5910-00-709-9883
Paper-Plastic Dielectric Metallized Fixed Capacitor
5910007099883 007099883 116P18601R5S13 4070-030-09
A capacitor whose capacitance value cannot be adjusted or varied having paper, plastic, or any combination of paper and plastic as the dielectric material with a metallic film deposited thereon. It may be a single unit or consist of two or more units which cannot be separated. View more Paper-Plastic Dielectric Metallized Fixed Capacitor
May 2023
10
Marketplace 5910-00-709-9883
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-709-9883 5+ Documents (More...)
/fsg-59/fsc-5910/us
Photo 1/4 5910-00-709-9883 Photo 2/4 NSN 5910-00-709-9883 (Identification) 3/4 NSN 5910-00-709-
Photo 2/4 NSN 5910-00-709-9883 (Identification) 3/4 NSN 5910-00-709- Photo 2/4 NSN 5910-00-709-
Marketplace Restrictions Approved Sources Datasheet https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-709-9883
5910007099883 007099883,116P18601R5S13 116P18601R5S135910007099883 007099883,116P18601R5S13 Upgrade
Restrictions 5910-00-709-9883
5910-00-709-9883 is a Paper-Plastic Dielectric Metallized Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-709-9883
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-709-9883
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5910-00-709-9883
- Part Number
- Manufacturer
- Status
- 116P18601R5S13
- Manufacturer
- 14655 - Cornell-Dubilier Electronics (Replaced)
- Original Design
- Original Design
- 4070-030-09
- 93568 - Harsco Corp Bmy-Combat Systems Div (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 116P18601R5S13
- 00853 - Cornell-Dubilier Marketing Inc (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5910-00-709-9883
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 1.000 Inches Minimum And 1.016 Inches Maximum
- Body Length [ADAQ]
- 2.562 Inches Minimum And 2.593 Inches Maximum
- Body Style [AAQL]
- W/O Mtg Facilities, Axial Terminals
- Capacitance Value Per Section [CQBQ]
- 18.000 Microfarads Single Section
- Case Material [CWJK]
- Metal
- Features Provided [CBBL]
- Hermetically Sealed Case
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 150.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
- Insulation Resistance At Maximum Operating Temp [CQBF]
- 20.0 Megohm-Microfarads
- Insulation Resistance At Reference Temp [CWPK]
- 2000.0 Megohm-Microfarads
- Power Factor At Reference Temp In Percent [CWPN]
- 1.000
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Tolerance Range Per Section [CRTP]
- -20.00/+20.00 Percent Single Section
- Terminal Diameter [AEBT]
- 0.025 Inches Nominal
- Terminal Length [ABJT]
- 1.625 Inches Minimum
- Terminal Surface Treatment [CWSG]
- Solder
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
Similar Supply Items to 5910-00-709-9883
Freight Information 5910-00-709-9883
5910-00-709-9883 has freight characteristics.. 5910-00-709-9883 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
