5905-00-243-7997
Precision Nonwire Wound Variable Resistor
5905002437997 002437997 0786
A resistor in which a sliding or rolling contact moves over an exposed area of the resistive element to change the ohmic value of the output. The finctional tolerance (linearity) of the output is equal to or less than plus or minus 1 percent on linear outputs. Specified outputs such as sine, cosine, tangent, etc., shall be considered to be precision. For items having manually postioned taps designed to be set and fixed prior to use, see RESISTOR, ADJUSTABLE. For items with step by step variation, see REHOSTAT and RESISTOR, STEP BY STEP. For tandem-mounted items designed to function together as an attenuator (and rated accordingly), see ATTENUATOR, VARIABLE. Excludes RESISTOR (1), VARIABLE, WIRE WOUND, NONPRECISION; RESISTOR (1), VARIABLE NONWIRE WOUND, NONPRECISION; and RESISTOR (1), VARIABLE, WIRE WOUND, PRECISION. View more Precision Nonwire Wound Variable Resistor
May 2023
4
Marketplace 5905-00-243-7997
Request a Quotation from participating marketplace vendors
Related Documents 5905-00-243-7997 2+ Documents (More...)
Request a Quotation from participating marketplace vendors Request Global Test Supply 0786 Kestrel 0786
RQST NE Updated Every Day 5905-00-243-7997 RQST Updated Every Day 5905-00-243-7997 RQST NE Related
Restrictions 5905-00-243-7997
5905-00-243-7997 is a Precision Nonwire Wound Variable Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal. This item is sensitive to Electrostatic Discharge.
Import and Export 5905-00-243-7997
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-00-243-7997
- US Air Force (FGGX)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- FGTX
- Brazil (YA01)
- Effective Date:
- 1 Nov 2008
- Turkey (ZW01)
- Effective Date:
- 1 Nov 2005
Approved Sources 5905-00-243-7997
- Part Number
- Manufacturer
- Status
- 0786
- Manufacturer
- 88379 - Frontgrade Technologies Inc. (Active)
- Primary Buy
- Primary Buy
Datasheet 5905-00-243-7997
- Characteristic
- Specifications
- FIIG
- Specifications
- A002A0
- Effective Electrical Rotation In Deg Angular Rotation [AEFH]
- 342.0 Nominal
- Electrical Resistance Per Section [CQCC]
- 5.000 Percent, Rated Amperes C And Better Finish
- Electrical Resistance Per Section [CQCC]
- 1.000 Percent, Rated Amperes C And Better Industrial Clears
- Electrical Resistance Per Section [CQCC]
- 1.000 Percent, Rated Amperes C And Better Select
- Actuator Travel Control Feature [CRSX]
- Continuous Motion
- Ambient Temp In Deg Celsius Per Section At Full Rated Power [CSDH]
- 25.0 Single Section
- Features Provided [CBBL]
- Nonmetallic Shaft
- Function Characteristic Per Section [CSBX]
- Single Section Linear
- Function Conformity Tolerance Per Section [CQFL]
- -1.00/+1.00 Single Section
- Maximum Running Torque [AEFL]
- 0.60 Inch-Ounces
- Maximum Starting Torque [AEFK]
- 0.60 Inch-Ounces
- Lateral Runout [AEGA]
- 0.002 Inches
- Power Dissipation Rating Per Section In Watts [CRGD]
- 2.0 Free Air Single Section
- Rotary Actuator Travel In Angular Deg [CQCK]
- 360.0 Nominal
- Section Quantity [AAPN]
- 3
- Shaft Bearing Type [AEDZ]
- Ball
- Shaft End Play [AEFY]
- 0.00300 Inches
- Shaft Radial Play [AEGC]
- 0.001 Inches
- Shaft Runout [AEFZ]
- 0.001 Inches
- Pilot Diameter Runout [AEGB]
- 0.00100 Inches
- Terminal Location [APXH]
- Radially Positioned Over Less Than Half The Circumference
Weapon Systems (WSDC) 5905-00-243-7997
DLA Procurement Analysis 5905-00-243-7997
Management Data 5905-00-243-7997
Similar Supply Items to 5905-00-243-7997
Freight Information 5905-00-243-7997
5905-00-243-7997 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-00-243-7997 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. 5905-00-243-7997 is rated as class 77.5 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-00-243-7997 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5905-00-243-7997 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 5905-00-243-7997 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5905-00-243-7997
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- --
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- --
- Special requirements
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- See Method of Preservation
- --
Contracting Technical Data File (CTDF) 5905-00-243-7997 October 2021
