5905-00-251-0537
Nonprecision Nonwire Wound Variable Resistor
5905002510537 002510537 GA2G048S253UA 441-602-008 N441-602-008
A resistor in which a sliding or rolling contact moves over an exposed area of the resistive element to change the ohmic value of the output. The functional tolerance (linearity), if given, of the output is greater than plus or minus 1 percent on linear outputs. Specified outputs such as sine, cosine, tangent, etc., shall be considered to be precision. For items having manually positioned taps designed to be set and fixed prior to use, see RESISTOR, ADJUSTABLE. For items with step by step variation, see RHEOSTAT and RESISTOR, STEP BY STEP. For tandem-mounted items designed to function together as an attenuator (and rated accordingly), see ATTENUATOR, VARIABLE. Excludes RESISTOR (1), VARIABLE, WIRE WOUND, NONPRECISION; RESISTOR (1), VARIABLE, NONWIRE WOUND PRECISION; and RESISTOR (1), VARIABLE, WIRE WOUND, PRECISION. View more Nonprecision Nonwire Wound Variable Resistor
May 2023
15
Marketplace 5905-00-251-0537
Request a Quotation from participating marketplace vendors
Related Documents 5905-00-251-0537 5+ Documents (More...)
Photo 1/3 NSN 5905-00-251-0537 (Identification) 2/3 NSN 5905-00-251-0537 (Identification) 3/3 -
RQST NE Updated Every Day 5905-00-251-0537 RQST Updated Every Day 5905-00-251-0537 RQST NE Related Documents
Restrictions 5905-00-251-0537
5905-00-251-0537 is a Nonprecision Nonwire Wound Variable Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5905-00-251-0537
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-00-251-0537
- Spain (YB01)
- Effective Date:
- 1 Jul 2003
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
Approved Sources 5905-00-251-0537
- Part Number
- Manufacturer
- Status
- GA2G048S253UA
- Manufacturer
- 01121 - Rockwell Automation, Inc. (Active)
- Primary Buy
- Primary Buy
- 441-602-008
- A1997 - Elettronica Spa (Active)
- Secondary Buy
- Secondary Buy
- N441-602-008
- A1997 - Elettronica Spa (Active)
- Secondary Buy
- Secondary Buy
- N441-602-008
- C3141 - Elettronica Gmbh (Active)
- Secondary Buy
- Secondary Buy
Datasheet 5905-00-251-0537
- Characteristic
- Specifications
- FIIG
- Specifications
- A002A0
- Effective Electrical Rotation In Deg Angular Rotation [AEFH]
- 295.0 Nominal
- Electrical Resistance Per Section [CQCC]
- 25.000 Kilohms Single Section
- Actuator Travel Control Feature [CRSX]
- Stops
- Actuator Type [AEFD]
- Single Shaft
- Ambient Temp In Deg Celsius Per Section At Full Rated Power [CSDH]
- 70.0 Single Section
- Ambient Temp In Deg Celsius Per Section At Zero Percent Rated Power [CQGN]
- 120.0 Single Section
- Body Diameter [ABPM]
- 0.500 Inches Nominal
- Body Length [ADAQ]
- 0.469 Inches Maximum
- Body Style [AAQL]
- Cylindrical Bushing Mounted
- Features Provided [CBBL]
- Nonmetallic Shaft
- Mechanical Backlash In Deg Angular Rotation [AEGD]
- 3.0
- Mounting Bushing Length [ADAP]
- 0.250 Inches Nominal
- Mounting Method [AXGY]
- Standard Bushing
- Nonturn Device Location [AEFN]
- At 4'30 Oclock And At 10'30 Oclock
- Nonturn Device Radius [AEFP]
- 0.245 Inches Nominal
- Overall Length [ABHP]
- 1.453 Inches Maximum
- Overall Diameter [ADAV]
- 0.500 Inches Nominal
- Power Dissipation Rating Per Section In Watts [CRGD]
- 0.5 Free Air Single Section
- Reliability Indicator [AARG]
- Not Established
- Resistance Tolerance Per Section In Percent [CRSS]
- -10.0 To 10.0 Single Section
- Rotary Actuator Travel In Angular Deg [CQCK]
- 295.0 Nominal
- Screw Thread Diameter [AJYN]
- 0.250 Inches Nominal
- Screw Thread Quantity Per Inch [AJYQ]
- 32.0
- Screw Thread Series Designator [AJYP]
- Unef
- Section Quantity [AAPN]
- 1
- Shaft Diameter [ABWV]
- 0.125 Inches Nominal
- Shaft Style [AEDX]
- Round, Slotted
- Shaft Length [ABXF]
- 0.750 Inches Nominal
- Terminal Location [APXH]
- Rear End
- Terminal Type And Quantity [TTQY]
- 3 Tab, Solder Lug
Similar Supply Items to 5905-00-251-0537
Freight Information 5905-00-251-0537
5905-00-251-0537 has freight characteristics managed by Germany.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-00-251-0537 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5905-00-251-0537 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-00-251-0537 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5905-00-251-0537 is not classified as a special type of cargo when transported by water. 5905-00-251-0537 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
