5910-01-260-1324

Electrolytic Fixed Capacitor

5910012601324 012601324 MIL-C-39003/3 M39003/03-3058 M39003-03-0058 M39003-03-0158 M39003/03-0358 M39003/03-0359 M3900303-0258 10135069

A capacitor, whose capacitance value cannot be adjusted or varied, having a chemically formed film as the dielectric. It may be a single unit, or consist of two or more fixed units which cannot be separated. View more Electrolytic Fixed Capacitor

Managed by United States

NSN Created on 26 Jul 1987

Data Last Changed
May 2023

NATO Update Count
18

NATO Data Quality

5910-01-260-1324 CAPACITOR,FIXED,ELECTROLYTIC 5910012601324 012601324 1/3 — 5910-01-260-1324 Photo 1/3

AAQL Style 26B for 5910-01-260-1324 2/3 — NSN 5910-01-260-1324 (Identification) 2/3

AEBZ Style 3C for 5910-01-260-1324 3/3 — NSN 5910-01-260-1324 (Identification) 3/3

Marketplace 5910-01-260-1324

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

MIL-C-39003/3 CAPACITOR,FIXED,ELECTROLYTIC 30 EA NS

Subscribe to View Vendor Details...

M3900303-0158 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS

Subscribe to View Vendor Details...

M-39003-03-3058 CAPACITOR,FIXED,ELECTROLYTIC 1 EA NS

Subscribe to View Vendor Details...

M39003/03-3058 CAPACITOR,FIXED,ELECTROLYTIC 13 EA NS

Subscribe to View Vendor Details...

M39003/03-0359 CAPACITOR,FIXED,ELECTROLYTIC 6 EA NS

M39003/03-3058 CAPACITOR,FIXED,ELECTROLYTIC 38 EA NS

M39003/03-0158 CAPACITOR,FIXED,ELECTROLYTIC 20 EA NS

M39003/03-0258 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS

M39003/03-0358 CAPACITOR,FIXED,ELECTROLYTIC 26 EA NS

Subscribe to View Vendor Details...

M39003/03-0258 CAPACITOR,FIXED,ELECTROLYTIC 50 EA NS

Subscribe to View Vendor Details...

M3900303-0258 CAPACITOR,FIXED,ELECTROLYTIC RQST NS

Subscribe to View Vendor Details...

M39003/03-0358 CAPACITOR,FIXED,ELECTROLYTIC 199 EA NS

M39003/03—0358 CAPACITOR,FIXED,ELECTROLYTIC 39 EA NS

Subscribe to View Vendor Details...

M39003/03-3058 CAPACITOR,FIXED,ELECTROLYTIC 1 EA NS

M39003/03-0358 CAPACITOR,FIXED,ELECTROLYTIC 199 EA NS

Subscribe to View Vendor Details...

MIL-C-390033 CAPACITOR,FIXED,ELECTROLYTIC 1 EA NS

Subscribe to View Vendor Details...

M39003/03-0158 CAPACITOR,FIXED,ELECTROLYTIC 67 EA NS

M39003/03-0358 CAPACITOR,FIXED,ELECTROLYTIC 260 EA NS

Updated Every Day

5910-01-260-1324 RQST NE

Updated Every Day

5910-01-260-1324 RQST

Updated Every Day

5910-01-260-1324 RQST NE

Restrictions 5910-01-260-1324

5910-01-260-1324 is a Electrolytic Fixed Capacitor that does not have a nuclear hardened feature, but does have another critical feature or features such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.

Import and Export 5910-01-260-1324

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5910-01-260-1324

US Army (A918)
Effective Date:: 1 Jun 2006
Former MOE Rule:: A196; AMC 1 AMSC T IMC Z IMCACTY CD

US Coast Guard (C911)
Effective Date:: 1 Jun 2006
Former MOE Rule:: C007; AMC 1 AMSC T

US Air Force (FXGX)
Effective Date:: 1 Jun 2006
Former MOE Rule:: FXTX; AMC 1 AMSC T IMC Z IMCACTY SX

US Navy (N9BN)
Effective Date:: 1 Jun 2006
Former MOE Rule:: N9ND
Supplementary Collaborators:: GTHDKE; AMC 1 AMSC T IMC Z IMCACTY GH

Finland (WF01)
Effective Date:: 1 Apr 2011

Spain (YB01)
Effective Date:: 1 May 1997

Australia (ZA01)
Effective Date:: 1 Jun 1994

Germany (ZG01)
Effective Date:: 1 Apr 1991

Republic of Korea (ZH01)
Effective Date:: 1 Sep 2012

Approved Sources 5910-01-260-1324

Part Number
Manufacturer
Status
M39003/03-3058: 81349 - Military Specifications (Active); Definitive Standard; RNCC 2 RNVC 2 DAC 3
MIL-C-39003/3: 81349 - Military Specifications (Active); Incomplete Standard; RNCC 4 RNVC 1 DAC 3
M39003-03-0058: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
M39003-03-0158: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
M39003/03-0358: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
M39003/03-0359: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 3
M3900303-0258: 81349 - Military Specifications (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC E
10135069: A486G - Nimikkeistokeskus Ncb Finland (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 5910-01-260-1324

Characteristic
Specifications
FIIG: A010B0
Electrical Polarization [AECQ]: Polarized
Anode Type [AECE]: Solid
Body Diameter [ABPM]: 0.304 Inches Nominal
Body Length [ADAQ]: 0.716 Inches Nominal
Body Style [AAQL]: W/O Mtg Facilities, Axial Terminals
Capacitive Electrode Material [CWNJ]: Tantalum
Capacitance Value Per Section [CQBQ]: 100.000 Microfarads Single Section
Case Insulation Material [CWSZ]: Plastic
Case Material [CWJK]: Metal
Criticality Code Justification [CRTL]: Feat
Dc Leakage At Maximum Operating Temp [CQLH]: 188.0 Microamperes
Dc Leakage At Reference Temp [CWQH]: 15.000 Microamperes
Dissipation Factor At Reference Temp In Percent [CWPM]: 6.000
Features Provided [CBBL]: Hermetically Sealed Case
Mil-Std-1276 Wire Lead Type Designator [AARF]: N-4
Nonderated Continuous Voltage Rating And Type Per Section [CQWM]: 20.0 Dc Single Section
Nonderated Operating Temp [CQJJ]: -55.0 Deg Celsius Minimum And 125.0 Deg Celsius Maximum
Reliability Failure Rate Level In Percent [AARH]: 0.010
Reliability Indicator [AARG]: Established
Schematic Diagram Designator [AEBZ]: Electrode(S) Grounded To Case, W/Gnd Terminal
Special Features [FEAT]: Weibull Graded Failure Rate
Tolerance Range Per Section [CRTP]: -10.00/+10.00 Percent Single Section
Specification/Standard Data [ZZZK]: 81349-Mil-C-39003/3 Government Specification
Terminal Diameter [AEBT]: 0.025 Inches Nominal
Terminal Length [ABJT]: 1.500 Inches Nominal
Terminal Type And Quantity [TTQY]: 2 Uninsulated Wire Lead
Test Data Document [TEST]: 81349-Mil-C-39003 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).

Subscribe
View Data

DLA Procurement Analysis 5910-01-260-1324

DLA Administrative Lead Time:: Subscribe
DLA Production Lead Time:: Subscribe

Subscribe to View DLA Inventory and Forecast...

Management Data 5910-01-260-1324

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Jun 2015: Defense Logistics Agency (DS); EA; Subscribe; 1
Oct 2008: Department of the Army (DA); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Army (DA): A; F; When Exhausted Use 5910-01-283-9087
Department of the Navy (DN): N; F; When Exhausted Use 5910-01-283-9087

Army

Materiel Category and Inventory Manager:

Q: Electronics Materiel (DLA/GSA Items)

Appropriation and Budget Activity:

2: Stock Fund Secondary Items

Management Inventory Segment:

2: Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.

Weapons System / End Item / Homogeneous Group:

00: DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item

Accounting Requirements:

X: Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.

Navy

Cognizance:

9B: Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg

Similar Supply Items to 5910-01-260-1324

Freight Information 5910-01-260-1324

5910-01-260-1324 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-01-260-1324 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-01-260-1324 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-01-260-1324 is not classified as a special type of cargo when transported by water. 5910-01-260-1324 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5910-01-260-1324

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"; 85 to 110G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; --; --; --; --; --

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: --; --; --; --; --; Special requirements

Intermediate Pack Level

Quantity of Unit Packs
Container: See Method of Preservation; --

Contracting Technical Data File (CTDF) 5910-01-260-1324 October 2021

Criticality and Quality

Critical Item Code:
Flight Safety:
Life Support:
Certified Samples:
Serialization:
First Article Test (FAT):
Certificate of Quality Compliance:
Production Lot Testing:
Special Testing:
Qualified Products List (QPL):

Commercial Properties

Government Furnished Material:
Government Furnished Tooling:
Government Furnished Property:
Price Evaluation Code:
Diminshing Manufacturing Sources:
Warranty:
Commerical Off The Shelf (COTS):
End Item Application:
Auctioning Candidate:
Source of Procurement:
Contract Option:

Restrictions

Boeing Rights Guard:
Export Controlled:
Controlled Technical Data Package (TDP):
Restricted Technical Data Package (TDP):
Contains Classified Material
Weapons System Indicator Code (WSIC):: N

Packaging Requirements

Packaging Determination Table:
Packaging Review Code:
Special Packaging Instruction Number (SPIN):
Special Packaging Instruction Number Revision:
Special Packaging Instruction Number Date:
Pallet Reference Number Required:
