5905-00-735-8547
Adjustable Resistor
5905007358547 007358547 7358547 A5428414
A resistor whose overall ohmic value is fixed; in addition, it has one or more movable terminals which are designed to be set and fixed prior to use, to include any desired value of resistance within the range of the complete resistor. The opposition to the flow of current is an inherent property of the material used and is manifest in the heat dissipated in the item itself. View more Adjustable Resistor
May 2023
19
Marketplace 5905-00-735-8547
Request a Quotation from participating marketplace vendors
Related Documents 5905-00-735-8547 1+ Documents (More...)
Photo 1/7 5905-00-735-8547 Photo 2/7 5905-00-735-8547 Photo 3/7 5905-00-735-8547 Photo 4/7 5905
-00-735-8547 Photo 5/7 5905-00-735-8547 Photo 6/7 NSN 5905-00-735-8547 (Identification) 7/7 - - - - -
Restrictions 5905-00-735-8547
5905-00-735-8547 is a Adjustable Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5905-00-735-8547
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-00-735-8547
- Austria (WB01)
- Effective Date:
- 1 Feb 2005
- Spain (YB01)
- Effective Date:
- 1 Oct 1998
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Aug 1995
- Turkey (ZW01)
- Effective Date:
- 1 Sep 2009
Approved Sources 5905-00-735-8547
- Part Number
- Manufacturer
- Status
- 7358547
- Manufacturer
- 19207 - U S Army Tank Automotive Command (Active)
- Primary Buy
- Primary Buy
- A5428414
- 24446 - General Electric Company (Active)
- Primary Buy
- Primary Buy
Datasheet 5905-00-735-8547
- Characteristic
- Specifications
- FIIG
- Specifications
- A001A0
- Electrical Resistance [AAPP]
- 75.000 Ohms
- Ambient Temp In Deg Celsius At Full Rated Power [AAQF]
- 40.0
- Ambient Temp In Deg Celsius At Zero Percent Rated Power [AAQG]
- 340.0
- Body Diameter [ABPM]
- 0.625 Inches Nominal
- Body Length [ADAQ]
- 2.000 Inches Nominal
- Inclosure Method [AAQZ]
- Encapsulated
- Power Dissipation Rating In Watts [AEFB]
- 75.000 Free Air
- Reactance Characteristic [AARE]
- Inductive
- Resistance Tolerance In Percent [AAPQ]
- -10.000/+10.000
- Style Designator [STYL]
- Radial Terminal Each End
- Terminal Length [ABJT]
- 0.562 Inches Nominal
- Terminal Type [AARB]
- Tab, Solder Lug
Similar Supply Items to 5905-00-735-8547
Freight Information 5905-00-735-8547
5905-00-735-8547 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-00-735-8547 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5905-00-735-8547 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-00-735-8547 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5905-00-735-8547 is not classified as a special type of cargo when transported by water. 5905-00-735-8547 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
