5910-00-165-2730
Plastic Dielectric Fixed Capacitor
5910001652730 001652730 4SES47 89P47394 250D1E473J6 89P47304 251D1E473J6
A capacitor whose capacitance value cannot be adjusted or varied, having a plastic, plastic film, plasticized (plastic impregnated) paper, or any combination of plastic and paper or plastic and paper films as the dielectric material. The plastic may be one or more types of synthetic compounds such as polyesters, polyfluorides, polycabonates, and the like. It may be a single unit, or consist of two or more fixed units which cannot be separated. For items whose electrodes consist of a metallic film deposited (metallized) on the dielectric material, see CAPACITOR, FIXED, METALLIZED, PAPER-PLASTIC DIELECTRIC. View more Plastic Dielectric Fixed Capacitor
May 2023
18
Marketplace 5910-00-165-2730
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-165-2730 5+ Documents (More...)
Photo 1/3 NSN 5910-00-165-2730 (Identification) 2/3 NSN 5910-00-165-2730 (Identification) 3/3 -
RQST NE Updated Every Day 5910-00-165-2730 RQST Updated Every Day 5910-00-165-2730 RQST NE Related Documents
Updated Every Day 5910-00-797-3856 RQST Updated Every https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-165-2730
Plastic Dielectric Fixed Capacitor 001652730 00-165-2730Plastic Dielectric Fixed Capacitor5910001652730
Plastic Dielectric Fixed Capacitor 001652730 2730Plastic Dielectric Fixed Capacitor5910001652730
Navy (DN)NZDiscontinued-Use 5910-00-165-2730Defense Logistics Agency (DS)IZDiscontinued-Use 5910-00-165-2730
Restrictions 5910-00-165-2730
5910-00-165-2730 is a Plastic Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-165-2730
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-165-2730
- US Marine Corps (MC49)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- MC13
- US Navy (N9BN)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HDHH
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Mar 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5910-00-165-2730
- Part Number
- Manufacturer
- Status
- 250D1E473J6
- Manufacturer
- 14752 - Electrocube, Inc. (Active)
- Primary Buy
- Primary Buy
- 89P47304
- 56289 - Sprague Electric Co World Hqs (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 251D1E473J6
- 14752 - Electrocube, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 4SES47
- 56289 - Sprague Electric Co World Hqs (Active)
- Advisory Reference
- Advisory Reference
- 89P47394
- 56289 - Sprague Electric Co World Hqs (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5910-00-165-2730
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.320 Inches Nominal
- Body Length [ADAQ]
- 0.950 Inches Nominal
- Body Style [AAQL]
- W/O Mtg Facilities, Axial Terminals
- Capacitance Value Per Section [CQBQ]
- 47000.000 Picofarads Single Section
- Case Material [CWJK]
- Plastic
- Dielectric Material [CWSS]
- Plastic
- Dissipation Factor At Reference Temp In Percent [CWPM]
- 0.500
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 400.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
- Insulation Resistance At Maximum Operating Temp [CQBF]
- 4000.0 Megohm-Microfarads
- Insulation Resistance At Reference Temp [CWPK]
- 40000.0 Megohm-Microfarads
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Terminal Diameter [AEBT]
- 0.025 Inches Nominal
- Terminal Length [ABJT]
- 2.000 Inches Nominal
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
- Terminal Surface Treatment [CWSG]
- Solder
- Tolerance Range Per Section [CRTP]
- -5.00/+5.00 Percent Single Section
Weapon Systems (WSDC) 5910-00-165-2730
DLA Procurement Analysis 5910-00-165-2730
Management Data 5910-00-165-2730
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 5
- Critical Repair Part to a Combat Essential End Item
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5910-00-165-2730
Freight Information 5910-00-165-2730
5910-00-165-2730 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-165-2730 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-165-2730 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-00-165-2730 is not classified as a special type of cargo when transported by water. 5910-00-165-2730 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5910-00-165-2730
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- Special requirements
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 5910-00-165-2730 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Y
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
