5910-00-192-2111
Ceramic Dielectric Fixed Capacitor
5910001922111 001922111 K34J238REV6PT151
A capacitor, whose capacitance value cannot be adjusted or varied, having a ceramic dielectric.It may be a single unit, or consist of two or more fixed units which cannot be separated. View more Ceramic Dielectric Fixed Capacitor
May 2023
12
Marketplace 5910-00-192-2111
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-192-2111 2+ Documents (More...)
Ceramic Dielectric Fixed Capacitor 001922111 Photo 1/3 NSN 5910-00-192-2111 (Identification) 2/3 NSN
5910-00-192-2111 (Identification) 3/3 - RQST NE Updated Every Day 5910-00-192-2111 RQST Updated Every
Restrictions 5910-00-192-2111
5910-00-192-2111 is a Ceramic Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-192-2111
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-192-2111
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 5910-00-192-2111
- Part Number
- Manufacturer
- Status
- K34J238REV6PT151
- Manufacturer
- 24446 - General Electric Company (Active)
- Primary Buy
- Primary Buy
Datasheet 5910-00-192-2111
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.240 Inches Nominal
- Body Length [ADAQ]
- 0.460 Inches Nominal
- Body Style [AAQL]
- W/O Mtg Facilities, Radial Terminals
- Capacitance Value Per Section [CQBQ]
- 47.000 Picofarads Single Section
- Case Material [CWJK]
- Ceramic
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 500.0 Dc Single Section
- Temp Coefficient Of Capacitance Per Section In Ppm Per Deg Celsius [CQLZ]
- 0.0 Single Section
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
- Tolerance Range Per Section [CRTP]
- -5.00/+5.00 Percent Single Section
- Tolerance Of Temp Coefficient Per Section In Ppm Per Deg Celsius [CRHD]
- -30.0/+30.0 Single Section
Similar Supply Items to 5910-00-192-2111
Freight Information 5910-00-192-2111
5910-00-192-2111 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-192-2111 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5910-00-192-2111 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-192-2111 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5910-00-192-2111 is not classified as a special type of cargo when transported by water. 5910-00-192-2111 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
