5910-00-543-9081
Paper Dielectric Fixed Capacitor
5910005439081 005439081 MILC25 330615 CPB006-013 C106P CP09A1KF473K3 035-099
A capacitor whose capacitance value cannot be adjusted or varied, having paper as the dielectric material. It may be a single unit or consist of two or more fixed units which cannot be seperated. For items whose dielectric material consist of plasticized (plastic impregnated) paper or paper-plastic combinations, see CAPACITOR, FIXED, PLASTIC DIELECTRIC. For items whose electrodes consist of a metallic film deposited (metallized) on the dielectric material, see CAPACITOR, FIXED, METALIZED, PAPER-PLASTIC DIELECTRIC. View more Paper Dielectric Fixed Capacitor
May 2023
46
Marketplace 5910-00-543-9081
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-543-9081 5+ Documents (More...)
Photo 1/3 NSN 5910-00-543-9081 (Identification) 2/3 NSN 5910-00-543-9081 (Identification) 3/3 -
MILC25 CAPACITOR,FIXED,PAPER DIELECTRIC 3 EA NS Request Quotation Updated Every Day 5910-00-543-9081
MILC25 CAPACITOR,FIXED,PAPER DIELECTRIC 41 EA NS Request Quotation Subscribe to View Vendor Details..
MILC25 CAPACITOR,FIXED,PAPER DIELECTRIC 24 EA NS Request Quotation Subscribe to View Vendor Details..
JavaScript in your web browser . 5910-00-644-0822Paper https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-543-9081
Paper Dielectric Fixed Capacitor 005439081 Account Upgrade 5910-00-543-9081Paper Dielectric Fixed
MILC25 CAPACITOR,FIXED,PAPER DIELECTRIC 41 EA NS Request Quotation Subscribe to View Vendor Details..
MILC25 CAPACITOR,FIXED,PAPER DIELECTRIC 24 EA NS Request Quotation Subscribe to View Vendor Details..
MILC25 CAPACITOR,FIXED,PAPER DIELECTRIC 41 EA NS Request Quotation Subscribe to View Vendor Details..
MILC25 CAPACITOR,FIXED,PAPER DIELECTRIC 24 EA NS Request Quotation Subscribe to View Vendor Details..
Restrictions 5910-00-543-9081
5910-00-543-9081 is a Paper Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5910-00-543-9081
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-543-9081
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Jan 2002
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Malaysia (YW01)
- Effective Date:
- 1 Apr 1991
- Thailand (YY01)
- Effective Date:
- 1 Feb 2015
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Nov 2006
Approved Sources 5910-00-543-9081
- Part Number
- Manufacturer
- Status
- CP09A1KF473K3
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MILC25
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- 330615
- 00853 - Cornell-Dubilier Marketing Inc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- CPB006-013
- 0ZW31 - Measurement Specialties Inc (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- C106P
- 56289 - Sprague Electric Co World Hqs (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 330615
- 06141 - L3 Aviation Products, Inc. (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- 035-099
- 92739 - Ampex Systems Corp (Replaced)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-00-543-9081
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.463 Inches Nominal
- Body Height [ADAU]
- 0.463 Inches Nominal
- Body Length [ADAQ]
- 1.438 Inches Nominal
- Body Style [AAQL]
- W/O Mtg Facilities, Axial Terminals
- Body Width [ADAT]
- 0.463 Inches Nominal
- Case Insulation Material [CWSZ]
- Plastic
- Case Material [CWJK]
- Metal
- Dissipation Factor At Reference Temp In Percent [CWPM]
- 1.0000
- Features Provided [CBBL]
- Hermetically Sealed Case
- Capacitance Value Per Section [CQBQ]
- 47000.000 Picofarads Single Section
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 600.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 125.0 Deg Celsius Maximum
- Insulation Resistance At Maximum Operating Temp [CQBF]
- 150.0 Megohms
- Internal Electrical Connection Type [AFHW]
- Extended Foil
- Terminal Surface Treatment [CWSG]
- Solder
- Insulation Resistance At Reference Temp [CWPK]
- 18000.0 Megohms
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Terminal Length [ABJT]
- 1.625 Inches Minimum
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
- Test Data Document [TEST]
- 81349-Mil-C-25 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
- Tolerance Range Per Section [CRTP]
- -10.00 To 10.00 Percent Single Section
Similar Supply Items to 5910-00-543-9081
Freight Information 5910-00-543-9081
5910-00-543-9081 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-543-9081 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-543-9081 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5910-00-543-9081 is not classified as a special type of cargo when transported by water. 5910-00-543-9081 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5910-00-543-9081
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- A-A-1051, Paperboard Cushioning
- --
- --
- --
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- ASTM-D5118, Type CF, Class Weather-Resistant, Corrugated Fiberboard Box
