5905-00-643-7571
Resistance Element
5905006437571 006437571 16990-7-4
An item of electrically resistive material in the form of a grid, ribbon, or wire designed to be used singly or built into groups to form a resistance unit. It is usually a maintenance part for a RESISTOR (as modified), a RHEOSTAT, or similar item. Includes items which can be used as "heaters" (heating elements) but which are rated in terms of resistance and resistance tolerance. Excludes ABSORBER, RADIO FREQUENCY RADIATION; HEATER, THERMAL RELEASE; HEATING ELEMENT, ELECTRICAL (as modified); and RESISTOR (as modified). View more Resistance Element
May 2023
6
Marketplace 5905-00-643-7571
Request a Quotation from participating marketplace vendors
Related Documents 5905-00-643-7571 1+ Documents (More...)
RQST NE Updated Every Day 5905-00-643-7571 RQST Updated Every Day 5905-00-643-7571 RQST NE Related Documents
5905-00-643-7571 1+ Documents ( More... ) https//www.nsnlookup.com /fsg-59/fsc-5905/us 5905-00-643-7571
Restrictions 5905-00-643-7571
5905-00-643-7571 is a Resistance Element that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5905-00-643-7571
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-00-643-7571
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5905-00-643-7571
- Part Number
- Manufacturer
- Status
- 16990-7-4
- Manufacturer
- 63743 - Ward Leonard Ct Llc (Active)
- Primary Buy
- Primary Buy
Datasheet 5905-00-643-7571
- Characteristic
- Specifications
- FIIG
- Specifications
- T172-G
- Electrical Resistance [AAPP]
- 0.6215 Ohms
- Material [MATT]
- Steel Corrosion Resisting
- Mounting Configuration [ALGC]
- Terminal Mounted
- Unit Type [APQB]
- Ribbon
- Resistance Tolerance In Percent [AAPQ]
- -20.0 To 20.0
- Resistor Power Dissipation Rating In Watts [ACZQ]
- 1176.0
- Section Resistance Between Taps In Ohms [AWEN]
- 0.124 And 0.249 And 0.249
- Width [ABGL]
- 1.000 Inches Nominal
- Tap Quantity [AWEM]
- 2
- Terminal Length [AAEY]
- 0.500 Inches
- Terminal Quantity [AARA]
- 4
- Terminal Thickness [AAFC]
- 0.016 Inches
- Terminal Type [AARB]
- Screw
- Terminal Width [AAEW]
- 0.438 Inches
- Thickness [ABNM]
- 0.00893 Inches Nominal
DLA Procurement Analysis 5905-00-643-7571
Management Data 5905-00-643-7571
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5905-00-643-7571
Freight Information 5905-00-643-7571
5905-00-643-7571 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-00-643-7571 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-00-643-7571 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5905-00-643-7571 is not classified as a special type of cargo when transported by water. 5905-00-643-7571 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5905-00-643-7571
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- A-A-1249, Paper, Tissue
- No Requirement
- Not Applicable
- --
- No special marking
- A-A-1249, Paper, Tissue
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
Contracting Technical Data File (CTDF) 5905-00-643-7571 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
