5910-00-080-0291
Mica Dielectric Fixed Capacitor
5910000800291 000800291 912-3857-00 2088537-0226 2088537-226 10205-0226 DM10E470G DM10E470G0500WV4CR
A capacitor, whose capacitance value cannot be adjusted or varied, having natural sheet mica or reconstituted flaked mica formed into sheets as the dielectric material. It may be a single unit, or consist of two or more fixed units which cannot be separated. View more Mica Dielectric Fixed Capacitor
May 2023
25
Marketplace 5910-00-080-0291
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-080-0291 5+ Documents (More...)
Photo 1/3 NSN 5910-00-080-0291 (Identification) 2/3 NSN 5910-00-080-0291 (Identification) 3/3 -
NE Updated Every Day 5910-00-080-0291 RQST Updated Every Day 5910-00-080-0291 RQST NE Related Documents
Mica Dielectric Fixed Capacitor 000800291 www.nsnlookup.com /fsg-59/fsc-5910/us 5910-00-080-0291
Mica Dielectric Fixed Capacitor 000800291 912-3857-002088537 https//www.nsnlookup.com /fsg-59/fsc-5910
Restrictions 5910-00-080-0291
5910-00-080-0291 is a Mica Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-080-0291
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-080-0291
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 Apr 1991
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5910-00-080-0291
- Part Number
- Manufacturer
- Status
- 912-3857-00
- Manufacturer
- 13499 - Rockwell Collins, Inc. (Active)
- Primary Buy
- Primary Buy
- 2088537-0226
- 27914 - Honeywell International Inc (Active)
- Primary Buy
- Primary Buy
- 2088537-226
- 27914 - Honeywell International Inc (Active)
- Secondary Buy
- Secondary Buy
- 10205-0226
- 27914 - Honeywell International Inc (Active)
- Secondary Buy
- Secondary Buy
- DM10E470G
- 72136 - Electro Motive Corp Subsidiary Of (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- DM10E470G0500WV4CR
- 72136 - Electro Motive Corp Subsidiary Of (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-00-080-0291
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Height [ADAU]
- 0.190 Inches Maximum
- Body Length [ADAQ]
- 0.370 Inches Maximum
- Body Style [AAQL]
- W/O Mtg Facilities Terminal(S) On One Surface
- Body Width [ADAT]
- 0.340 Inches Maximum
- Capacitance Value Per Section [CQBQ]
- 47.000 Picofarads Single Section
- Case Material [CWJK]
- Plastic
- Center To Center Distance Between Terminals Parallel To Length [AEBP]
- 0.110 Inches Minimum And 0.172 Inches Maximum
- Dissipation Factor At Reference Temp In Percent [CWPM]
- 0.0010
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 500.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- -55.0 Deg Celsius Minimum And 125.0 Deg Celsius Maximum
- Insulation Resistance At Maximum Operating Temp [CQBF]
- 20000.0 Megohms
- Terminal Surface Treatment [CWSG]
- Solder
- Insulation Resistance At Reference Temp [CWPK]
- 100000.0 Megohms
- Quality Factor At Reference Temp [CWQF]
- 2000.0000
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Tolerance Range Per Section [CRTP]
- -2.00 To 2.00 Percent Single Section
- Temp Coefficient Of Capacitance Range Per Section In Ppm Per Deg Celsius [CRDN]
- -20.0 To 100.0 Single Section
- Terminal Length [ABJT]
- 1.250 Inches Minimum
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
Similar Supply Items to 5910-00-080-0291
Freight Information 5910-00-080-0291
5910-00-080-0291 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061400. A Sub NMFC of X. It has a NMFC Description of CONDENSERS/PARTS NOI/CAPACITORS. 5910-00-080-0291 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5910-00-080-0291 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 34450 which rates the freight between FCL and LCL. 5910-00-080-0291 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5910-00-080-0291 is not classified as a special type of cargo when transported by water. 5910-00-080-0291 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
