5910-00-617-4305
Plastic Dielectric Fixed Capacitor
5910006174305 006174305 B238-5005-60K 615G68396
A capacitor whose capacitance value cannot be adjusted or varied, having a plastic, plastic film, plasticized (plastic impregnated) paper, or any combination of plastic and paper or plastic and paper films as the dielectric material. The plastic may be one or more types of synthetic compounds such as polyesters, polyfluorides, polycabonates, and the like. It may be a single unit, or consist of two or more fixed units which cannot be separated. For items whose electrodes consist of a metallic film deposited (metallized) on the dielectric material, see CAPACITOR, FIXED, METALLIZED, PAPER-PLASTIC DIELECTRIC. View more Plastic Dielectric Fixed Capacitor
May 2023
23
Marketplace 5910-00-617-4305
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-617-4305 5+ Documents (More...)
) https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-617-4305 Plastic Dielectric Fixed Capacitor 006174305
-59/fsc-5910/us 5910-00-617-4305 Plastic Dielectric Fixed Capacitor 006174305 https//www.nsnlookup.com
Plastic Dielectric Fixed Capacitor 006174305 4305 Plastic Dielectric Fixed Capacitor 006174305
Per AssyUOMTechnical DocumentQuantative ExpressionDepartment of the Navy (DN)NLSuperseded By 5910-00-617-4305
Plastic Dielectric Fixed Capacitor 006174305 of the Navy (DN)NLSuperseded By 5910-00-617-4305 https
AssyUOMTechnical DocumentQuantative ExpressionDepartment of the Navy (DN)NZDiscontinued-Use 5910-00-617-4305
Restrictions 5910-00-617-4305
5910-00-617-4305 is a Plastic Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-617-4305
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-617-4305
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- KE
Approved Sources 5910-00-617-4305
- Part Number
- Manufacturer
- Status
- B238-5005-60K
- Manufacturer
- 81413 - Bae Systems Information And (Active)
- Primary Buy
- Primary Buy
- 615G68396
- 84411 - American Shizuki Corp (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- B238-5005-60K
- 82199 - Rohde & Schwarz Usa, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-00-617-4305
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.400 Inches Nominal
- Body Length [ADAQ]
- 0.875 Inches Nominal
- Body Style [AAQL]
- W/O Mtg Facilities, Axial Terminals
- Capacitance Value Per Section [CQBQ]
- 68000.000 Picofarads Single Section
- Case Material [CWJK]
- Metal
- Dielectric Material [CWSS]
- Plastic Polyethylene Terephthalate
- Dissipation Factor At Reference Temp In Percent [CWPM]
- 1.0000
- Features Provided [CBBL]
- Hermetically Sealed Case
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 600.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 150.0 Deg Celsius Maximum
- Internal Electrical Connection Type [AFHW]
- Inserted Tab
- Insulation Resistance At Reference Temp [CWPK]
- 30000.0 Megohm-Microfarads
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Terminal Length [ABJT]
- 1.500 Inches Nominal
- Terminal Surface Treatment [CWSG]
- Solder
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
- Tolerance Range Per Section [CRTP]
- -10.00/+10.00 Percent Single Section
DLA Procurement Analysis 5910-00-617-4305
Management Data 5910-00-617-4305
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5910-00-617-4305
Freight Information 5910-00-617-4305
5910-00-617-4305 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-617-4305 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-617-4305 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-00-617-4305 is not classified as a special type of cargo when transported by water. 5910-00-617-4305 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5910-00-617-4305
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-P-130, Laminated and Creped Wrapping Paper
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- Special requirements
- MIL-P-130, Laminated and Creped Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
Contracting Technical Data File (CTDF) 5910-00-617-4305 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- N
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
