5910-00-943-3921
Paper Dielectric Fixed Capacitor
5910009433921 009433921 MILC25-7 CP72B1EG605K1
A capacitor whose capacitance value cannot be adjusted or varied, having paper as the dielectric material. It may be a single unit or consist of two or more fixed units which cannot be seperated. For items whose dielectric material consist of plasticized (plastic impregnated) paper or paper-plastic combinations, see CAPACITOR, FIXED, PLASTIC DIELECTRIC. For items whose electrodes consist of a metallic film deposited (metallized) on the dielectric material, see CAPACITOR, FIXED, METALIZED, PAPER-PLASTIC DIELECTRIC. View more Paper Dielectric Fixed Capacitor
May 2023
23
Marketplace 5910-00-943-3921
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-943-3921 5+ Documents (More...)
Photo 1/3 NSN 5910-00-943-3921 (Identification) 2/3 NSN 5910-00-943-3921 (Identification) 3/3 -
RQST NE Updated Every Day 5910-00-943-3921 RQST Updated Every Day 5910-00-943-3921 RQST NE Related Documents
MILC19978 MILC19978-3 CP072SF2 An item primarily designed to position and/or restrain CQ072FD5 MILC25-7
Fixed Capacitor5910009433921 009433921 MILC25-7 MILC19978 MILC19978-3 CP072SF2 An item primarily designed
CP72B1EG605K1 A capacitor whose capacitance value cannot be adjusted or varied, having a plastic,
Paper Dielectric Fixed Capacitor 009433921 Upgrade your Account Upgrade 5910-00-943-3921Paper Dielectric
Restrictions 5910-00-943-3921
5910-00-943-3921 is a Paper Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-943-3921
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-943-3921
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5910-00-943-3921
- Part Number
- Manufacturer
- Status
- CP72B1EG605K1
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MILC25-7
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
Datasheet 5910-00-943-3921
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Height [ADAU]
- 4.000 Inches Nominal
- Body Length [ADAQ]
- 3.750 Inches Nominal
- Body Style [AAQL]
- W/O Mtg Facilities, Terminal(S) On One Surface
- Body Width [ADAT]
- 1.750 Inches Nominal
- Case Material [CWJK]
- Metal
- Dissipation Factor At Reference Temp In Percent [CWPM]
- 1.0000
- Features Provided [CBBL]
- Hermetically Sealed Case
- Capacitance Value Per Section [CQBQ]
- 6.000 Microfarads Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 1000.0 Dc Single Section
- Insulation Resistance At Maximum Operating Temp [CQBF]
- 20.0 Megohm-Microfarads
- Terminal Surface Treatment [CWSG]
- Solder
- Insulation Resistance At Reference Temp [CWPK]
- 2000.0 Megohm-Microfarads
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Tolerance Range Per Section [CRTP]
- -10.00 To 10.00 Percent Single Section
- Terminal Type And Quantity [TTQY]
- 2 Tab, Solder Lug
- Test Data Document [TEST]
- 81349-Mil-C-25 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Similar Supply Items to 5910-00-943-3921
Freight Information 5910-00-943-3921
5910-00-943-3921 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-943-3921 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-943-3921 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-00-943-3921 is not classified as a special type of cargo when transported by water. 5910-00-943-3921 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5910-00-943-3921
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- --
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
