5910-00-810-1255
Ceramic Dielectric Fixed Capacitor
5910008101255 008101255 6023290-27 10065568-14 2300576R91 GA0-91UUF5PCT
A capacitor, whose capacitance value cannot be adjusted or varied, having a ceramic dielectric.It may be a single unit, or consist of two or more fixed units which cannot be separated. View more Ceramic Dielectric Fixed Capacitor
May 2023
41
Marketplace 5910-00-810-1255
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-810-1255 5+ Documents (More...)
Photo 1/4 5910-00-810-1255 Photo 2/4 NSN 5910-00-810-1255 (Identification) 3/4 NSN 5910-00-810-
5910-00-810-1255 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-810-1255
Ceramic Dielectric Fixed Capacitor 008101255 Day 5910-00-810-1255 RQST NE Related Documents https
Navy (DN)NZDiscontinued-Use 5910-00-810-1255Defense Logistics Agency (DS)IZDiscontinued-Use 5910-00-810-1255
www.nsnlookup.com /fsg-99/fsc-9999/dk 9999-22-600-6774 Ceramic Dielectric Fixed Capacitor 226006774 225-9433 5910-00-810-1255
111-9433 5910-01-335-6123 5910-01-446-6369 5910-01-334-1877 5910-01-262-3590 5910-00-225-9433 5910-00-810-1255
111-9433 5910-01-335-6123 5910-01-446-6369 5910-01-334-1877 5910-01-262-3590 5910-00-225-9433 5910-00-810-1255
111-9433 5910-01-335-6123 5910-01-446-6369 5910-01-334-1877 5910-01-262-3590 5910-00-225-9433 5910-00-810-1255
Restrictions 5910-00-810-1255
5910-00-810-1255 is a Ceramic Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-810-1255
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-810-1255
- US Air Force (FXGX)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- FXTX
- Supplementary Receivers:
- SJ
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- NIND
- Supplementary Collaborators:
- HDKE
- Spain (YB01)
- Effective Date:
- 1 Sep 2008
- Israel (YD01)
- Effective Date:
- 1 Aug 2016
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Kuwait (YK01)
- Effective Date:
- 1 Jan 2015
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
Approved Sources 5910-00-810-1255
- Part Number
- Manufacturer
- Status
- 10065568-14
- Manufacturer
- 18876 - Us Army Aviation And Missile Command (Active)
- Primary Buy
- Primary Buy
- 2300576R91
- 10001 - Navair And Navsea Managed Original (Active)
- Secondary Buy
- Secondary Buy
- GA0-91UUF5PCT
- 78488 - Stackpole Corp The (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 6023290-27
- 07187 - Honeywell International Inc. (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5910-00-810-1255
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.150 Inches Minimum And 0.170 Inches Maximum
- Body Length [ADAQ]
- 0.330 Inches Maximum
- Body Style [AAQL]
- W/O Mtg Facilities, Axial Terminalsw/O Mtg Facilities, Axial Terminalsw/O Mtg Facilities, Axial Terminals
- Capacitance Value Per Section [CQBQ]
- 0.910 Picofarads Single Section
- Case Material [CWJK]
- Plastic
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 500.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
- Insulation Resistance At Reference Temp [CWPK]
- 1000.0 Megohms
- Power Factor At Reference Temp In Percent [CWPN]
- 1.0000
- Reliability Indicator [AARG]
- Not Establishednot Establishednot Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Tolerance Range Per Section [CRTP]
- -5.00/+5.00 Percent Single Section
- Voltage Temp Limits Per Section In Percent Capacitance Change [CQFB]
- -2.0/+2.0 Without Voltage Applied Single Section
- Terminal Diameter [AEBT]
- 0.028 Inches Minimum And 0.032 Inches Maximum
- Terminal Length [ABJT]
- 1.500 Inches Nominal1.500 Inches Nominal1.500 Inches Nominal
- Terminal Surface Treatment [CWSG]
- Solder
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
Weapon Systems (WSDC) 5910-00-810-1255
DLA Procurement Analysis 5910-00-810-1255
Management Data 5910-00-810-1255
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5910-00-810-1255
Freight Information 5910-00-810-1255
5910-00-810-1255 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-810-1255 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-810-1255 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-00-810-1255 is not classified as a special type of cargo when transported by water. 5910-00-810-1255 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5910-00-810-1255
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- --
- Special requirements
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
