5905-00-256-8898
Film Fixed Resistor
5905002568898 002568898 MIL-PRF-55182/1 705+1499+810 705-1499-810 RN55E6802F RNR55J6812FR 705-1475-040 2501459-568 MFF1816G71501F RNR55J6812FM RNR55J6812FP RN55E6812F 538029-6368 C4-1/8-TO-6802 RNC55J6812FS RNR55J6812FS RNC55J6812FM RNC55J6812FR RNC55J6812FP MIL-R-55182/1
A resistor whose ohmic value cannot be adjusted or varied. The resistance element consists of either a thin layer of conductive material, containing either binders or insulating materials, deposited on an insulated form; or an alloy of metal and ceramic materials, usually fused to an insulated form. Opposition to the flow of current is an inherent property of the materials used and is manifest by the heat dissipation in the resistor. See also ATTENUATOR, FIXED and RESISTOR, FIXED, COMPOSITION. Excludes carbon composition type resistors. View more Film Fixed Resistor
Managed by United States
NSN Created on 24 Mar 1971
Data Last Changed
November 2023
November 2023
NATO Update Count
45
45
NATO Data Quality
Marketplace 5905-00-256-8898
Need Help?
Request a Quotation from participating marketplace vendors
Request a Quotation from participating marketplace vendors
5905002568898 RESISTOR,FIXED,FILM 4 EA NS
5905002478684 RESISTOR,FIXED,FILM 1 EA NS
5905002586955 RESISTOR,FIXED,FILM 1 EA NS
Updated Every Day 5905-00-256-8898 RQST NE
Updated Every Day 5905-00-256-8898 RQST
Updated Every Day 5905-00-256-8898 RQST NE
Related Documents 5905-00-256-8898 5+ Documents (More...)
MIL-PRF-55182/1 705+1499+810 705-1499-810 RN55E6802F RNR55J6812FR 705-1475-040 2501459-568 MFF1816G71501F
RNR55J6812FM RNR55J6812FP RN55E6812F 538029-6368 C4-1/8-TO-6802 RNC55J6812FS RNR55J6812FS RNC55J6812FM
RNC55J6812FR RNC55J6812FP MIL-R-55182/1 A resistor whose ohmic value cannot be adjusted or varied.
RNR55J6812FM RNR55J6812FP RN55E6812F 538029-6368 C4-1/8-TO-6802 RNC55J6812FS RNR55J6812FS RNC55J6812FM
RNC55J6812FR RNC55J6812FP MIL-R-55182/1 A resistor whose ohmic value cannot be adjusted or varied.
RN55E6812F RESISTOR,FIXED,FILM 106 EA NS Request Quotation Subscribe to View Vendor Details...
RN55E6812F RESISTOR,FIXED,FILM 245 EA NS Request Quotation RNC55J6812FS RESISTOR,FIXED,FILM 4572 EA NS
RNC55J6812FS RESISTOR,FIXED,FILM 5029 EA NS Request Quotation RN55E6812F RESISTOR,FIXED,FILM 2595 EA
RN55E6812F RESISTOR,FIXED,FILM 245 EA NS Request Quotation RNC55J6812FS RESISTOR,FIXED,FILM 4572 EA NS
RNC55J6812FS RESISTOR,FIXED,FILM 5029 EA NS Request Quotation RN55E6812F RESISTOR,FIXED,FILM 2595 EA
RNR55H4530FM MIL-R-55182/1 A resistor whose ohmic value cannot be adjusted or varied.
whose A resistor whose RNR55E2152FS RNC55E2152FS MIL-R-55182/1 RNR55H6651BS MIL-R-55182/1 DAC E MILR55182
Film Fixed Resistor 5905002568898 002568898 a day Upgrade your Account Upgrade 5905-00-256-8898Film
whose A resistor whose RNR55E2152FS RNC55E2152FS MIL-R-55182/1 RNR55H6651BS MIL-R-55182/1 DAC E MILR55182
Film Fixed Resistor 5905002568898 002568898 a day Upgrade your Account Upgrade 5905-00-256-8898Film
RNR55J4992FM MIL-R-55182/1 A resistor whose ohmic value cannot be adjusted or varied.
whose A resistor whose RNR55E2152FS RNC55E2152FS MIL-R-55182/1 //www.nsnlookup.com /fsg-59/fsc-5905/
Film Fixed Resistor 5905002568898 002568898 a day Upgrade your Account Upgrade 5905-00-256-8898Film
whose A resistor whose RNR55E2152FS RNC55E2152FS MIL-R-55182/1 //www.nsnlookup.com /fsg-59/fsc-5905/
Film Fixed Resistor 5905002568898 002568898 a day Upgrade your Account Upgrade 5905-00-256-8898Film
RNR55J6802FM MIL-R-55182/1 RN55E6802F A resistor whose ohmic value cannot be adjusted or varied
RNR55E2152FR RNR55E2152FM A resistor whose A resistor whose RNR55E2152FS RNC55E2152FS MIL-R-55182/1
RNR55H6651BS MIL-R-55182/1 DAC E MILR55182-1 81349 - Military Specifications (Active) Canceled https
RNR55E2152FR RNR55E2152FM A resistor whose A resistor whose RNR55E2152FS RNC55E2152FS MIL-R-55182/1
RNR55H6651BS MIL-R-55182/1 DAC E MILR55182-1 81349 - Military Specifications (Active) Canceled https
Restrictions 5905-00-256-8898
5905-00-256-8898 is a Film Fixed Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown. This item is sensitive to Electrostatic Discharge.
Import and Export 5905-00-256-8898
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-00-256-8898
- US Army (A918)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- A196
- Supplementary Receivers:
- BFCT
- US Air Force (FXGX)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- FXTX
- US Marine Corps (MC49)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- MC13
- US Navy (N9BN)
- Effective Date:
- 1 Aug 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- GTKEJBHXHD
- Poland (WP01)
- Effective Date:
- 1 Mar 2007
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Singapore (YJ01)
- Effective Date:
- 1 May 1994
- Australia (ZA01)
- Effective Date:
- 1 Apr 1991
- New Zealand (ZE01)
- Effective Date:
- 1 Nov 1998
- France (ZF01)
- Effective Date:
- 1 May 2015
- Germany (ZG01)
- Effective Date:
- 1 Apr 1991
- Republic of Korea (ZH01)
- Effective Date:
- 1 Nov 2002
- Netherlands (ZN01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Apr 1991
- Greece (ZU01)
- Effective Date:
- 1 Mar 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5905-00-256-8898
- Part Number
- Manufacturer
- Status
- RNC55J6812FS
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-55182/1
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- RNC55J6812FM
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- RNC55J6812FR
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- RNC55J6812FP
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- MIL-R-55182/1
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 705+1499+810
- 13499 - Rockwell Collins, Inc. (Active)
- Advisory Reference
- Advisory Reference
- 705-1499-810
- 13499 - Rockwell Collins, Inc. (Active)
- Advisory Reference
- Advisory Reference
- RN55E6802F
- 81349 - Military Specifications (Active)
- Advisory Reference
- Advisory Reference
- RNR55J6812FR
- 81349 - Military Specifications (Active)
- Advisory Reference
- Advisory Reference
- 705-1475-040
- 13499 - Rockwell Collins, Inc. (Active)
- Advisory Reference
- Advisory Reference
- 2501459-568
- 07187 - Honeywell International Inc. (Active)
- Advisory Reference
- Advisory Reference
- MFF1816G71501F
- 91637 - Vishay Dale Electronics, Llc (Active)
- Advisory Reference
- Advisory Reference
- RNR55J6812FM
- 81349 - Military Specifications (Active)
- Advisory Reference
- Advisory Reference
- RNR55J6812FP
- 81349 - Military Specifications (Active)
- Advisory Reference
- Advisory Reference
- RN55E6812F
- 81349 - Military Specifications (Active)
- Advisory Reference
- Advisory Reference
- 538029-6368
- 96214 - Raytheon Company (Active)
- Advisory Reference
- Advisory Reference
- C4-1/8-TO-6802
- 24546 - Dale Electronics Inc A Vishay (Obsolete)
- Advisory Reference
- Advisory Reference
- RNR55J6812FS
- 81349 - Military Specifications (Active)
- Transferred
- Transferred
Datasheet 5905-00-256-8898
- Characteristic
- Specifications
- FIIG
- Specifications
- A001A0
- Electrical Resistance [AAPP]
- 68.100 Kilohms
- Ambient Temp In Deg Celsius At Full Rated Power [AAQF]
- 125.0
- Ambient Temp In Deg Celsius At Zero Percent Rated Power [AAQG]
- 175.0
- Body Diameter [ABPM]
- 0.109 Inches Nominal
- Body Length [ADAQ]
- 0.250 Inches Nominal
- Inclosure Method [AAQZ]
- Encapsulated
- Power Dissipation Rating In Watts [AEFB]
- 0.100 Free Air
- Reliability Failure Rate Level In Percent [AARH]
- 0.001
- Reliability Indicator [AARG]
- Established
- Resistance Tolerance In Percent [AAPQ]
- -1.000/+1.000
- Style Designator [STYL]
- Axial Terminal Each End
- Temp Range Of Temp Coefficient In Deg Celsius [AAQH]
- -55.0/+175.0
- Temp Coefficient Of Resistance In Ppm Per Deg Celsius [AAPE]
- -25.0/+25.0
- Terminal Type [AARB]
- Wire Lead
- Test Data Document [TEST]
- 81349-Milr55182 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Weapon Systems (WSDC) 5905-00-256-8898
DLA Procurement Analysis 5905-00-256-8898
- Last Stock Position:
- 306 In Stock
- DLA Administrative Lead Time:
- Subscribe
- DLA Production Lead Time:
- Subscribe
Management Data 5905-00-256-8898
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- CC
- Other Aircraft Categories
Multi-Application Aviation Spares
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Marine Corps
- Stores Account:
- 1
- Stock Fund Account Item
- Combat Essentiality:
- 2
- Non-Critical Repair Part
- Echelon Management:
- B2
- Operational Test:
- No Special Procedures
Similar Supply Items to 5905-00-256-8898
Freight Information 5905-00-256-8898
5905-00-256-8898 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-00-256-8898 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-00-256-8898 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5905-00-256-8898 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 5905-00-256-8898 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5905-00-256-8898
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- No Requirement
- No Requirement
- Not Applicable
- --
- Special requirements
- No Requirement
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
