5905-00-465-0264
Nonprecision Nonwire Wound Variable Resistor
5905004650264 004650264 MIL-PRF-94/3 RV6SAYD503A 4171786-499 RV6SAYSD503A 76208M010002 MIL-R-9416 5905PL1280916
A resistor in which a sliding or rolling contact moves over an exposed area of the resistive element to change the ohmic value of the output. The functional tolerance (linearity), if given, of the output is greater than plus or minus 1 percent on linear outputs. Specified outputs such as sine, cosine, tangent, etc., shall be considered to be precision. For items having manually positioned taps designed to be set and fixed prior to use, see RESISTOR, ADJUSTABLE. For items with step by step variation, see RHEOSTAT and RESISTOR, STEP BY STEP. For tandem-mounted items designed to function together as an attenuator (and rated accordingly), see ATTENUATOR, VARIABLE. Excludes RESISTOR (1), VARIABLE, WIRE WOUND, NONPRECISION; RESISTOR (1), VARIABLE, NONWIRE WOUND PRECISION; and RESISTOR (1), VARIABLE, WIRE WOUND, PRECISION. View more Nonprecision Nonwire Wound Variable Resistor
November 2023
33
Marketplace 5905-00-465-0264
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5905-00-465-0264 5+ Documents (More...)
Photo 1/3 NSN 5905-00-465-0264 (Identification) 2/3 NSN 5905-00-465-0264 (Identification) 3/3 -
RV6SAYSD503A RESISTOR,VARIABLE,NONWIRE WOUND,NONPRECISION 10 EA NS Request Quotation 5905-00-465-0264
Variable Resistor Similar Supply Items to 9999-99-429-8319 5905-00-184-0926 5905-00-283-6454 5905-00-465-0264
Variable Resistor Similar Supply Items to 9999-99-418-8176 5905-00-184-0926 5905-00-283-6454 5905-00-465-0264
Variable Resistor Similar Supply Items to 9999-22-600-9417 5905-00-184-0926 5905-00-283-6454 5905-00-465-0264
Restrictions 5905-00-465-0264
5905-00-465-0264 is a Nonprecision Nonwire Wound Variable Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown. This item is sensitive to Electrostatic Discharge.
Import and Export 5905-00-465-0264
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-00-465-0264
- US Army (A918)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- A196
- Supplementary Receivers:
- CL
- US Air Force (FXGX)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FXTX
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- GTKEHD
- Austria (WB01)
- Effective Date:
- 1 Aug 2006
- Poland (WP01)
- Effective Date:
- 1 Apr 2005
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Apr 1991
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Apr 1991
- Denmark (ZS01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5905-00-465-0264
- Part Number
- Manufacturer
- Status
- RV6SAYSD503A
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-94/3
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- 76208M010002
- A0810 - Leonardo S.P.A. (Active)
- Secondary Buy
- Secondary Buy
- MIL-R-9416
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 5905PL1280916
- 9009H - Jednolity Indeks Materialowy - (Active)
- NATO Reference
- NATO Reference
- RV6SAYD503A
- 81349 - Military Specifications (Active)
- Advisory Reference
- Advisory Reference
- 4171786-499
- 05869 - Raytheon Company (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5905-00-465-0264
- Characteristic
- Specifications
- FIIG
- Specifications
- A002A0
- Electrical Resistance Per Section [CQCC]
- 50.0 Kilohms Single Section
- Actuator Travel Control Feature [CRSX]
- Stops
- Actuator Type [AEFD]
- Single Shaft
- Ambient Temp In Deg Celsius Per Section At Full Rated Power [CSDH]
- 70.0 Single Section
- Ambient Temp In Deg Celsius Per Section At Zero Percent Rated Power [CQGN]
- 120.0 Single Section
- Body Diameter [ABPM]
- 0.500 Inches Nominal
- Body Length [ADAQ]
- 0.531 Inches Nominal
- Body Style [AAQL]
- Cylindrical Bushing Mounted
- Features Provided [CBBL]
- Panel Seal
- Maximum Starting Torque [AEFK]
- 6.00 Inch-Ounces
- Maximum Stop Torque [AEFM]
- 48.00 Inch-Ounces
- Mounting Bushing Length [ADAP]
- 0.250 Inches Nominal
- Mounting Method [AXGY]
- Standard Bushing
- Nonturn Device Radius [AEFP]
- 0.245 Inches Nominal
- Overall Diameter [ADAV]
- 0.500 Inches Nominal
- Overall Length [ABHP]
- 1.718 Inches Nominal
- Power Dissipation Rating Per Section In Watts [CRGD]
- 0.5 Free Air Single Section
- Resistance Temp Characteristic Range Per Section In Percent [CQDB]
- -3.0 To 0.0 -55 Deg Celsius Single Section And -5.0 To 10.0 -25 Deg Celsius Single Section And -5.0 To 10.0 25 Deg Celsius Single Section And -0.0 To 3.0 120 Deg Celsius Single Section
- Reliability Indicator [AARG]
- Not Established
- Resistance Tolerance Per Section In Percent [CRSS]
- -10.0 To 10.0 Single Section
- Rotary Actuator Travel In Angular Deg [CQCK]
- 292.0 Minimum And 298.0 Maximum
- Screw Thread Diameter [AJYN]
- 0.250 Inches Nominal
- Screw Thread Quantity Per Inch [AJYQ]
- 32.0
- Screw Thread Series Designator [AJYP]
- Unef
- Section Quantity [AAPN]
- 1
- Shaft Diameter [ABWV]
- 0.125 Inches Nominal
- Shaft Length [ABXF]
- 0.875 Inches Nominal
- Shaft Style [AEDX]
- Round, Slotted
- Specification/Standard Data [ZZZK]
- 81349-Mil-R-94/3 Government Specification
- Terminal Location [APXH]
- Rear End
- Terminal Type And Quantity [TTQY]
- 3 Tab, Solder Lug
- Test Data Document [TEST]
- 81349-Mil-R-94 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Weapon Systems (WSDC) 5905-00-465-0264
DLA Procurement Analysis 5905-00-465-0264
- Last Stock Position:
- 35 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5905-00-465-0264
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Apr 2022
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Oct 2021
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Jan 2021
- Defense Logistics Agency (DS)
- EA
- Subscribe
- 1
- EA
- Feb 2020
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- 00
- DLA/GSA Material
DLA/GSA-Managed Items that cannot be identified to a specific Army Weapons Systems/End Item
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5905-00-465-0264
Freight Information 5905-00-465-0264
5905-00-465-0264 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-00-465-0264 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-00-465-0264 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5905-00-465-0264 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 5905-00-465-0264 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5905-00-465-0264
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-P-130, Laminated and Creped Wrapping Paper
- No Requirement
- Not Applicable
- --
- Special requirements
- MIL-P-130, Laminated and Creped Wrapping Paper
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566, PPP-B-676, or ASTM-D5118, Folding, Setup or Fiberboard Box
