5910-00-257-0588
Paper Dielectric Fixed Capacitor
5910002570588 002570588 91A12300 FRC-52
A capacitor whose capacitance value cannot be adjusted or varied, having paper as the dielectric material. It may be a single unit or consist of two or more fixed units which cannot be seperated. For items whose dielectric material consist of plasticized (plastic impregnated) paper or paper-plastic combinations, see CAPACITOR, FIXED, PLASTIC DIELECTRIC. For items whose electrodes consist of a metallic film deposited (metallized) on the dielectric material, see CAPACITOR, FIXED, METALIZED, PAPER-PLASTIC DIELECTRIC. View more Paper Dielectric Fixed Capacitor
May 2023
17
Marketplace 5910-00-257-0588
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-257-0588 4+ Documents (More...)
Photo 1/3 NSN 5910-00-257-0588 (Identification) 2/3 NSN 5910-00-257-0588 (Identification) 3/3 -
5910-00-257-0588 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-257-0588
Restrictions 5910-00-257-0588
5910-00-257-0588 is a Paper Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-257-0588
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-257-0588
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5910-00-257-0588
- Part Number
- Manufacturer
- Status
- 91A12300
- Manufacturer
- 23040 - Ford Motor Co Ford Parts And Service (Replaced)
- Original Design
- Original Design
- 91A12300
- 57526 - Ford Motor Company (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- FRC-52
- 73961 - Guaranteed Parts Co Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-00-257-0588
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.672 Inches Nominal
- Body Height [ADAU]
- 0.672 Inches Nominal
- Body Length [ADAQ]
- 1.375 Inches Nominal
- Body Style [AAQL]
- W/Mtg Bracket, Terminal(S) On One End
- Case Material [CWJK]
- Metal
- Features Provided [CBBL]
- Hermetically Sealed Case
- Capacitance Value Per Section [CQBQ]
- 0.290 Microfarads Single Section
- Mounting Facility Type And Quantity [AXHR]
- 1 Unthreaded Mounting Holes
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 300.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- Electrode(S) Grounded To Case
- Unthreaded Mounting Hole Diameter [AEBV]
- 0.203 Inches Nominal
- Terminal Length [ABJT]
- 2.125 Inches Nominal
- Terminal Type And Quantity [TTQY]
- 1 Insulated Wire Lead W/Terminal Lug
- Tolerance Range Per Section [CRTP]
- -0.00 To 30000.00 Picofarads Single Section
Similar Supply Items to 5910-00-257-0588
Freight Information 5910-00-257-0588
5910-00-257-0588 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-257-0588 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-257-0588 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 723 for ocean manifesting and military sealift. 5910-00-257-0588 is not classified as a special type of cargo when transported by water. 5910-00-257-0588 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5910-00-257-0588
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- --
- A-A-1507, Chipboard Sheet used as a Stiffener on One Side of Item
- --
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
