5910-00-122-3438
Paper Dielectric Fixed Capacitor
5910001223438 001223438 350A970G22 45F272
A capacitor whose capacitance value cannot be adjusted or varied, having paper as the dielectric material. It may be a single unit or consist of two or more fixed units which cannot be seperated. For items whose dielectric material consist of plasticized (plastic impregnated) paper or paper-plastic combinations, see CAPACITOR, FIXED, PLASTIC DIELECTRIC. For items whose electrodes consist of a metallic film deposited (metallized) on the dielectric material, see CAPACITOR, FIXED, METALIZED, PAPER-PLASTIC DIELECTRIC. View more Paper Dielectric Fixed Capacitor
May 2023
10
Marketplace 5910-00-122-3438
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-122-3438 5+ Documents (More...)
Photo 1/3 NSN 5910-00-122-3438 (Identification) 2/3 NSN 5910-00-122-3438 (Identification) 3/3 -
5910-00-122-3438 4+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-122-3438
0011Paper Dielectric Fixed Capacitor5910996360011 https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-122-3438
Paper Dielectric Fixed Capacitor 001223438 Day 5910-00-122-3438 RQST NE Related Documents https
Request a Quotation from participating marketplace vendors Request Subscribe to View Vendor Details... 45F272
Quotation Updated Every Day 5910-01-071-0273 RQST NE https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-122-3438
Marketplace Restrictions Approved Sources Datasheet https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-122-3438
Paper Dielectric Fixed Capacitor 001223438 www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-122-3438
Restrictions 5910-00-122-3438
5910-00-122-3438 is a Paper Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item has been determined to be hazardous and information is contained in the Hazardous Materials Information Resource System (HMIRS). This item does not contain a precious metal.
Import and Export 5910-00-122-3438
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-122-3438
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Mar 1997
Approved Sources 5910-00-122-3438
- Part Number
- Manufacturer
- Status
- 350A970G22
- Manufacturer
- 79500 - Westinghouse Electric Corp (Active)
- Primary Buy
- Primary Buy
- 45F272
- 01002 - General Electric Co Capacitors Div (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-00-122-3438
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Height [ADAU]
- 2.000 Inches Minimum And 2.180 Inches Maximum
- Body Length [ADAQ]
- 2.130 Inches Minimum And 2.190 Inches Maximum
- Body Style [AAQL]
- W/O Mtg Facilities, Terminal(S) On One Surface
- Body Width [ADAT]
- 1.250 Inches Minimum And 1.370 Inches Maximum
- Case Material [CWJK]
- Metal
- Center To Center Distance Between Terminals Parallel To Length [AEBP]
- 0.780 Inches Minimum And 0.840 Inches Maximum
- Features Provided [CBBL]
- Hermetically Sealed Case
- Capacitance Value Per Section [CQBQ]
- 4.000 Microfarads Single Section
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 370.0 Ac-Rms Single Section
- Nonderated Operating Temp [CQJJ]
- -30.0 Deg Celsius Minimum And 70.0 Deg Celsius Maximum
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Terminal Length [ABJT]
- 0.400 Inches Minimum And 0.520 Inches Maximum
- Terminal Type And Quantity [TTQY]
- 2 Quick Disconnect, Male, Double Blade
- Terminal Surface Treatment [CWSG]
- Solder
- Tolerance Range Per Section [CRTP]
- -10.00 To 10.00 Percent Single Section
DLA Procurement Analysis 5910-00-122-3438
Management Data 5910-00-122-3438
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Feb 2013
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Defense Logistics Agency (DS)
- I
- V
- Discontinued W/O Replacement
- V
Similar Supply Items to 5910-00-122-3438
Freight Information 5910-00-122-3438
5910-00-122-3438 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-122-3438 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-122-3438 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5910-00-122-3438 is not classified as a special type of cargo when transported by water. 5910-00-122-3438 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5910-00-122-3438
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- --
- --
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
- Special requirements
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 5910-00-122-3438 October 2021
Criticality and Quality
- Critical Item Code:
- X
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
