5910-00-100-8059
Mica Dielectric Fixed Capacitor
5910001008059 001008059 MIL-C-5/4 1417 CM30B332K MILC5 P727865-159 H004-0521024 B57111-3 521024 0162-8
A capacitor, whose capacitance value cannot be adjusted or varied, having natural sheet mica or reconstituted flaked mica formed into sheets as the dielectric material. It may be a single unit, or consist of two or more fixed units which cannot be separated. View more Mica Dielectric Fixed Capacitor
May 2023
36
Marketplace 5910-00-100-8059
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-100-8059 5+ Documents (More...)
Photo 1/4 5910-00-100-8059 Photo 2/4 NSN 5910-00-100-8059 (Identification) 3/4 NSN 5910-00-100-
NE Updated Every Day 5910-00-100-8059 RQST Updated Every Day 5910-00-100-8059 RQST NE Related Documents
,FIXED,MICA DIELECTRIC 20 EA NS Request Quotation Subscribe to View Vendor Details... 1417 CAPACITOR,
141-7 CAPACITOR,FIXED,MICA DIELECTRIC 5 EA NS Request Quotation Subscribe to View Vendor Details... 1417
5910-00-841-8300 RQST NE Related Documents https/ https//www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-100-8059
Mica Dielectric Fixed Capacitor 001008059 Account Upgrade 5910-00-100-8059Mica Dielectric Fixed
Restrictions 5910-00-100-8059
5910-00-100-8059 is a Mica Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-100-8059
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-100-8059
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Brazil (YA01)
- Effective Date:
- 1 Nov 2008
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Nov 2011
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- United Kingdom (ZK01)
- Effective Date:
- 1 Jul 2004
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5910-00-100-8059
- Part Number
- Manufacturer
- Status
- CM30B332K
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-C-5/4
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- 1417
- 06141 - L3 Aviation Products, Inc. (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- MILC5
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- P727865-159
- 49671 - Lockheed Martin Corporation (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- H004-0521024
- 00000 - Ordnance Corps (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- P727865-159
- 21921 - Rca Corp Distributor And Special (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- B57111-3
- 93241 - Electronic Development Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 521024
- 00000 - Ordnance Corps (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 0162-8
- 56232 - Lockheed Martin Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-00-100-8059
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Height [ADAU]
- 0.828 Inches Nominal
- Body Length [ADAQ]
- 0.828 Inches Nominal
- Body Width [ADAT]
- 0.281 Inches Nominal
- Body Style [AAQL]
- W/O Mtg Facilities, Terminals On Opposite Surfaces
- Capacitance Value Per Section [CQBQ]
- 3300.000 Picofarads Single Section
- Case Material [CWJK]
- Plastic
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 500.0 Dc Single Section
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
- Tolerance Range Per Section [CRTP]
- -10.00 To 10.00 Percent Single Section
Similar Supply Items to 5910-00-100-8059
Freight Information 5910-00-100-8059
5910-00-100-8059 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-100-8059 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5910-00-100-8059 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-100-8059 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5910-00-100-8059 is not classified as a special type of cargo when transported by water. 5910-00-100-8059 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
