5910-00-186-7252
Air Dielectric Variable Capacitor
5910001867252 001867252 B7389D B7389
A capacitor whose capacitance value is controlled by a mechanical means which effects a continuous variation of its capacitance. It includes items consisting of two or more variable capacitors which are inseparable. View more Air Dielectric Variable Capacitor
May 2023
17
Marketplace 5910-00-186-7252
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-186-7252 5+ Documents (More...)
United States (US) 4. 5910-00-186-7252 Marketplace Restrictions Approved Sources Datasheet Management
RQST NE Updated Every Day 5910-00-186-7252 RQST Updated Every Day 5910-00-186-7252 RQST NE Related Documents
www.nsnlookup.com /fsg-53/fsc-5315/be 5315-13-110-2541 Headless Straight Pin 5315131102541131102541 B7389
Air Dielectric Variable Capacitor 001867252 your Account Upgrade 5910-00-186-7252Air Dielectric
ITEM 3 B7389/3 Managed by United Kingdom NSN Created on 28 Mar 1992 Data Last Changed January 2023 NATO
NumberManufacturerStatusB7389 ITEM 3 K0107 - Mactaggart Scott & Co Ltd (Active) Primary Buy RNCC 3 RNVC 2 DAC 2 B7389
Restrictions 5910-00-186-7252
5910-00-186-7252 is a Air Dielectric Variable Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-186-7252
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-186-7252
- US Navy (N9BN)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- Brazil (YA01)
- Effective Date:
- 1 Dec 1999
Approved Sources 5910-00-186-7252
- Part Number
- Manufacturer
- Status
- B7389D
- Manufacturer
- 26548 - Bae Systems Technology Solutions & (Obsolete)
- Original Design
- Original Design
- B7389
- 26548 - Bae Systems Technology Solutions & (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-00-186-7252
- Characteristic
- Specifications
- FIIG
- Specifications
- A096A0
- Adjustment Device Drive Type And Quantity [CTGR]
- 1 Shaft
- Adjustment Device Rotation [AXGJ]
- 180.0 Degrees Nominal Clockwise And 180.0 Degrees Nominal Counterclockwise
- Capacitance Range In Picofarads [CTGN]
- +16.0/+168.0 All Sections
- Nonderated Voltage Rating And Type [CTGP]
- 1100.0 Ac Peak All Sections
- Individual Section Quantity [AFBH]
- 2
- Inclosure Type [AKNA]
- Uninclosed
- Shaft Diameter [ABWV]
- 0.250 Inches Nominal Single Shaft
- Shaft Length [ABXF]
- 0.469 Inches Nominal Single Shaft
- Shaft Type [CRSJ]
- Round Single Shaft
- Overall Length [ABHP]
- 3.719 Inches Nominal
- Tuning Characteristic [AXCM]
- Straight Line Capacity All Sections
- Terminal Type And Quantity [TTQY]
- 4 Threaded Stud
DLA Procurement Analysis 5910-00-186-7252
Management Data 5910-00-186-7252
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5910-00-186-7252
Freight Information 5910-00-186-7252
5910-00-186-7252 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-186-7252 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-186-7252 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-00-186-7252 is not classified as a special type of cargo when transported by water. 5910-00-186-7252 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5910-00-186-7252
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-DTL-17667, Neutral Wrapping Paper
- ASTM-D4727, Fiberboard used as Pads, Cells, Die-cuts or Sleeves
- --
- PPP-B-566 or PPP-B-676, Folding or Setup Box
- Special requirements
- MIL-DTL-17667, Neutral Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 5910-00-186-7252 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Z
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
