5910-00-511-2717
Plastic Dielectric Fixed Capacitor
5910005112717 005112717 933-1039-040 135-0473 292P47352 292P47392 CP3473-047UFD200V
A capacitor whose capacitance value cannot be adjusted or varied, having a plastic, plastic film, plasticized (plastic impregnated) paper, or any combination of plastic and paper or plastic and paper films as the dielectric material. The plastic may be one or more types of synthetic compounds such as polyesters, polyfluorides, polycabonates, and the like. It may be a single unit, or consist of two or more fixed units which cannot be separated. For items whose electrodes consist of a metallic film deposited (metallized) on the dielectric material, see CAPACITOR, FIXED, METALLIZED, PAPER-PLASTIC DIELECTRIC. View more Plastic Dielectric Fixed Capacitor
May 2023
54
Marketplace 5910-00-511-2717
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-511-2717 5+ Documents (More...)
Photo 1/8 5910-00-511-2717 Photo 2/8 5910-00-511-2717 Photo 3/8 5910-00-511-2717 Photo 4/8 5910
-00-511-2717 Photo 5/8 5910-00-511-2717 Photo 6/8 NSN 5910-00-511-2717 (Identification) 7/8 NSN 5910-
4910-66-135-0473 3+ Documents ( More... ) https//www.nsnlookup.com /fsg-49/fsc-4910/au 4910-66-135-0473
4910-66-135-0473 3+ Documents ( More... ) https https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00
Plastic Dielectric Fixed Capacitor 005112717 5910-00-511-2717 (Identification) 7/8 NSN 5910- https
Navy (DN)NZDiscontinued-Use 5910-00-511-2717Defense Logistics Agency (DS)IZDiscontinued-Use 5910-00-511-2717
Restrictions 5910-00-511-2717
5910-00-511-2717 is a Plastic Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-511-2717
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-511-2717
- NASA (G170)
- Effective Date:
- 1 Apr 1991
- Poland (WP01)
- Effective Date:
- 1 Jun 2007
- Brazil (YA01)
- Effective Date:
- 1 Jan 2002
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Saudi Arabia (YS01)
- Effective Date:
- 1 Feb 2015
- Malaysia (YW01)
- Effective Date:
- 1 Aug 2000
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Belgium (ZB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- France (ZF01)
- Effective Date:
- 1 Apr 2000
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5910-00-511-2717
- Part Number
- Manufacturer
- Status
- 292P47352
- Manufacturer
- 56289 - Sprague Electric Co World Hqs (Active)
- Primary Buy
- Primary Buy
- 292P47392
- 56289 - Sprague Electric Co World Hqs (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- CP3473-047UFD200V
- 23934 - Power/Mate Co (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 933-1039-040
- 13499 - Rockwell Collins, Inc. (Active)
- Advisory Reference
- Advisory Reference
- 135-0473
- 54817 - Autek Systems Corp (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5910-00-511-2717
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.290 Inches Nominal
- Body Length [ADAQ]
- 0.562 Inches Nominal
- Body Style [AAQL]
- W/O Mtg Facilities, Axial Terminals
- Capacitance Value Per Section [CQBQ]
- 0.047 Microfarads Single Section
- Case Material [CWJK]
- Plastic
- Dissipation Factor At Reference Temp In Percent [CWPM]
- 1.0000
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 200.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
- Insulation Resistance At Reference Temp [CWPK]
- 50000.0 Megohm-Microfarads
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Special Features [FEAT]
- Resin-Coated
- Terminal Diameter [AEBT]
- 0.032 Inches Nominal
- Terminal Length [ABJT]
- 1.250 Inches Minimum
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
- Tolerance Range Per Section [CRTP]
- -5.00/+5.00 Percent Single Section
Similar Supply Items to 5910-00-511-2717
Freight Information 5910-00-511-2717
5910-00-511-2717 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-511-2717 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-511-2717 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-00-511-2717 is not classified as a special type of cargo when transported by water. 5910-00-511-2717 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5910-00-511-2717
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- Packaging Data does not meet current MIL-STD-2073-1E
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- --
- --
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- --
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
