5905-00-938-3527
Precision Nonwire Wound Variable Resistor
5905009383527 009383527 60609 749-6175 7648736P005 7648736PT5
A resistor in which a sliding or rolling contact moves over an exposed area of the resistive element to change the ohmic value of the output. The finctional tolerance (linearity) of the output is equal to or less than plus or minus 1 percent on linear outputs. Specified outputs such as sine, cosine, tangent, etc., shall be considered to be precision. For items having manually postioned taps designed to be set and fixed prior to use, see RESISTOR, ADJUSTABLE. For items with step by step variation, see REHOSTAT and RESISTOR, STEP BY STEP. For tandem-mounted items designed to function together as an attenuator (and rated accordingly), see ATTENUATOR, VARIABLE. Excludes RESISTOR (1), VARIABLE, WIRE WOUND, NONPRECISION; RESISTOR (1), VARIABLE NONWIRE WOUND, NONPRECISION; and RESISTOR (1), VARIABLE, WIRE WOUND, PRECISION. View more Precision Nonwire Wound Variable Resistor
May 2023
6
Marketplace 5905-00-938-3527
Request a Quotation from participating marketplace vendors
Related Documents 5905-00-938-3527 5+ Documents (More...)
Photo 1/6 5905-00-938-3527 Photo 2/6 5905-00-938-3527 Photo 3/6 5905-00-938-3527 Photo 4/6 NSN
5905-00-938-3527 (Identification) 5/6 NSN 5905-00-938-3527 (Identification) 6/6 - - - - - - 1.
Request a Quotation from participating marketplace vendors Request Updated Every Day 5306-99-749-6175
RQST NE Updated Every Day 5306-99-749-6175 RQST Updated Every Day 5306-99-749-6175 RQST NE Related Documents
5315-14-354-7684 Graisseur Axe 5315143547684 143547684,60609 2641 Part NumberManufacturerStatus1303-60609
Every Day 3040-12-191-6101 RQST NE Restrictions https//www.nsnlookup.com /fsg-59/fsc-5905/us 5905-00-938-3527
your Account Upgrade 4720-01-699-0006Nonmetallic Hose Assembly4720016990006 016990006 161SW30-66 17-60609
14-354-7684 Graisseur Axe 5315143547684 143547684,60609 Active) Primary Buy RNCC 3 RNVC 2 DAC 5 17-60609
4310-99-591-2721 Bin Lid Assembly 4310995912721 995912721 906-2641 Part NumberManufacturerStatus1303 -60609
354-7684 Graisseur Axe 5315143547684 143547684,60609 Quotation Subscribe to View Vendor Details... 60609
Restrictions 5905-00-938-3527
5905-00-938-3527 is a Precision Nonwire Wound Variable Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5905-00-938-3527
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-00-938-3527
- US Navy (N9BN)
- Effective Date:
- 1 Jul 2005
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5905-00-938-3527
- Part Number
- Manufacturer
- Status
- 60609
- Manufacturer
- 10112 - General Dynamics Motion Control Llc (Active)
- Primary Buy
- Primary Buy
- 7648736PT5
- 03538 - Lockheed Martin Corporation (Active)
- Secondary Buy
- Secondary Buy
- 749-6175
- 03538 - Lockheed Martin Corporation (Active)
- Secondary Buy
- Secondary Buy
- 7648736PT5
- 98659 - Donel Systems Llc (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7648736P005
- 03538 - Lockheed Martin Corporation (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 5905-00-938-3527
- Characteristic
- Specifications
- FIIG
- Specifications
- A002A0
- Effective Electrical Rotation In Deg Angular Rotation [AEFH]
- 350.0 Nominal
- Electrical Resistance Per Section [CQCC]
- 5.0 Percent, Rated Amperes C And Better Finish
- Electrical Resistance Per Section [CQCC]
- 50.0 Percent, Rated Amperes C And Better Industrial Clears
- Actuator Travel Control Feature [CRSX]
- Continuous Motion
- Actuator Type [AEFD]
- Single Shaft
- Ambient Temp In Deg Celsius Per Section At Full Rated Power [CSDH]
- 40.0 All Sections
- Ambient Temp In Deg Celsius Per Section At Zero Percent Rated Power [CQGN]
- 125.0 All Sections
- Body Diameter [ABPM]
- 1.453 Inches Nominal
- Body Length [ADAQ]
- 1.500 Inches Nominal
- Body Style [AAQL]
- Cylindrical Servo Mounted
- Function Characteristic Per Section [CSBX]
- All Sections Linear
- Function Conformity Per Section [CRGM]
- All Sections Independent Linearity
- Function Conformity Tolerance Per Section [CQFL]
- -0.10/+0.10 All Sections
- Maximum Starting Torque [AEFK]
- 0.70 Inch-Ounces
- Mounting Lip Depth [AEDA]
- 0.0880 Inches Minimum And 0.0980 Inches Maximum
- Mounting Lip Diameter [AECZ]
- 1.4320 Inches Minimum And 1.4420 Inches Maximum
- Mounting Method [AXGY]
- Clamp Ring
- Lateral Runout [AEGA]
- 0.002 Inches
- Power Dissipation Rating Per Section In Watts [CRGD]
- 2.0 Free Air All Sections
- Reliability Indicator [AARG]
- Not Established
- Resistance Tolerance Per Section In Percent [CRSS]
- -10.0/+10.0 2Nd Section
- Resistance Tolerance Per Section In Percent [CRSS]
- -10.0/+10.0 1St Section
- Rotary Actuator Travel In Angular Deg [CQCK]
- 360.0 Nominal
- Section Quantity [AAPN]
- 2
- Shaft Bearing Type [AEDZ]
- Ball
- Shaft Diameter [ABWV]
- 0.120 Inches Nominal
- Shaft Runout [AEFZ]
- 0.001 Inches
- Shaft Style [AEDX]
- Round
- Shaft Length [ABXF]
- 0.672 Inches Nominal
- Overall Diameter [ADAV]
- 1.578 Inches Nominal
- Overall Length [ABHP]
- 2.172 Inches Nominal
- Pilot Length [AAVM]
- 0.1270 Inches Minimum And 0.1370 Inches Maximum
- Pilot Diameter Runout [AEGB]
- 0.001 Inches
- Pilot Diameter [AAVL]
- 1.3115 Inches Minimum And 1.3120 Inches Maximum
- Undercut Diameter [ABPA]
- 1.312 Inches Nominal
- Undercut Width [ABPC]
- 0.0730 Inches Nominal
- Terminal Location [APXH]
- Radially Positioned Over Less Than Half The Circumference
- Terminal Length [ABJT]
- 0.125 Inches Nominal
- Terminal Type And Quantity [TTQY]
- 6 Turret
Weapon Systems (WSDC) 5905-00-938-3527
DLA Procurement Analysis 5905-00-938-3527
Management Data 5905-00-938-3527
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5905-00-938-3527
Freight Information 5905-00-938-3527
5905-00-938-3527 has freight characteristics managed by the Office od the Secretary of HEW.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-00-938-3527 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-00-938-3527 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5905-00-938-3527 is not classified as a special type of cargo when transported by water. 5905-00-938-3527 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
