274 CAPACITOR,FIXED,ELECTROLYTIC 778 EA NS Request Quotation Subscribe to View Vendor Details
M39003-01-5674 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS Request Quotation Subscribe to View Vendor Details
M39003/01-5074 CAPACITOR,FIXED,ELECTROLYTIC 1 EA NS Request Quotation Subscribe to View Vendor Details
M39003/01-5274 CAPACITOR,FIXED,ELECTROLYTIC 778 EA NS Request Quotation Subscribe to View Vendor Details
M39003-01-5674 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS Request Quotation Subscribe to View Vendor Details

5910-01-271-0878 Demil Restrictions 5910-01-271-0878

DEMIL: A | DEMILI: 1 | CRITICALITY: Y | HMIC: P | PMIC: A | EDC: | ADPEC:

5910-01-271-0878 is a Electrolytic Fixed Capacitor that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.

5910-01-271-0878 HTS and ScheduleB Import and Export 5910-01-271-0878

5910-01-271-0878 End Users End Users 5910-01-271-0878

US Army (A918)
Effective Date:
1 Jun 2006
Former MOE Rule:
A196
US Air Force (FXGX)
Effective Date:
1 Jun 2006
Former MOE Rule:
FXTX
US Marine Corps (MC49)
Effective Date:
1 Jun 2006
Former MOE Rule:
MC13
US Navy (N9BN)
Effective Date:
1 Jun 2006
Former MOE Rule:
N9ND
Supplementary Collaborators:
GTKEHSHD
Brazil (YA01)
Effective Date:
1 Jul 2001
Spain (YB01)
Effective Date:
1 Aug 2003
Australia (ZA01)
Effective Date:
1 Feb 1998
Canada (ZC01)
Effective Date:
1 Aug 1999

5910-01-271-0878 Manufacturers Approved Sources 5910-01-271-0878

5910-01-271-0878 Technical Data Datasheet 5910-01-271-0878

Characteristic
Specifications
FIIG
A010B0
Electrical Polarization [AECQ]
Polarized
Anode Type [AECE]
Solid
Body Diameter [ABPM]
0.120 Inches Minimum And 0.151 Inches Maximum
Body Length [ADAQ]
0.286 Inches Nominal
Body Style [AAQL]
W/O Mtg Facilities, Axial Terminals
Capacitive Electrode Material [CWNJ]
Tantalum
Capacitance Value Per Section [CQBQ]
0.470 Microfarads Single Section
Case Insulation Material [CWSZ]
Plastic
Case Material [CWJK]
Metal
Criticality Code Justification [CRTL]
Feat
Dc Leakage At Maximum Operating Temp [CQLH]
5.0 Microamperes
Dc Leakage At Reference Temp [CWQH]
0.300 Microamperes
Dissipation Factor At Reference Temp In Percent [CWPM]
2.000
Features Provided [CBBL]
Hermetically Sealed Case
Mil-Std-1276 Wire Lead Type Designator [AARF]
N-4
Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
50.0 Dc Single Section
Nonderated Operating Temp [CQJJ]
-55.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
Reliability Failure Rate Level In Percent [AARH]
0.001
Reliability Indicator [AARG]
Established
Schematic Diagram Designator [AEBZ]
Electrode(S) Grounded To Case, W/Gnd Terminal
Special Features [FEAT]
Weibull Graded Failure Rate
Tolerance Range Per Section [CRTP]
-5.00/+5.00 Percent Single Section
Specification/Standard Data [ZZZK]
81349-Mil-C-39003/1 Government Specification
Terminal Diameter [AEBT]
0.020 Inches Nominal
Terminal Length [ABJT]
1.500 Inches Nominal
Terminal Type And Quantity [TTQY]
2 Uninsulated Wire Lead
Test Data Document [TEST]
81349-Mil-C-39003 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).

5910-01-271-0878 Weapon Systems (WSDC) Weapon Systems (WSDC) 5910-01-271-0878

5910-01-271-0878 Stock, Inventory and Procurement DLA Procurement Analysis 5910-01-271-0878

Last Stock Position:
121 In Stock
DLA Administrative Lead Time:
Subscribe
DLA Production Lead Time:
Subscribe
Subscribe to View DLA Inventory and Forecast...

5910-01-271-0878 Management Data Management Data 5910-01-271-0878

Effective Date
Organization
Unit of Issue
Unit Price
Qty Unit Pack
Apr 2023
Department of the Air Force (DF)
EA
Subscribe
1
Oct 2022
US Marine Corps (DM)
EA
Subscribe
1
Jan 2022
Defense Logistics Agency (DS)
EA
Subscribe
1
Oct 2021
US Marine Corps (DM)
EA
Subscribe
1
Jan 2021
Department of the Air Force (DF)
EA
Subscribe
1
Feb 2020
Department of the Air Force (DF)
EA
Subscribe
1
MOE
USC
Code
Statement
Order of Use
Jump To Code
Qty Per Assy
UOM
Technical Document
Quantative Expression
US Marine Corps (DM)
M
0
Reversal Of Phrase Code Z 5910-00-905-3645

Navy Navy

Cognizance:
9B
Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Marine Corps Marine Corps

Stores Account:
1
Stock Fund Account Item
Combat Essentiality:
5
Critical Repair Part to a Combat Essential End Item
Echelon Management:
B2
Operational Test:
No Special Procedures

5910-01-271-0878 Similar Items Similar Supply Items to 5910-01-271-0878

5910-01-271-0878 Freight Data Freight Information 5910-01-271-0878

5910-01-271-0878 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-01-271-0878 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-01-271-0878 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-01-271-0878 is not classified as a special type of cargo when transported by water. 5910-01-271-0878 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

5910-01-271-0878 Packaging Data Packaging Data 5910-01-271-0878

Responsible Activity
Packaging Data Source
Primary Inventory Control Activity (PICA)
--

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation
--
--
--
0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
85 to 110G
No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying
1
--
--
--
Physical Protection
Any Suitable Process
Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking
No Requirement
No Requirement
--
--
Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
Special requirements

Intermediate Pack Level

Quantity of Unit Packs
Container
PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
