5905-00-166-4082
Inductive Wire Wound Fixed Resistor
5905001664082 001664082 MIL-PRF-39009/1 RH-25-13.3 0HMS RER70F13R3R MIL-R-18546/1 RE70G13R3 MIL-R-39009/1
A resistor whose ohmic value cannot be adjusted or varied. The resistance element consists of high resistance wire (or ribbon) either wound on an insulated form or constructed so as to be self-supporting. The item must have inherent characteristics of inducing self-inductance. Opposition to current flow is an inherent property of the resistance wire and is manifested by the heat dissipation in the resistor. Exclut s SUPPRESSOR, IGNITION INTERFERENCE. See also RESISTOR (1), FIXED, WIRE WOUND, NONINDUCTIVE. View more Inductive Wire Wound Fixed Resistor
May 2023
33
Marketplace 5905-00-166-4082
Request a Quotation from participating marketplace vendors
Updated Every Day Updated Every Day
Updated Every Day Related Documents 5905-00-166-4082 5+ Documents (More...)
RE70G13R3 RESISTOR,FIXED,WIRE WOUND,INDUCTIVE 19 EA NS Request Quotation RER70F13R3R RESISTOR,FIXED,WIRE
ohmic value cannot MIL-R-18546/1 RESISTOR,FIXED,WIRE WOUND /us 5905-00-166-4082 Inductive https https
MIL-R-18546/1 RESISTOR,FIXED,WIRE WOUND,INDUCTIVE 3 EA NS Request Quotation Subscribe to View Vendor
Inductive Wire Wound Fixed Resistor RH-25-13.3 0HMS RER70F13R3R MIL-R-18546/1 RE70G13R3 MIL-R-39009
Inductive Wire Wound Fixed Resistor RH-25-13.3 0HMS RER70F13R3R MIL-R-18546/1 RE70G13R3 MIL-R-39009
/1 A resistor whose ohmic value RER75F82R5P RER75F82R5R MIL-R-18546/1 RE75G82R5 MIL-R-39009/1 Day 5905
Inductive Wire Wound Fixed Resistor RH-25-13.3 0HMS RER70F13R3R MIL-R-18546/1 RE70G13R3 MIL-R-39009
/1 A resistor whose ohmic value RER75F82R5P RER75F82R5R MIL-R-18546/1 RE75G82R5 MIL-R-39009/1 Day 5905
Resistor RER65F41R2RRE65G41R2 MIL-R-18546/1MIL-R-39009/1 A resistor RE70G13R3 MIL-R-39009/1 A resistor
A resistor whose ohmic value cannot RE70G13R3 MIL-R-39009/1 A resistor whose RE60G53R6 MIL-R-39009
Restrictions 5905-00-166-4082
5905-00-166-4082 is a Inductive Wire Wound Fixed Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5905-00-166-4082
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-00-166-4082
- US Army (A918)
- Effective Date:
- 1 Apr 2006
- Supplementary Receivers:
- CLCT
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Supplementary Collaborators:
- KE
- Brazil (YA)
- Brazil (YA01)
- Effective Date:
- 1 Aug 2000
- Spain (YB)
- Spain (YB01)
- Effective Date:
- 1 Oct 1998
- NATO Maintenance and Supply Agency (ZX)
- NATO Maintenance and Supply Agency (ZX01)
- Effective Date:
- 1 Nov 2003
- United States of America (ZZ)
Approved Sources 5905-00-166-4082
- Part Number
- Manufacturer
- Status
- RER70F13R3R
- Manufacturer
- 81349 - Military Specifications (Active)
- Definitive Standard
- Definitive Standard
- MIL-PRF-39009/1
- 81349 - Military Specifications (Active)
- Incomplete Standard
- Incomplete Standard
- MIL-R-39009/1
- 81349 - Military Specifications (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- RH-25-13.3 0HMS
- 91637 - Vishay Dale Electronics, Llc (Active)
- Advisory Reference
- Advisory Reference
- MIL-R-18546/1
- 81349 - Military Specifications (Active)
- Transferred
- Transferred
- RE70G13R3
- 81349 - Military Specifications (Active)
- Transferred
- Transferred
Datasheet 5905-00-166-4082
- Characteristic
- Specifications
- FIIG
- Specifications
- A001A0
- Ambient Temp In Deg Celsius At Full Rated Power [AAQF]
- 25.0
- Ambient Temp In Deg Celsius At Zero Percent Rated Power [AAQG]
- 275.0
- Body Height [ADAU]
- 0.531 Inches Minimum And 0.593 Inches Maximum
- Body Length [ADAQ]
- 1.000 Inches Minimum And 1.124 Inches Maximum
- Body Width [ADAT]
- 0.469 Inches Minimum And 0.593 Inches Maximum
- Cubic Measure [CBME]
- 0.317 Cubic Inches
- Distance Between Centerlines Of Mounting Facilities Parallel To Body Length [AEBY]
- 0.709 Inches Minimum And 0.729 Inches Maximum
- Electrical Resistance [AAPP]
- 13.300 Ohms
- Mounting Hole Size [BYML]
- 0.120 Inches Minimum And 0.130 Inches Maximum
- Inclosure Method [AAQZ]
- Encased
- Power Dissipation Rating In Watts [AEFB]
- 8.000 Free Air
- Reliability Failure Rate Level In Percent [AARH]
- 0.010
- Reliability Indicator [AARG]
- Established
- Resistance Tolerance In Percent [AAPQ]
- -1.000/+1.000
- Unpackaged Unit Weight [PKWT]
- 15.0 Grams
- Specification/Standard Data [ZZZK]
- 81349-Mil-R-39009/1 Government Specification
- Style Designator [STYL]
- Axial Terminal (S)
- Temp Range Of Temp Coefficient In Deg Celsius [AAQH]
- -55.0/+275.0
- Temp Coefficient Of Resistance In Ppm Per Deg Celsius [AAPE]
- -50.0/+50.0
- Terminal Length [ABJT]
- 0.376 Inches Minimum And 0.500 Inches Maximum
- Terminal Width [AFWW]
- 0.140 Inches Minimum
- Terminal Type [AARB]
- Tab, Solder Lug
- Test Data Document [TEST]
- 81349-Mil-R-39009 Specification (Includes Engineering Type Bulletins, Brochures,Etc., That Reflect Specification Type Data In Specification Format; Excludes Commercial Catalogs, Industry Directories, And Similar Trade Publications, Reflecting General Type Data On Certain Environmental And Performance Requirements And Test Conditions That Are Shown As "Typical", "Average", "Nominal", Etc.).
Weapon Systems (WSDC) 5905-00-166-4082
DLA Procurement Analysis 5905-00-166-4082
Management Data 5905-00-166-4082
Army
- Materiel Category and Inventory Manager:
- Q
- Electronics Materiel (DLA/GSA Items)
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 2
- Non-Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify items, which are not reparable.
- Weapons System / End Item / Homogeneous Group:
- SG
- Surveillance Target Acquisition and Night Observation (STANO)
Infra-red Systems
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
NATO Stock Numbers Related to 5905-00-166-4082
Freight Information 5905-00-166-4082
5905-00-166-4082 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-00-166-4082 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-00-166-4082 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5905-00-166-4082 is not classified as a special type of cargo when transported by water. 5905-00-166-4082 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Contracting Technical Data File (CTDF) 5905-00-166-4082 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- L
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
