5905-00-108-1036
Nonprecision Nonwire Wound Variable Resistor
5905001081036 001081036 7249708 A83571 380-0219-000 353-5077 380-0219-00 35
A resistor in which a sliding or rolling contact moves over an exposed area of the resistive element to change the ohmic value of the output. The functional tolerance (linearity), if given, of the output is greater than plus or minus 1 percent on linear outputs. Specified outputs such as sine, cosine, tangent, etc., shall be considered to be precision. For items having manually positioned taps designed to be set and fixed prior to use, see RESISTOR, ADJUSTABLE. For items with step by step variation, see RHEOSTAT and RESISTOR, STEP BY STEP. For tandem-mounted items designed to function together as an attenuator (and rated accordingly), see ATTENUATOR, VARIABLE. Excludes RESISTOR (1), VARIABLE, WIRE WOUND, NONPRECISION; RESISTOR (1), VARIABLE, NONWIRE WOUND PRECISION; and RESISTOR (1), VARIABLE, WIRE WOUND, PRECISION. View more Nonprecision Nonwire Wound Variable Resistor
May 2023
30
Marketplace 5905-00-108-1036
Request a Quotation from participating marketplace vendors
Related Documents 5905-00-108-1036 5+ Documents (More...)
/fsg-59/fsc-5905/us
-353-5077 3+ 5905001081036 001081036,7249708,A83571 Updated Every Day https//www.nsnlookup.com /fsg-61
,A83571 fsc-9905 /fr 9905-14 -353-5077 /fsg-99/fsc-9905 https//www.nsnlookup.com /fsg-61/fsc-6150/de
001081036,7249708,A83571 www.nsnlookup.com https//www.nsnlookup.com /fsg-59/fsc-5905/us 5905-00-108-1036
5905001081036 001081036,7249708,A83571 -108-10365905001081036 001081036,7249708,A83571 https//www.nsnlookup.com
or rolling contact 001081036,7249708,A83571 9905/fr 9905-14-353-5077 https 5905-00-108-10365905001081036
001081036,7249708,A83571 fsc-9905 /fr 9905-14 -353-5077 353-5077 001081036,7249708,A83571 9905/fr 9905
//www.nsnlookup.com /fsg-41/fsc-4130/us 4130-00-353-5077 4130003535077003535077 us 5905-00-108-1036 5905001081036
001081036,7249708,A83571 vendors Request https//www.nsnlookup.com /fsg-59/fsc-5905/us 5905-00-108-1036
/fsg-61/fsc-6150/de 6150-12-353-5077 6150-12-353-5077 RQST NE Related Documents 6150-12-353-5077 4+
//www.nsnlookup.com /fsg-59/fsc-5905/us 5905-00-108-1036 5905001081036 001081036,7249708,A83571 9905-
Restrictions 5905-00-108-1036
5905-00-108-1036 is a Nonprecision Nonwire Wound Variable Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
Import and Export 5905-00-108-1036
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-00-108-1036
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Former MOE Rule:
- N9ND
- Brazil (YA01)
- Effective Date:
- 1 Dec 1999
- Spain (YB01)
- Effective Date:
- 1 Apr 1991
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Portugal (ZP01)
- Effective Date:
- 1 Apr 1991
- Italy (ZR01)
- Effective Date:
- 1 Jul 1997
- Greece (ZU01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5905-00-108-1036
- Part Number
- Manufacturer
- Status
- A83571
- Manufacturer
- 58756 - Cts Corp Electromechanical Div (Active)
- Primary Buy
- Primary Buy
- A83571
- 71450 - Cts Corp (Replaced)
- Original Design
- Original Design
- 7249708
- 24617 - General Motors Corp (Active)
- Secondary Buy
- Secondary Buy
- 380-0219-000
- 13499 - Rockwell Collins, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 353-5077
- 11530 - Lockheed Martin Corporation (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 380-0219-00
- 13499 - Rockwell Collins, Inc. (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- 7249708
- 16758 - General Motors Corp Delco (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
- 35
- 11237 - Cts Corp Of California Dba Cts (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5905-00-108-1036
- Characteristic
- Specifications
- FIIG
- Specifications
- A002A0
- Effective Electrical Rotation In Deg Angular Rotation [AEFH]
- 315.0 Nominal
- Electrical Resistance Per Section [CQCC]
- 1.0 Megohms Single Section
- Actuator Travel Control Feature [CRSX]
- Stops
- Actuator Type [AEFD]
- Single Shaft
- Ambient Temp In Deg Celsius Per Section At Full Rated Power [CSDH]
- 40.0 Single Section
- Ambient Temp In Deg Celsius Per Section At Zero Percent Rated Power [CQGN]
- 85.0 Single Section
- Body Diameter [ABPM]
- 1.125 Inches Nominal
- Body Length [ADAQ]
- 0.500 Inches Nominal
- Body Style [AAQL]
- Cylindrical Bushing Mounted
- Mounting Bushing Length [ADAP]
- 0.375 Inches Nominal
- Mounting Method [AXGY]
- Standard Bushing
- Nonturn Device Location [AEFN]
- At 9 Oclock
- Nonturn Device Radius [AEFP]
- 0.531 Inches Nominal
- Power Dissipation Rating Per Section In Watts [CRGD]
- 0.5 Free Air Single Section
- Reliability Indicator [AARG]
- Not Established
- Resistance Tolerance Per Section In Percent [CRSS]
- -20.0 To 20.0 Single Section
- Rotary Actuator Travel In Angular Deg [CQCK]
- 315.0 Nominal
- Screw Thread Diameter [AJYN]
- 0.375 Inches Nominal
- Screw Thread Quantity Per Inch [AJYQ]
- 32.0
- Screw Thread Series Designator [AJYP]
- Unef
- Section Quantity [AAPN]
- 1
- Shaft Diameter [ABWV]
- 0.250 Inches Nominal
- Shaft Style [AEDX]
- Round, Slotted
- Shaft Length [ABXF]
- 0.500 Inches Nominal
- Terminal Location [APXH]
- Radially Positioned Over Less Than Half The Circumference
- Terminal Type And Quantity [TTQY]
- 3 Tab, Solder Lug
DLA Procurement Analysis 5905-00-108-1036
Management Data 5905-00-108-1036
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5905-00-108-1036
Freight Information 5905-00-108-1036
5905-00-108-1036 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-00-108-1036 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-00-108-1036 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5905-00-108-1036 is not classified as a special type of cargo when transported by water. 5905-00-108-1036 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5905-00-108-1036
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- 0.25 lb or less, one dimension 2" or less, other dimensions less than 24"
- 85 to 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- No Requirements
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- A-A-1249, Paper, Tissue
- No Requirement
- Not Applicable
- --
- Special requirements
- A-A-1249, Paper, Tissue
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- PPP-B-566 or PPP-B-676, Folding or Setup Box
Contracting Technical Data File (CTDF) 5905-00-108-1036 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- N
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
