5910-00-072-8527
Paper Dielectric Fixed Capacitor
5910000728527 000728527 1681823-1 VJS502G20
A capacitor whose capacitance value cannot be adjusted or varied, having paper as the dielectric material. It may be a single unit or consist of two or more fixed units which cannot be seperated. For items whose dielectric material consist of plasticized (plastic impregnated) paper or paper-plastic combinations, see CAPACITOR, FIXED, PLASTIC DIELECTRIC. For items whose electrodes consist of a metallic film deposited (metallized) on the dielectric material, see CAPACITOR, FIXED, METALIZED, PAPER-PLASTIC DIELECTRIC. View more Paper Dielectric Fixed Capacitor
May 2023
13
Marketplace 5910-00-072-8527
Request a Quotation from participating marketplace vendors
Related Documents 5910-00-072-8527 3+ Documents (More...)
Photo 1/6 5910-00-072-8527 Photo 2/6 5910-00-072-8527 Photo 3/6 5910-00-072-8527 Photo 4/6 NSN
5910-00-072-8527 (Identification) 5/6 NSN 5910-00-072-8527 (Identification) 6/6 - - - - - - 1.
Restrictions 5910-00-072-8527
5910-00-072-8527 is a Paper Dielectric Fixed Capacitor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. The precious metals content of this item is unknown.
Import and Export 5910-00-072-8527
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5910-00-072-8527
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5910-00-072-8527
- Part Number
- Manufacturer
- Status
- 1681823-1
- Manufacturer
- 10001 - Navair And Navsea Managed Original (Active)
- Primary Buy
- Primary Buy
- 1681823-1
- 03538 - Lockheed Martin Corporation (Active)
- Incomplete Secondary Reference
- Incomplete Secondary Reference
- VJS502G20
- 01854 - Thornton-Fuller Co (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5910-00-072-8527
- Characteristic
- Specifications
- FIIG
- Specifications
- A010B0
- Body Diameter [ABPM]
- 0.656 Inches Maximum
- Body Height [ADAU]
- 0.656 Inches Nominal
- Body Length [ADAQ]
- 1.250 Inches Maximum
- Body Style [AAQL]
- W/O Mtg Facilities, Axial Terminals
- Body Width [ADAT]
- 0.656 Inches Nominal
- Case Insulation Material [CWSZ]
- Plastic
- Case Material [CWJK]
- Plastic
- Capacitance Value Per Section [CQBQ]
- 5000.000 Picofarads Single Section
- Nonderated Continuous Voltage Rating And Type Per Section [CQWM]
- 2000.0 Dc Single Section
- Nonderated Operating Temp [CQJJ]
- 0.0 Deg Celsius Minimum And 160.0 Deg Celsius Maximum
- Terminal Surface Treatment [CWSG]
- Solder
- Insulation Resistance At Reference Temp [CWPK]
- 50.0 Megohms
- Reliability Indicator [AARG]
- Not Established
- Schematic Diagram Designator [AEBZ]
- No Common Or Grounded Electrode(S)
- Terminal Diameter [AEBT]
- 0.032 Inches Nominal
- Terminal Length [ABJT]
- 2.000 Inches Minimum And 2.500 Inches Maximum
- Terminal Type And Quantity [TTQY]
- 2 Uninsulated Wire Lead
- Tolerance Range Per Section [CRTP]
- -2.00 To 2.00 Percent Single Section
Similar Supply Items to 5910-00-072-8527
Freight Information 5910-00-072-8527
5910-00-072-8527 has freight characteristics.. 5910-00-072-8527 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
Packaging Data 5910-00-072-8527
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- --
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-P-130, Laminated and Creped Wrapping Paper
- No Requirement
- Not Applicable
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- --
- MIL-P-130, Laminated and Creped Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
