5905-01-314-6252
Film Fixed Chip Resistor
5905013146252 013146252 MIL-PRF-55342/3 M55342/3-K1961KBM M55342K03B1N96M M55342K03B1E96R MIL-R-55342/3
A resistor whose ohmic value cannot be adjusted or varied. The resistor element consists of either a thin layer or conductive material, containing neither binders or insulating materials, deposited on an insulated form, or an alloy of metal and ceramic materials, usually fused to an insulated form. Opposition to the flow of current is an inherent property of the materials used and is manifest by the heat dissipation in the resistor. Primarily intended for incorporation into microelectronic circuits and surface mounted applications. View more Film Fixed Chip Resistor
November 2023
10
Marketplace 5905-01-314-6252
Request a Quotation from participating marketplace vendors
Related Documents 5905-01-314-6252 5+ Documents (More...)
/fsg-59/fsc-5905/us
MIL-R-55342/3 Fixed 3 M55342K03B464ER MIL-R MIL-R-55342/3 Fixed Chip MIL-PRF-55342/3 M55342K03B464ER
MIL-R-55342 Fixed Chip MIL-PRF -55342/3 M55342 M55342K03B464ER MIL-R-55342/ 3 M55342 M55342K03B464ER
/fsg-59/fsc-5905/us
MIL-R-55342 Fixed Chip MIL-PRF -55342/3 M55342 M55342K03B464ER MIL-R-55342/ 3 M55342 M55342K03B464ER
Fixed Chip MIL-PRF-55342 3 M55342K03B464ER MIL-R MIL-R-55342 /3 Fixed Chip MIL-PRF-55342/3 M55342K03B464ER
/fsg-59/fsc-5905/us
M55342K03B464ER MIL-R-55342 /3 Fixed Chip MIL-PRF -55342/3 M55342 M55342K03B464ER MIL-R-55342 https/
Chip MIL-PRF-55342/3 M55342K03B464ER MIL-R MIL-R-55342/3 3 M55342K03B464ER MIL-R MIL-R-55342/3 Fixed
/fsg-59/fsc-5905/us
Chip MIL-PRF-55342/3 M55342K03B464ER MIL-R MIL-R-55342/3 3 M55342K03B464ER MIL-R MIL-R-55342/3 Fixed
M55342 M55342K03B464ER MIL-R-55342/ 3 M55342 M55342K03B464ER MIL-R-55342 Fixed Chip MIL-PRF -
/fsg-59/fsc-5905/us
Fixed Chip MIL-PRF-55342/3 M55342 Resistor 5905014444095 M55342K03B464ER MIL-R MIL-R-55342/3 Fixed
Chip Resistor5905012664612 012664612 MIL-PRF-55342/ 3 M55342K03B464ER MIL-R MIL-R-55342/3 Fixed Chip
Restrictions 5905-01-314-6252
5905-01-314-6252 is a Film Fixed Chip Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal. This item is sensitive to Electrostatic Discharge.
Import and Export 5905-01-314-6252
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-01-314-6252
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- Spain (YB01)
- Effective Date:
- 1 Jun 2003
Approved Sources 5905-01-314-6252
- Part Number
- Manufacturer
- Status
- M55342K03B1E96R
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-55342/3
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-R-55342/3
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- M55342/3-K1961KBM
- 81349 - Military Specifications (Active)
- Advisory Reference
- Advisory Reference
- M55342K03B1N96M
- 81349 - Military Specifications (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5905-01-314-6252
- Characteristic
- Specifications
- FIIG
- Specifications
- A001A0
- Electrical Resistance [AAPP]
- 1.960 Kilohms
- Ambient Temp In Deg Celsius At Full Rated Power [AAQF]
- 70.0
- Ambient Temp In Deg Celsius At Zero Percent Rated Power [AAQG]
- 150.0
- Body Height [ADAU]
- 0.010 Inches Minimum And 0.040 Inches Maximum
- Body Length [ADAQ]
- 0.045 Inches Minimum And 0.060 Inches Maximum
- Body Width [ADAT]
- 0.095 Inches Minimum And 0.125 Inches Maximum
- End Item Identification [AGAV]
- Pump,Centrifu
- Inclosure Method [AAQZ]
- Uninclosed
- Power Dissipation Rating In Watts [AEFB]
- 0.100 Free Air
- Reliability Failure Rate Level In Percent [AARH]
- 0.010
- Reliability Indicator [AARG]
- Established
- Resistance Tolerance In Percent [AAPQ]
- -1.000 To 1.000
- Unpackaged Unit Weight [PKWT]
- 0.01 Grams
- Specification/Standard Data [ZZZK]
- 81349-Mil-R-55342/3 Government Specification
- Style Designator [STYL]
- Termination Pad Each End
- Temp Coefficient Of Resistance In Ppm Per Deg Celsius [AAPE]
- -100.0 To 100.0
- Temp Range Of Temp Coefficient In Deg Celsius [AAQH]
- -55.0 To 125.0
- Terminal Type [AARB]
- Terminal Type Per Body Style
- Test Data Document [TEST]
- 81349-Mil-R-55342 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Weapon Systems (WSDC) 5905-01-314-6252
DLA Procurement Analysis 5905-01-314-6252
- Last Stock Position:
- 1 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5905-01-314-6252
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5905-01-314-6252
Freight Information 5905-01-314-6252
5905-01-314-6252 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-01-314-6252 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-01-314-6252 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5905-01-314-6252 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 5905-01-314-6252 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
