5910-00-521-7771
Paper Dielectric Fixed Capacitor
5910005217771 005217771 AS3209 7238958
A capacitor whose capacitance value cannot be adjusted or varied, having paper as the dielectric material. It may be a single unit or consist of two or more fixed units which cannot be seperated. For items whose dielectric material consist of plasticized (plastic impregnated) paper or paper-plastic combinations, see CAPACITOR, FIXED, PLASTIC DIELECTRIC. For items whose electrodes consist of a metallic film deposited (metallized) on the dielectric material, see CAPACITOR, FIXED, METALIZED, PAPER-PLASTIC DIELECTRIC. View more Paper Dielectric Fixed Capacitor
May 2023
8
Marketplace 5910-00-521-7771
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-521-7771 5+ Documents (More...)
Photo 1/3 NSN 5910-00-521-7771 (Identification) 2/3 NSN 5910-00-521-7771 (Identification) 3/3 -
AS3209 CAPACITOR,FIXED,PAPER DIELECTRIC 16 EA NS Request Quotation Updated Every Day 5910-00-521-7771
AS3209 CAPACITOR,FIXED,PAPER DIELECTRIC 16 EA NS Request Quotation Updated Every Day 5910-00-544-6743
CAPACITOR,FIXED,PAPER DIELECTRIC 400 EA NS Request AS3209 CAPACITOR,FIXED,PAPER DIELECTRIC 16 EA NS
AS3209-030 O-RING 99 EA NS Request Quotation Subscribe to View Vendor Details...
AS3209-030 O-RING RQST NS Request Quotation Subscribe to View Vendor Details...
Restrictions 5910-00-521-7771
5910-00-521-7771 is a Paper Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5910-00-521-7771
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-521-7771
- National Security Agency (DGX1)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- DTX1
- Supplementary Receivers:
- TX
- General Services Administration (TGM1)
- Effective Date:
- 3 Sep 1997
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5910-00-521-7771
- Part Number
- Manufacturer
- Status
- AS3209
- Manufacturer
- 23160 - Lindgren Rf Enclosures Inc (Active)
- Primary Buy
- Primary Buy
- 7238958
- 98749 - Sacramento Air Logistics Center (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-00-521-7771
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Height [ADAU]
- 2.000 Inches Nominal
- Body Length [ADAQ]
- 1.130 Inches Nominal
- Body Style [AAQL]
- W/Thd Mtg Hole(S)/Stud(S), Terminal(S) On One Surface
- Body Width [ADAT]
- 0.750 Inches Nominal
- Case Material [CWJK]
- Metal
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Length [AEBY]
- 0.625 Inches Nominal
- Dissipation Factor At Reference Temp In Percent [CWPM]
- 1.000
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Width [AEHA]
- 0.375 Inches Nominal
- Features Provided [CBBL]
- Hermetically Sealed Case
- Capacitance Value Per Section [CQBQ]
- 2.500 Microfarads Single Section
- Mounting Facility Type And Quantity [AXHR]
- 2 Threaded Mounting Studs
- Nominal Thread Size [CQJX]
- 0.138 Inches
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 300.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
- Mounting Facility Screw Thread Series Designator [AKEJ]
- Unc
- Internal Electrical Connection Type [AFHW]
- Extended Foil
- Insulation Resistance At Maximum Operating Temp [CQBF]
- 20.0 Megohm-Microfarads
- Insulation Resistance At Reference Temp [CWPK]
- 2000.0 Megohm-Microfarads
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- Electrode(S) Grounded To Case
- Tolerance Range Per Section [CRTP]
- -10.00 To 10.00 Percent Single Section
- Terminal Length [ABJT]
- 0.380 Inches Nominal
- Terminal Surface Treatment [CWSG]
- Solder
- Terminal Type And Quantity [TTQY]
- 1 Tab, Solder Lug
