5910-00-107-0758
Ceramic Dielectric Fixed Capacitor
5910001070758 001070758 C0004
A capacitor, whose capacitance value cannot be adjusted or varied, having a ceramic dielectric.It may be a single unit, or consist of two or more fixed units which cannot be separated. View more Ceramic Dielectric Fixed Capacitor
May 2023
12
Marketplace 5910-00-107-0758
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-107-0758 5+ Documents (More...)
5910-00-107-0758 5+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-107-0758
Ceramic Dielectric Fixed Capacitor 001070758 Photo 1/3 NSN 5910-00-107-0758 (Identification) 2/3 NSN
-001 (Active) Primary Buy RNCC 3 RNVC 2 DAC 6 EE-C0004 https//www.nsnlookup.com /fsg-59/fsc-5945/de
Ceramic Dielectric Fixed Capacitor 001070758 Upgrade your Account Upgrade 5910-00-107-0758Ceramic
/fsc-5945/de 5945-12-360-1702 Electromagnetic Relay 5945123601702123601702 VG96928T10F1A0A0AV23234-C0004
web browser . 5945-12-360-1702Electromagnetic Relay5945123601702 123601702VG96928T10F1A0A0A V23234-C0004
013640150 EE-C0004 -001 90A772EE-C0004 -001 https//www.nsnlookup.com /fsg-59 https//www.nsnlookup.com
-001 90A772EE-C0004 -001 https//www.nsnlookup.com /fsg-59/ https//www.nsnlookup.com /fsg-41/fsc-4130/
-001 A device for reducing 5985 - -0889Variable Attenuator5985011250889 01125088990A772EE-C0004 -001
Attenuator5985013640150 013640150 EE-C0004 -001 90A772EE-C0004 -001 https https//www.nsnlookup.com /
Restrictions 5910-00-107-0758
5910-00-107-0758 is a Ceramic Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5910-00-107-0758
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-107-0758
- US Air Force (FXGX)
- Effective Date:
- 1 Jun 2006
- Former MOE Rule:
- FXTX
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5910-00-107-0758
- Part Number
- Manufacturer
- Status
- C0004
- Manufacturer
- 14304 - L3harris Technologies, Inc. (Active)
- Primary Buy
- Primary Buy
Datasheet 5910-00-107-0758
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.760 Inches Nominal
- Body Length [ADAQ]
- 0.250 Inches Maximum
- Body Style [AAQL]
- W/O Mtg Facilities, Radial Terminals
- Capacitance Value Per Section [CQBQ]
- 0.020 Microfarads Single Section
- Case Material [CWJK]
- Plastic
- Center To Center Distance Between Terminals Parallel To Diameter [AEBS]
- 0.313 Inches Minimum And 0.437 Inches Maximum
- Dissipation Factor At Reference Temp In Percent [CWPM]
- 2.000
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 500.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- 10.0 Deg Celsius Minimum And 85.0 Deg Celsius Maximum
- Insulation Resistance At Reference Temp [CWPK]
- 10000.0 Megohms
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Voltage Temp Limits Per Section In Percent Capacitance Change [CQFB]
- -56.0/+22.0 Without Voltage Applied Single Section
- Terminal Diameter [AEBT]
- 0.025 Inches Nominal
- Terminal Length [ABJT]
- 1.764 Inches Nominal
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
- Terminal Surface Treatment [CWSG]
- Solder
- Tolerance Range Per Section [CRTP]
- -20.00/+20.00 Percent Single Section
DLA Procurement Analysis 5910-00-107-0758
Management Data 5910-00-107-0758
Similar Supply Items to 5910-00-107-0758
Freight Information 5910-00-107-0758
5910-00-107-0758 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-107-0758 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-107-0758 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5910-00-107-0758 is not classified as a special type of cargo when transported by water. 5910-00-107-0758 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
