5910-01-105-0321
Paper-Plastic Dielectric Metallized Fixed Capacitor
5910011050321 011050321 61404-3129 BA27C405K-14
A capacitor whose capacitance value cannot be adjusted or varied having paper, plastic, or any combination of paper and plastic as the dielectric material with a metallic film deposited thereon. It may be a single unit or consist of two or more units which cannot be separated. View more Paper-Plastic Dielectric Metallized Fixed Capacitor
May 2023
11
Marketplace 5910-01-105-0321
Request a Quotation from participating marketplace vendors
Related Documents 5910-01-105-0321 5+ Documents (More...)
Photo 1/5 5910-01-105-0321 Photo 2/5 5910-01-105-0321 Photo 3/5 NSN 5910-01-105-0321 (Identification
Photo 2/5 5910-01-105-0321 Photo 3/5 NSN 5910-01-105-0321 (Identification Photo 2/5 5910-01-105
61404-3129 MIL-C-55514/4 A capacitor whose capacitance value cannot be adjusted or varied having
5910011050321 011050321,61404-3129 Upgrade 5910-01-105-0321Paper-Plastic Dielectric Metallized
Restrictions 5910-01-105-0321
5910-01-105-0321 is a Paper-Plastic Dielectric Metallized Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5910-01-105-0321
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-01-105-0321
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5910-01-105-0321
- Part Number
- Manufacturer
- Status
- 61404-3129
- Manufacturer
- 10109 - Power Paragon Inc (Active)
- Primary Buy
- Primary Buy
- BA27C405K-14
- 27556 - Imb Electronic Products Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-01-105-0321
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.480 Inches Nominal
- Body Length [ADAQ]
- 0.813 Inches Nominal
- Body Style [AAQL]
- W/O Mtg Facilities, Axial Terminals
- Capacitance Value Per Section [CQBQ]
- 4.000 Microfarads Single Section
- Case Material [CWJK]
- Plastic
- Dissipation Factor At Reference Temp In Percent [CWPM]
- 0.5000
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 200.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 125.0 Deg Celsius Maximum
- Insulation Resistance At Reference Temp [CWPK]
- 100000.0 Megohms
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Tolerance Range Per Section [CRTP]
- -10.00/+10.00 Percent Single Section
- Terminal Diameter [AEBT]
- 0.025 Inches Nominal
- Terminal Length [ABJT]
- 1.500 Inches Minimum
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
Similar Supply Items to 5910-01-105-0321
Freight Information 5910-01-105-0321
5910-01-105-0321 has freight characteristics managed by Australia.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-01-105-0321 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-01-105-0321 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-01-105-0321 is not classified as a special type of cargo when transported by water. 5910-01-105-0321 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5910-01-105-0321
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- --
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
