5905-00-155-6906
Nonprecision Nonwire Wound Variable Resistor
5905001556906 001556906 J
A resistor in which a sliding or rolling contact moves over an exposed area of the resistive element to change the ohmic value of the output. The functional tolerance (linearity), if given, of the output is greater than plus or minus 1 percent on linear outputs. Specified outputs such as sine, cosine, tangent, etc., shall be considered to be precision. For items having manually positioned taps designed to be set and fixed prior to use, see RESISTOR, ADJUSTABLE. For items with step by step variation, see RHEOSTAT and RESISTOR, STEP BY STEP. For tandem-mounted items designed to function together as an attenuator (and rated accordingly), see ATTENUATOR, VARIABLE. Excludes RESISTOR (1), VARIABLE, WIRE WOUND, NONPRECISION; RESISTOR (1), VARIABLE, NONWIRE WOUND PRECISION; and RESISTOR (1), VARIABLE, WIRE WOUND, PRECISION. View more Nonprecision Nonwire Wound Variable Resistor
May 2023
6
Marketplace 5905-00-155-6906
Request a Quotation from participating marketplace vendors
Related Documents 5905-00-155-6906 5+ Documents (More...)
J RESISTOR,VARIABLE,NONWIRE WOUND,NONPRECISION 1 EA NS Request Quotation Updated Every Day 5905-00-155
-6906 RQST NE Updated Every Day 5905-00-155-6906 RQST Updated Every Day 5905-00-155-6906 RQST NE Related
Restrictions 5905-00-155-6906
5905-00-155-6906 is a Nonprecision Nonwire Wound Variable Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown.
Import and Export 5905-00-155-6906
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-00-155-6906
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ND
- Supplementary Collaborators:
- HD
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
Approved Sources 5905-00-155-6906
- Part Number
- Manufacturer
- Status
- J
- Manufacturer
- 01121 - Rockwell Automation, Inc. (Active)
- Incomplete Reference
- Incomplete Reference
Datasheet 5905-00-155-6906
- Characteristic
- Specifications
- FIIG
- Specifications
- A002A0
- Effective Electrical Rotation In Deg Angular Rotation [AEFH]
- 312.0 Nominal
- Electrical Resistance Per Section [CQCC]
- 500.0 Kilohms Single Section
- Actuator Travel Control Feature [CRSX]
- Stops
- Actuator Type [AEFD]
- Single Shaft
- Ambient Temp In Deg Celsius Per Section At Full Rated Power [CSDH]
- 70.0 Single Section
- Ambient Temp In Deg Celsius Per Section At Zero Percent Rated Power [CQGN]
- 120.0 Single Section
- Body Diameter [ABPM]
- 1.156 Inches Maximum
- Body Length [ADAQ]
- 0.625 Inches Maximum
- Body Style [AAQL]
- Cylindrical Bushing Mounted
- First Flat Length [ABNB]
- 0.344 Inches Nominal
- Flat Height [ABNC]
- 0.214 Inches Minimum And 0.218 Inches Maximum
- Maximum Starting Torque [AEFK]
- 6.00 Inch-Ounces
- Maximum Stop Torque [AEFM]
- 192.00 Inch-Ounces
- Mechanical Backlash In Deg Angular Rotation [AEGD]
- 1.500
- Mounting Bushing Length [ADAP]
- 0.375 Inches Nominal
- Mounting Method [AXGY]
- Standard Bushing
- Nonturn Device Location [AEFN]
- At 3 Oclock And At 9 Oclock
- Nonturn Device Radius [AEFP]
- 0.526 Inches Minimum And 0.536 Inches Maximum
- Overall Diameter [ADAV]
- 1.484 Inches Maximum
- Power Dissipation Rating Per Section In Watts [CRGD]
- 2.25 Heat Sink Single Section
- Reliability Indicator [AARG]
- Not Established
- Resistance Tolerance Per Section In Percent [CRSS]
- -10.0 To 10.0 Single Section
- Rotary Actuator Travel In Angular Deg [CQCK]
- 312.0 Nominal
- Screw Thread Diameter [AJYN]
- 0.375 Inches Nominal
- Screw Thread Quantity Per Inch [AJYQ]
- 32.0
- Screw Thread Series Designator [AJYP]
- Unef
- Section Quantity [AAPN]
- 1
- Shaft Diameter [ABWV]
- 0.248 Inches Minimum And 0.250 Inches Maximum
- Shaft Style [AEDX]
- Round, Flatted
- Shaft Length [ABXF]
- 0.750 Inches Nominal
- Terminal Location [APXH]
- Radially Positioned Over Less Than Half The Circumference
- Terminal Length [ABJT]
- 0.328 Inches Maximum
- Terminal Type And Quantity [TTQY]
- 3 Tab, Solder Lug
DLA Procurement Analysis 5905-00-155-6906
Management Data 5905-00-155-6906
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5905-00-155-6906
Freight Information 5905-00-155-6906
5905-00-155-6906 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-00-155-6906 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-00-155-6906 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5905-00-155-6906 is not classified as a special type of cargo when transported by water. 5905-00-155-6906 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
