5905-01-123-5187
Film Fixed Resistor
5905011235187 011235187 35300020-1 35300018-1
A resistor whose ohmic value cannot be adjusted or varied. The resistance element consists of either a thin layer of conductive material, containing either binders or insulating materials, deposited on an insulated form; or an alloy of metal and ceramic materials, usually fused to an insulated form. Opposition to the flow of current is an inherent property of the materials used and is manifest by the heat dissipation in the resistor. See also ATTENUATOR, FIXED and RESISTOR, FIXED, COMPOSITION. Excludes carbon composition type resistors. View more Film Fixed Resistor
May 2023
4
Marketplace 5905-01-123-5187
Request a Quotation from participating marketplace vendors
Related Documents 5905-01-123-5187 2+ Documents (More...)
Quotation Updated Every Day 5905-01-123-5187 RQST NE Updated Every Day 5905-01-123-5187 RQST Updated
Every Day 5905-01-123-5187 RQST NE Related Documents 5905-01-123-5187 2+ Documents ( More... ) https
Film Fixed Resistor 5905011235187 011235187 $1 a day Upgrade your Account Upgrade 5905-01-123-5187Film
Fixed Resistor5905011235187 011235187 35300020 ... 35300018-1 RESISTOR,FIXED,FILM 1 EA NS Request Quotation
Restrictions 5905-01-123-5187
5905-01-123-5187 is a Film Fixed Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5905-01-123-5187
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-01-123-5187
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- GTHXHD
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5905-01-123-5187
- Part Number
- Manufacturer
- Status
- 35300020-1
- Manufacturer
- 20019 - Ward Leonard Ct Llc (Active)
- Primary Buy
- Primary Buy
- 35300018-1
- 20019 - Ward Leonard Ct Llc (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5905-01-123-5187
- Characteristic
- Specifications
- FIIG
- Specifications
- A001A0
- Electrical Resistance [AAPP]
- 0.240 Ohms
- Ambient Temp In Deg Celsius At Full Rated Power [AAQF]
- 25.0
- Ambient Temp In Deg Celsius At Zero Percent Rated Power [AAQG]
- 275.0
- Body Length [ADAQ]
- 27.500 Inches Nominal
- Body Width [ADAT]
- 3.000 Inches Nominal
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Length [AEBY]
- 29.000 Inches Nominal
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Width [AEHA]
- 1.750 Inches Nominal
- Mounting Hole Size [BYML]
- 0.656 Inches Nominal
- Inclosure Method [AAQZ]
- Uninclosed
- Power Dissipation Rating In Watts [AEFB]
- 4056.000 Free Air
- Reliability Indicator [AARG]
- Not Established
- Resistance Tolerance In Percent [AAPQ]
- -10.000/+10.000
- Style Designator [STYL]
- Terminals One Side
- Terminal Length [ABJT]
- 1.000 Inches Nominal
- Terminal Type [AARB]
- Double Screw
- Terminal Width [AFWW]
- 3.000 Inches Nominal
Weapon Systems (WSDC) 5905-01-123-5187
DLA Procurement Analysis 5905-01-123-5187
Management Data 5905-01-123-5187
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5905-01-123-5187
Freight Information 5905-01-123-5187
5905-01-123-5187 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-01-123-5187 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-01-123-5187 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5905-01-123-5187 is not classified as a special type of cargo when transported by water. 5905-01-123-5187 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5905-01-123-5187
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- A-A-203, Kraft Wrapping Paper
- ASTM-D4727, Fiberboard used as Pads, Cells, Die-cuts or Sleeves
- --
- ASTM-D5118, Type CF, Class Domestic, Corrugated Fiberboard Box
- Special requirements
- A-A-203, Kraft Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- Any Suitable Fiber Box
Contracting Technical Data File (CTDF) 5905-01-123-5187 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- J
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
