5910-00-735-8527
Ceramic Dielectric Fixed Capacitor
5910007358527 007358527 8945423-13
A capacitor, whose capacitance value cannot be adjusted or varied, having a ceramic dielectric.It may be a single unit, or consist of two or more fixed units which cannot be separated. View more Ceramic Dielectric Fixed Capacitor
May 2023
13
Marketplace 5910-00-735-8527
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-735-8527 5+ Documents (More...)
5910-00-735-8527 Photo 5/14 5910-00-735-8527 Photo 6/14 5910-00-735-8527 Photo 7/14 5910-00-735-8527
Photo 8/14 5910-00-735-8527 Photo 9/14 5910-00-735-8527 Photo 10/14 5910-00-735-8527 Photo 11/14 5910
225-9433 5910-00-810-1255 5910-00-243-6322 5910-00-172-2738 5910-00-280-5705 5910-01-260-7077 5910-00-735-8527
225-9433 5910-00-810-1255 5910-00-243-6322 5910-00-172-2738 5910-00-280-5705 5910-01-260-7077 5910-00-735-8527
Capacitor 991982678 243-6322 5910-00-172-2738 5910-00-280-5705 5910-01-260-7077 5910-00-438-5707 5910-00-735-8527
Capacitor 991988972 243-6322 5910-00-172-2738 5910-00-280-5705 5910-01-260-7077 5910-00-438-5707 5910-00-735-8527
225-9433 5910-00-810-1255 5910-00-243-6322 5910-00-172-2738 5910-00-280-5705 5910-01-260-7077 5910-00-735-8527
Restrictions 5910-00-735-8527
5910-00-735-8527 is a Ceramic Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-735-8527
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-735-8527
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5910-00-735-8527
- Part Number
- Manufacturer
- Status
- 8945423-13
- Manufacturer
- 11447 - L3 Technologies, Inc. (Active)
- Primary Buy
- Primary Buy
- 8945423-13
- 49671 - Lockheed Martin Corporation (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-00-735-8527
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.140 Inches Nominal
- Body Length [ADAQ]
- 0.655 Inches Nominal
- Capacitance Value Per Section [CQBQ]
- 1000.000 Picofarads Single Section
- Features Provided [CBBL]
- Mounting Hardware
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 750.0 Dc Single Section
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- Feedthrough
- Special Features [FEAT]
- Feed Thru W/End Cap Terminations
- Tolerance Range Per Section [CRTP]
- -20.00/+20.00 Percent Single Section
- Terminal Surface Treatment [CWSG]
- Solder
Similar Supply Items to 5910-00-735-8527
Freight Information 5910-00-735-8527
5910-00-735-8527 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-735-8527 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5910-00-735-8527 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-735-8527 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5910-00-735-8527 is not classified as a special type of cargo when transported by water. 5910-00-735-8527 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
