5910-00-456-4474

Electrolytic Fixed Capacitor

5910004564474 004564474 150D105X9035A2 K1J35KS TAS105K035P1A 420001 S30-1218 C41056 096-1005-00 336948 SNS105A035ML 8412778-87 SA1NFT 150D105X9035A2DYS 02-030 037-164 100082 10047-723 STA5185-1 SCM105FP035D2 SNS105A035K1 150D105X9035-2A 0000037-164

A capacitor, whose capacitance value cannot be adjusted or varied, having a chemically formed film as the dielectric. It may be a single unit, or consist of two or more fixed units which cannot be separated. View more Electrolytic Fixed Capacitor

Managed by United States

NSN Created on 30 Apr 1969

Data Last Changed
November 2023

NATO Update Count
51

NATO Data Quality

5910-00-456-4474 CAPACITOR,FIXED,ELECTROLYTIC 5910004564474 004564474 1/3 — 5910-00-456-4474 Photo 1/3

AAQL Style 26B for 5910-00-456-4474 2/3 — NSN 5910-00-456-4474 (Identification) 2/3

AEBZ Style 1C for 5910-00-456-4474 3/3 — NSN 5910-00-456-4474 (Identification) 3/3

Marketplace 5910-00-456-4474

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

10-0082 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS

Subscribe to View Vendor Details...

100082 CAPACITOR,FIXED,ELECTROLYTIC 2 EA NS

Subscribe to View Vendor Details...

8412778-87 CAPACITOR,FIXED,ELECTROLYTIC 1 EA NS

100082 CAPACITOR,FIXED,ELECTROLYTIC 1 EA NS

Subscribe to View Vendor Details...

C41056 CAPACITOR,FIXED,ELECTROLYTIC 4 EA NS

150D105X9035A2 CAPACITOR,FIXED,ELECTROLYTIC 49 EA NS

Subscribe to View Vendor Details...

42.0001 CAPACITOR,FIXED,ELECTROLYTIC 334 EA NS

Subscribe to View Vendor Details...

150D105X9035A2 CAPACITOR,FIXED,ELECTROLYTIC 4580 EA NS

Subscribe to View Vendor Details...

150D105X9035A2 CAPACITOR,FIXED,ELECTROLYTIC 882 EA NS

Subscribe to View Vendor Details...

150D105X9035A2 CAPACITOR,FIXED,ELECTROLYTIC 4 EA NS

Subscribe to View Vendor Details...

150D105X9035A2 CAPACITOR,FIXED,ELECTROLYTIC 1 EA NS

Subscribe to View Vendor Details...

150D105X9035A2 CAPACITOR,FIXED,ELECTROLYTIC 8 EA NS

Updated Every Day

5910-00-456-4474 RQST NE

Updated Every Day

5910-00-456-4474 RQST

Updated Every Day

5910-00-456-4474 RQST NE

Restrictions 5910-00-456-4474

5910-00-456-4474 is a Electrolytic Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.

Import and Export 5910-00-456-4474

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5910-00-456-4474

Brazil (YA01)
Effective Date:: 1 Dec 2003

Spain (YB01)
Effective Date:: 1 Apr 1991

Columbia (YC01)
Effective Date:: 1 Jul 2015

Singapore (YJ01)
Effective Date:: 1 Apr 1991

Kuwait (YK01)
Effective Date:: 1 Jan 2015

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Portugal (ZP01)
Effective Date:: 1 Apr 1991

Italy (ZR01)
Effective Date:: 1 Apr 1991

Denmark (ZS01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Apr 1991

Turkey (ZW01)
Effective Date:: 1 Apr 1991

Approved Sources 5910-00-456-4474

Part Number
Manufacturer
Status
8412778-87: 11447 - L3 Technologies, Inc. (Active); Primary Buy; RNCC 3 RNVC 2 DAC 5
SA1NFT: 31550 - L3harris Technologies, Inc. (Active); Primary Buy; RNCC 3 RNVC 2 DAC 5
150D105X9035A2: 56289 - Sprague Electric Co World Hqs (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 3
K1J35KS: 05397 - Union Carbide Corp Materials Systems (Obsolete); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
TAS105K035P1A: 37942 - Yosemite Investment Inc (Active); Incomplete Secondary Reference; RNCC 5 RNVC 1 DAC 5
150D105X9035A2DYS: 56289 - Sprague Electric Co World Hqs (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4
02-030: 00816 - Palomar Products, Inc. (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
037-164: 0PN68 - Ampex Data Systems Corporation (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 5
100082: 52542 - Systron-Donner Corp (Obsolete); Secondary Buy; RNCC 5 RNVC 2 DAC 5
10047-723: 18192 - Cooper Crouse-Hinds, Llc (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
STA5185-1: 21520 - Fansteel Inc. (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
SCM105FP035D2: 96214 - Raytheon Company (Active); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
SNS105A035K1: 26769 - Sprague Palm Beach Inc (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
8412778-87: 49671 - Lockheed Martin Corporation (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 1
150D105X9035-2A: 56286 - Hewlett-Packard Co (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 4
0000037-164: 92739 - Ampex Systems Corp (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
037-164: 92739 - Ampex Systems Corp (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 6
SA1NFT: 28528 - Itt Industries Inc (Replaced); Canceled/Obsolete; RNCC 5 RNVC 9 DAC 5
420001: 33642 - Syqwest Llc (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
S30-1218: 54418 - Miltope Corporation (Active); Advisory Reference; RNCC C RNVC 1 DAC 5
C41056: 34764 - Scientific Radio Systems Inc (Obsolete); Advisory Reference; RNCC C RNVC 1 DAC 5
096-1005-00: 12115 - Drs Icas, Llc (Replaced); Advisory Reference; RNCC C RNVC 1 DAC 5
336948: 64959 - American Telephone And Telegraph Co (Replaced); Advisory Reference; RNCC C RNVC 1 DAC 5
SNS105A035ML: 12040 - National Semiconductor Corp (Obsolete); Advisory Reference; RNCC C RNVC 1 DAC 5

Datasheet 5910-00-456-4474

Characteristic
Specifications
FIIG: A010B0
Electrical Polarization [AECQ]: Polarized
Anode Type [AECE]: Solid
Body Diameter [ABPM]: 0.135 Inches Nominal
Body Length [ADAQ]: 0.322 Inches Nominal
Body Style [AAQL]: W/O Mtg Facilities, Axial Terminals
Capacitive Electrode Material [CWNJ]: Tantalum
Capacitance Value Per Section [CQBQ]: 1.000 Microfarads Single Section
Case Insulation Material [CWSZ]: Plastic
Case Material [CWJK]: Metal
Features Provided [CBBL]: Hermetically Sealed Case
Nonderated Operating Temp [CQJJ]: -80.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
Nonderated Continuous Voltage Rating And Type Per Section [CQWM]: 35.0 Dc Single Section
Reliability Indicator [AARG]: Not Established
Schematic Diagram Designator [AEBZ]: No Common Or Grounded Electrode(S)
Terminal Length [ABJT]: 1.500 Inches Nominal
Terminal Type And Quantity [TTQY]: 2 Uninsulated Wire Lead
Terminal Surface Treatment [CWSG]: Solder
Tolerance Range Per Section [CRTP]: -10.00/+10.00 Percent Single Section

Similar Supply Items to 5910-00-456-4474

Freight Information 5910-00-456-4474

5910-00-456-4474 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-456-4474 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-456-4474 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5910-00-456-4474 is not classified as a special type of cargo when transported by water. 5910-00-456-4474 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5910-00-456-4474

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"; 85 to 110G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: --; --; --; --; Physical Protection; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; No Requirement; No Requirement; Not Applicable; Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal; --

Intermediate Pack Level

Quantity of Unit Packs
Container: PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
