5910-00-262-0724
Electrolytic Fixed Capacitor
5910002620724 002620724 MIL-PRF-39006/19 9167411 XTH12E XTH12L M39006/19-1033 M39006-19-1013 MILC39006-19
A capacitor, whose capacitance value cannot be adjusted or varied, having a chemically formed film as the dielectric. It may be a single unit, or consist of two or more fixed units which cannot be separated. View more Electrolytic Fixed Capacitor
Managed by United States
NSN Created on 4 Jul 1973
Data Last Changed
November 2023
November 2023
NATO Update Count
32
32
NATO Data Quality
Marketplace 5910-00-262-0724
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-262-0724 5+ Documents (More...)
MIL-PRF-39006/19 9167411 XTH12E XTH12L M39006/19-1033 M39006-19-1013 MILC39006-19 A capacitor, whose
Photo 1/3 NSN 5910-00-262-0724 (Identification) 2/3 NSN 5910-00-262-0724 (Identification) 3/3 -
MILC39006-19 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS Request Quotation Updated Every Day 5910-00-262-0724
Photo 1/3 NSN 5910-00-262-0724 (Identification) 2/3 NSN 5910-00-262-0724 (Identification) 3/3 -
MILC39006-19 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS Request Quotation Updated Every Day 5910-00-262-0724
MILC39006-19 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS Request Quotation Updated Every Day 5910-00-167-0997
0997 Electrolytic Fixed Capacitor 5910001670997 https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-262-0724
Electrolytic Fixed Capacitor 5910002620724 Request Quotation Updated Every Day 5910-00-114 https
0997 Electrolytic Fixed Capacitor 5910001670997 https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-262-0724
Electrolytic Fixed Capacitor 5910002620724 Request Quotation Updated Every Day 5910-00-114 https
M39006-19-1013 A capacitor, whose capacitance value cannot be adjusted or varied, having a chemically
MILC39006-19 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS Request Quotation Updated Every Day 5910-00-137-0800
MILC39006-19 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS Request Quotation Updated Every Day 5910-00-114
MILC39006-19 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS Request Quotation Updated Every Day 5910-00-137-0800
MILC39006-19 CAPACITOR,FIXED,ELECTROLYTIC 3 EA NS Request Quotation Updated Every Day 5910-00-114
Items to 9999-22-604-3416 5910-99-955-8418 5910-00-049-0532 5910-01-239-1686 5910-01-271-0878 5910-00-262-0724
936-3304 5910-99-955-8418 5910-00-049-0532 5910-01-239-1686 5910-01-271-0878 5910-00-115-8148 5910-00-262-0724
Restrictions 5910-00-262-0724
5910-00-262-0724 is a Electrolytic Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5910-00-262-0724
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-262-0724
- US Army (A918)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- A196
- US Air Force (FXGX)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- FXTX
- US Marine Corps (MC49)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- MC13
- US Navy (N9BN)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HDKE
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5910-00-262-0724
- Part Number
- Manufacturer
- Status
- M39006/19-1033
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-39006/19
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MILC39006-19
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 9167411
- 18876 - Us Army Aviation And Missile Command (Active)
- Advisory Reference
- Advisory Reference
- XTH12E
- 37942 - Yosemite Investment Inc (Active)
- Advisory Reference
- Advisory Reference
- XTH12L
- 37942 - Yosemite Investment Inc (Active)
- Advisory Reference
- Advisory Reference
- M39006-19-1013
- 81349 - Military Specifications (Active)
- Transferred
- Transferred
Datasheet 5910-00-262-0724
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Electrical Polarization [AECQ]
- Polarized
- Anode Type [AECE]
- Solid
- Body Diameter [ABPM]
- 0.875 Inches Nominal
- Body Length [ADAQ]
- 2.420 Inches Nominal
- Body Style [AAQL]
- W/O Mtg Facilities, Terminal(S) On One End
- Capacitive Electrode Material [CWNJ]
- Tantalum
- Capacitance Value Per Section [CQBQ]
- 12.000 Microfarads Single Section
- Case Material [CWJK]
- Metal
- Dc Leakage At Maximum Operating Temp [CQLH]
- 144.0 Microamperes
- Dc Leakage At Reference Temp [CWQH]
- 18.000 Microamperes
- Dissipation Factor At Reference Temp In Percent [CWPM]
- 10.0000
- Features Provided [CBBL]
- Hermetically Sealed Case
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 360.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
- Impedance At Minimum Operating Temp In Ohms [AECN]
- 180.0
- Reliability Failure Rate Level In Percent [AARH]
- 1.0000
- Reliability Indicator [AARG]
- Established
- Schematic Diagram Designator [AEBZ]
- Electrode(S) Grounded To Case, W/Gnd Terminal
- Specification/Standard Data [ZZZK]
- 81349-Mil-C-39006/19 Government Specification
- Terminal Length [ABJT]
- 0.406 Inches Nominal
- Terminal Type And Quantity [TTQY]
- 1 Solder Stud And 1 Tab, Solder Lug
- Test Data Document [TEST]
- 81349-Mil-C-39006 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
- Tolerance Range Per Section [CRTP]
- -15.00/+75.00 Percent Single Section
DLA Procurement Analysis 5910-00-262-0724
- Last Stock Position:
- 8 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5910-00-262-0724
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Feb 2020
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2019
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5910-00-262-0724
Freight Information 5910-00-262-0724
5910-00-262-0724 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-262-0724 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-262-0724 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-00-262-0724 is not classified as a special type of cargo when transported by water. 5910-00-262-0724 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5910-00-262-0724
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- Special requirements
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 5910-00-262-0724 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
