5905-01-649-7376
Precision Nonwire Wound Variable Resistor
5905016497376 016497376 RH0253K000F
A resistor in which a sliding or rolling contact moves over an exposed area of the resistive element to change the ohmic value of the output. The finctional tolerance (linearity) of the output is equal to or less than plus or minus 1 percent on linear outputs. Specified outputs such as sine, cosine, tangent, etc., shall be considered to be precision. For items having manually postioned taps designed to be set and fixed prior to use, see RESISTOR, ADJUSTABLE. For items with step by step variation, see REHOSTAT and RESISTOR, STEP BY STEP. For tandem-mounted items designed to function together as an attenuator (and rated accordingly), see ATTENUATOR, VARIABLE. Excludes RESISTOR (1), VARIABLE, WIRE WOUND, NONPRECISION; RESISTOR (1), VARIABLE NONWIRE WOUND, NONPRECISION; and RESISTOR (1), VARIABLE, WIRE WOUND, PRECISION. View more Precision Nonwire Wound Variable Resistor
January 2023
2
Marketplace 5905-01-649-7376
Request a Quotation from participating marketplace vendors
Related Documents 5905-01-649-7376 1+ Documents (More...)
5905-01-649-7376 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5905/us 5905-01-649-7376
/fsg-59/fsc-5905/us 5905-01-649-7376 RQST NE Updated Every Day 5905-01-649-7376 RQST Updated Every Day
Restrictions 5905-01-649-7376
5905-01-649-7376 is a Precision Nonwire Wound Variable Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5905-01-649-7376
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-01-649-7376
- Republic of Korea (ZH01)
- Effective Date:
- 1 Nov 2015
Approved Sources 5905-01-649-7376
- Part Number
- Manufacturer
- Status
- RH0253K000F
- Manufacturer
- 09969 - Vishay Dale Electronics, Inc. (Active)
- Primary Buy
- Primary Buy
Datasheet 5905-01-649-7376
- Characteristic
- Specifications
- FIIG
- Specifications
- A002A0
- Distance Between Mounting Hole Centers [AFQM]
- 0.714 Inches Minimum And 0.724 Inches Maximum
- Electrical Resistance Per Section [CQCC]
- 3000.0 Ohms All Sections
- Body Length [ADAQ]
- 1.031 Inches Minimum And 1.093 Inches Maximum
- Body Style [AAQL]
- Rectangular W/Mounting Tabs/Flanges
- Body Width [ADAT]
- 0.535 Inches Minimum And 0.565 Inches Maximum
- Lateral Distance Between Mounting Hole Centers [AGTP]
- 0.714 Inches Minimum And 0.724 Inches Maximum
- Reliability Indicator [AARG]
- Established
- Reliability Failure Rate Level In Percent [AARH]
- 1.0
- Resistance Tolerance Per Section In Percent [CRSS]
- -1.0 To 1.0 All Sections
- Special Features [FEAT]
- Rohs Compliant
- Terminal Type And Quantity [TTQY]
- 2 Screw Base
NATO Stock Numbers Related to 5905-01-649-7376
Freight Information 5905-01-649-7376
5905-01-649-7376 has freight characteristics managed by the Republic of Korea.. 5905-01-649-7376 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
