5910-01-257-0132
Ceramic Dielectric Variable Capacitor
5910012570132 012570132 10170-0012 7S-TRIK0
A capacitor whose capacitance value is controlled by a mechanical means which effects a continuous variation of its capacitance. It includes items consisting of two or more variable capacitors which are inseparable. View more Ceramic Dielectric Variable Capacitor
May 2023
5
Marketplace 5910-01-257-0132
Request a Quotation from participating marketplace vendors
Related Documents 5910-01-257-0132 5+ Documents (More...)
Photo 1/2 NSN 5910-01-257-0132 (Identification) 2/2 - - 1.
United States (US) 4. 5910-01-257-0132 Marketplace Restrictions Approved Sources Datasheet Management
Dielectric Variable Capacitor5910010154399 010154399 https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-01-257-0132
Ceramic Dielectric Variable Capacitor www.nsnlookup.com /fsg-59/fsc-5910/us 5910-01-257-0132 https
www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-477-8042 https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-01-257-0132
Account Upgrade 5910-00-477-8042Ceramic Dielectric Variable Capacitor5910004778042 004778042 0121-0446 7S-TRIK0
Request Quotation Updated Every Day 5910-00-858-9211 https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-01-257-0132
5910-00-858-9211Ceramic Dielectric Variable Capacitor5910008589211 008589211 0121-0443300450201 7S-TRIK0
-5910/us 5910-00-910-0285 Ceramic Dielectric Variable Capacitor 73TR1K0-02-4-5-275-TRIK0-02-4.5/ 7S-TRIK0
Ceramic Dielectric Variable Capacitor Capacitor5910011409474 011409474 1510-70-0130 7S-TRIK0 https
Restrictions 5910-01-257-0132
5910-01-257-0132 is a Ceramic Dielectric Variable Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5910-01-257-0132
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-01-257-0132
- US Air Force (FXGX)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- FXTX
Approved Sources 5910-01-257-0132
- Part Number
- Manufacturer
- Status
- 10170-0012
- Manufacturer
- 27914 - Honeywell International Inc (Active)
- Primary Buy
- Primary Buy
- 7S-TRIK0
- 52763 - Stettner Electronics Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-01-257-0132
- Characteristic
- Specifications
- FIIG
- Specifications
- A096A0
- Adjustment Device Drive Type And Quantity [CTGR]
- 1 Slotted Screw
- Adjustment Device Torque [AXGR]
- 11.000 Inch-Ounces Minimum And 48.000 Inch-Ounces Maximum
- Body Style [AAQL]
- Rotary
- Capacitance Change In Percent At Operating Temp From 25 Deg Celsius [CTGQ]
- +1.75 To 8.00 Minimum And -5.75/-1.75 Maximum Single Section
- Capacitance Range In Picofarads [CTGN]
- +4.5 To 20.0 Single Section
- Center To Center Distance Between Terminals Parallel To Diameter [AEBS]
- 7.5 Millimeters Nominal
- Terminal Width [AFWW]
- 1.2 Millimeters Nominal
- Mounting Facility Type And Quantity [AXHR]
- 3 Terminal
- Nonderated Voltage Rating And Type [CTGP]
- 110.0 Ac Rms Or 160.0 Dc Continuous Single Section
- Nonderated Operating Temp [CQJJ]
- -40.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
- Insulation Dc Resistance At 25 Deg Celsius [AXGT]
- 10.0 Gigohms
- Material [MATT]
- Metal Base
- Quality Factor At 25 Deg Celsius [AECJ]
- 500.0
- Inclosure Type [AKNA]
- Encased
- Overall Diameter [ADAV]
- 7.0 Millimeters Nominal
- Overall Height [ABKW]
- 8.2 Millimeters Nominal
- Temp Coefficient Of Capacitance In Ppm Per Deg Celsius [AEBC]
- -750.0 Single Section
- Terminal Length [ABJT]
- 3.9 Millimeters Nominal
- Terminal Location [APXH]
- Circumference On End Opposite Adjustment Control Perpendicular
- Terminal Type And Quantity [TTQY]
- 3 Printed Circuit
DLA Procurement Analysis 5910-01-257-0132
Management Data 5910-01-257-0132
Air Force
- Fund:
- SF
- Stock fund applicable to items managed for the Air Force by the respective Inventory Control Point
- Budget:
- 9
- 57X4921.070 - General Support DIV - Air Force decentralized managed expense items (ERRC XB3, XF3) with a unit cost of less than $250,000 that are requisitioned/procured at base (retail) level from DLA, GSA, Army, Navy, Depot Maintenance Service, Air Force Industrial Fund (AFMC), local manufacture and commercial vendors
- Aggregation Code:
- EH
- ELECTRONIC COMPONENTS
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - N
- Expendable. Condemn at User. Stock Fund (except Munitions).
Similar Supply Items to 5910-01-257-0132
Freight Information 5910-01-257-0132
5910-01-257-0132 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-01-257-0132 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-01-257-0132 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-01-257-0132 is not classified as a special type of cargo when transported by water. 5910-01-257-0132 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
