5910-01-058-1246
Paper-Plastic Dielectric Metallized Fixed Capacitor
5910010581246 010581246 MIL-PRF-83421/1 M83421/01-1179P MIL-C-83421/1
A capacitor whose capacitance value cannot be adjusted or varied having paper, plastic, or any combination of paper and plastic as the dielectric material with a metallic film deposited thereon. It may be a single unit or consist of two or more units which cannot be separated. View more Paper-Plastic Dielectric Metallized Fixed Capacitor
May 2023
21
Marketplace 5910-01-058-1246
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5910-01-058-1246 5+ Documents (More...)
Photo 1/4 5910-01-058-1246 Photo 2/4 NSN 5910-01-058-1246 (Identification) 3/4 NSN 5910-01-058-
RQST NE Updated Every Day 5910-01-058-1246 RQST Updated Every Day 5910-01-058-1246 RQST NE Related
5910010581246 010581246,MIL-PRF-83421/1 M83421/01-1179P MIL-C-83421/1 A capacitor whose capacitance
73K0J333+3 73K0J333-3 M83421/01-2131 M83421/01-2132M MIL-C-83421/1 10134901 A capacitor whose
5910010581246 010581246,MIL-PRF-83421/1 M83421/01-1179P MIL-C-83421/1 A capacitor whose capacitance
MIL-PRF-83421/1 M39022-09A181M https 5910013720835 013720835,MIL-PRF-83421 /1 004694820,MIL-PRF https
5910010581246 010581246,MIL-PRF-83421/1 M83421/01-1179P MIL-C-83421/1 A capacitor whose capacitance
A capacitor whose capacitance value cannot be adjusted or varied MIL-C-83421/ 1 https MIL-C-83421/
Restrictions 5910-01-058-1246
5910-01-058-1246 is a Paper-Plastic Dielectric Metallized Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item contains gold.
Import and Export 5910-01-058-1246
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-01-058-1246
- Spain (YB01)
- Effective Date:
- 1 Dec 2008
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5910-01-058-1246
- Part Number
- Manufacturer
- Status
- M83421/01-1179P
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-83421/1
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-C-83421/1
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-01-058-1246
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.223 Inches Maximum
- Body Length [ADAQ]
- 0.687 Inches Nominal
- Body Style [AAQL]
- W/O Mtg Facilities, Axial Terminals
- Capacitance Value Per Section [CQBQ]
- 0.120 Microfarads Single Section
- Case Insulation Material [CWSZ]
- Plastic
- Case Material [CWJK]
- Metal
- Dissipation Factor At Reference Temp In Percent [CWPM]
- 0.1500
- Features Provided [CBBL]
- Hermetically Sealed Case
- Mil-Std-1276 Wire Lead Type Designator [AARF]
- N-2
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 30.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -65.0 Deg Celsius Minimum And 100.0 Deg Celsius Maximum
- Insulation Resistance At Maximum Operating Temp [CQBF]
- 300000.0 Megohms
- Insulation Resistance At Reference Temp [CWPK]
- 3000000.0 Megohms
- Precious Material And Location [PMLC]
- Terminals Gold
- Reliability Failure Rate Level In Percent [AARH]
- 0.1000
- Reliability Indicator [AARG]
- Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Tolerance Range Per Section [CRTP]
- -5.00/+5.00 Percent Single Section
- Specification/Standard Data [ZZZK]
- 81349-Mil-C-83421/1 Government Specification
- Terminal Diameter [AEBT]
- 0.025 Inches Nominal
- Terminal Length [ABJT]
- 1.625 Inches Minimum
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
- Test Data Document [TEST]
- 81349-Mil-C-83421 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
