5905-01-452-5008
Precision Wire Wound Variable Resistor
5905014525008 014525008 3415S-1-102 400-7968
A resistor in which a sliding or rolling contact moves over an exposed area of the resistive element to change the ohmic value of the output. The functional tolerance (linearity) of the output is equal to or less than plus or munus 1 percent on linear outputs. Specified outputs such as sine, cosine, tangent, etc., shall be considered to be precision. For items having manually positioned taps designed to be set and fixed prior to use, see RESISTOR, ADJUSTABLE, For items with step by step variation, see RHEOSTAT and RESISTOR, STEP BY STEP. For tandem-mounted items designed to function together as an attenuator (and rated accordingly), see ATTENUATOR, VARIABLE. Excludes RESISTOR (1), VARIABLE, NONWIRE WOUND, NONPRECISION; RESISTOR (1), VARIABLE, NONWIRE WOUND, PRECISION; and RESISTOR (1), VARIABLE, WIRE WOUND, NONPRECISION. View more Precision Wire Wound Variable Resistor
May 2023
4
Marketplace 5905-01-452-5008
Request a Quotation from participating marketplace vendors
Related Documents 5905-01-452-5008 5+ Documents (More...)
/fsg-59/fsc-5905/us
Photo 1/5 5905-01-452-5008 Photo 2/5 5905-01-452-5008 Photo 3/5 NSN 5905-01-452-5008 (Identification
Photo 2/5 5905-01-452-5008 Photo 3/5 NSN 5905-01-452-5008 (Identification Photo 2/5 5905-01-452
RQST Updated Every Day 3610-00-400-7968 RQST NE Related Documents 3610-00-400-7968 2+ Documents ( More
/us 3610-00-400-7968 3610004007968004007968 United States (US) 4. 3610-00-400-7968 Marketplace Restrictions
Request a Quotation from participating marketplace vendors Request Related Documents 7642-01-400-7968
Precision Wire Wound Variable Resistor Restrictions 3610-00-400-7968 DEMIL: A | DEMILI : | https
Request a Quotation from participating marketplace vendors Request Related Documents 2920-99-400-7968
vendors Request Updated Every Day 3610-00-400-7968 https//www.nsnlookup.com /fsg-29/fsc-2920/uk 2920
RQST NE Updated Every Day 5305-14-400-7968 RQST Updated Every Day 5305-14-400-7968 RQST NE Related Documents
5305-14-400-7968 2+ Documents ( More... ) https//www.nsnlookup.com /fsg-53/fsc-5305/fr 5305-14-400-7968
Restrictions 5905-01-452-5008
5905-01-452-5008 is a Precision Wire Wound Variable Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item contains gold.
Import and Export 5905-01-452-5008
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-01-452-5008
- Finland (WF01)
- Effective Date:
- 1 Feb 2012
- United Kingdom (ZK01)
- Effective Date:
- 1 Jan 1998
Approved Sources 5905-01-452-5008
- Part Number
- Manufacturer
- Status
- 3415S-1-102
- Manufacturer
- 80294 - Bourns Instruments Inc (Obsolete)
- Original Design
- Original Design
- 400-7968
- A486G - Nimikkeistokeskus Ncb Finland (Active)
- NATO Reference
- NATO Reference
Datasheet 5905-01-452-5008
- Characteristic
- Specifications
- FIIG
- Specifications
- A002A0
- Effective Electrical Rotation In Deg Angular Rotation [AEFH]
- 350.0 Nominal
- Electrical Resistance Per Section [CQCC]
- 1000.0 Ohms C And Better Flooring
- Actuator Travel Control Feature [CRSX]
- Continuous Motion
- Actuator Type [AEFD]
- Single Shaft
- Ambient Temp In Deg Celsius Per Section At Full Rated Power [CSDH]
- 70.0 Single Section
- Ambient Temp In Deg Celsius Per Section At Zero Percent Rated Power [CQGN]
- 125.0 Single Section
- Body Diameter [ABPM]
- 50.8 Major Inches
- Body Length [ADAQ]
- 21.4 Millimeters Nominal
- Body Style [AAQL]
- Cylindrical Bushing Mounted
- Features Provided [CBBL]
- Humidity Proof
- Function Characteristic Per Section [CSBX]
- 7 Oclock All Primaries
- Function Conformity Per Section [CRGM]
- Single Section Independent Linearity
- Function Conformity Tolerance Per Section [CQFL]
- -0.30/+0.30 Single Section
- Maximum Running Torque [AEFL]
- 1.00 Inch-Ounces
- Maximum Starting Torque [AEFK]
- 1.50 Inch-Ounces
- Mounting Bushing Length [ADAP]
- 9.5 Millimeters Nominal
- Mounting Method [AXGY]
- Standard Bushing
- Power Dissipation Rating Per Section In Watts [CRGD]
- 4.0 7Th Secondary Quality
- Precious Material And Location [PMLC]
- Terminal Surfaces Gold
- Precious Material [PRMT]
- Gold
- Reliability Indicator [AARG]
- Not Established
- Resistance Tolerance Per Section In Percent [CRSS]
- -3.0/+3.0 Single Section
- Rotary Actuator Travel In Angular Deg [CQCK]
- 360.0 Nominal
- Screw Thread Diameter [AJYN]
- 0.375 Inches Nominal
- Screw Thread Quantity Per Inch [AJYQ]
- 32.0
- Screw Thread Series Designator [AJYP]
- Unef
- Section Quantity [AAPN]
- 1
- Shaft Diameter [ABWV]
- 6.3 Millimeters Nominal
- Shaft Bearing Type [AEDZ]
- Sleeve
- Shaft End Play [AEFY]
- 0.003 Inches
- Shaft Length [ABXF]
- 12.7 Millimeters Nominal
- Shaft Radial Play [AEGC]
- 0.003 Inches
- Shaft Runout [AEFZ]
- 0.001 Inches
- Shaft Style [AEDX]
- Round, Slotted
- Temp Coefficient Of Resistance Wire Per Section In Ppm Per Deg Celsius [CSCY]
- -20.0/+20.0 Single Section
- Terminal Location [APXH]
- Radially Positioned Over Less Than Half The Circumference
- Terminal Type And Quantity [TTQY]
- 3 Turret
Similar Supply Items to 5905-01-452-5008
Freight Information 5905-01-452-5008
5905-01-452-5008 has freight characteristics.. 5905-01-452-5008 has a variance between NMFC and UFC when transported by rail and the description should be consulted.
