5905-00-104-0870
Thermal Resistor
5905001040870 001040870 TM1-4 18PORM10PC TM14-180HMSP0RM1 171-002-1801 TM1/4 180K
A thermally sensitive resistor whose primary function is to exhibit a change in electrical resistance with a change in body temperature. Item may be mounted in a probe or housing. For ballast tube type resistors, see RESISTOR (1), CURRENT REGULATING. Excludes TRANSMITTER (1), TEMPERATURE, ELECTRICAL RESISTANCE and TEMPERATURE ELEMENT, RESISTANCE METEOROLOGICAL. View more Thermal Resistor
August 2023
6
Marketplace 5905-00-104-0870
Request a Quotation from participating marketplace vendors
Related Documents 5905-00-104-0870 4+ Documents (More...)
Photo 1/4 5905-00-104-0870 Photo 2/4 5905-00-104-0870 Photo 3/4 NSN 5905-00-104-0870 (Identification
Every Day 5905-00-104-0870 RQST Updated Every Day 5905-00-104-0870 RQST NE Related Documents 5905-00
Thermal Resistor 5905001040870 001040870 0870Thermal Resistor5905001040870 001040870TM1-4 https
www.nsnlookup.com /fsg-59/fsc-5905/us 5905-00-418-3615 Thermal Resistor 5905004183615004183615 5905-00-104-0870
TM1-4-180K RESISTOR 1 EA NS Request Quotation Subscribe to View Vendor Details... 5905-00-879-7127 RESISTOR
531713-001TM1-4-180KTM1-4-180 A thermally sensitive resistor whose primary function is to exhibit TM1-4-180K
Restrictions 5905-00-104-0870
5905-00-104-0870 is a Thermal Resistor that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. The precious metals content of this item is unknown. This item is sensitive to Electrostatic Discharge.
Import and Export 5905-00-104-0870
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5905-00-104-0870
- US Air Force (FXGX)
- Effective Date:
- 1 Apr 2006
- US Navy (N9BN)
- Effective Date:
- 1 Apr 2006
- Supplementary Collaborators:
- KE
- Greece (ZU)
- Greece (ZU01)
- Effective Date:
- 1 Mar 2008
- United States of America (ZZ)
Approved Sources 5905-00-104-0870
- Part Number
- Manufacturer
- Status
- 171-002-1801
- Manufacturer
- 88818 - Kearfott Corporation (Active)
- Primary Buy
- Primary Buy
- TM1/4 180K
- 01295 - Texas Instruments Incorporated (Active)
- Canceled/Obsolete
- Canceled/Obsolete
- TM1-4 18PORM10PC
- 01295 - Texas Instruments Incorporated (Active)
- Advisory Reference
- Advisory Reference
- TM14-180HMSP0RM1
- 01295 - Texas Instruments Incorporated (Active)
- Advisory Reference
- Advisory Reference
Datasheet 5905-00-104-0870
- Characteristic
- Specifications
- FIIG
- Specifications
- A086A0
- Ambient Temp At Full Rated Power [AEHY]
- 100.0 Deg Celsius
- Body Length [ADAQ]
- 0.585 Inches Nominal
- Body Outside Diameter [ADAR]
- 0.200 Inches Nominal
- Maximum Operating Temp [AEHZ]
- 150.0 Deg Celsius
- Maximum Power Dissipation Rating [AEHX]
- 250.00 Milliwatts
- Reference Temp In Deg Celsius [CTGT]
- 25.0
- Terminal Surface Treatment [ABDN]
- Solder
- Zero Power Resistance [CQWD]
- 18.000 Ohms
- Inclosure Type [AKNA]
- Encapsulated
- Power Dissipation Constant In Milliwatts Per Deg Celsius [AEJB]
- 5.0
- Reliability Indicator [AARG]
- Not Established
- Resistance Tolerance At A Specified Temp In Percent [AEJF]
- -12.8/+12.8 4Th Resistance-Temperature Point
- Resistance Tolerance At A Specified Temp In Percent [AEJF]
- -14.3/+14.3 7Th Resistance-Temperature Point
- Resistance Tolerance At A Specified Temp In Percent [AEJF]
- -14.6 To 14.6 3Rd Resistance-Temperature Point
- Resistance Tolerance At A Specified Temp In Percent [AEJF]
- -15.0/+15.0 2Nd Resistance-Temperature Point
- Resistance Tolerance At A Specified Temp In Percent [AEJF]
- -16.2 To 16.2 8Th Resistance-Temperature Point
- Resistance Tolerance At A Specified Temp In Percent [AEJF]
- -16.1 To 16.1 1St Resistance-Temperature Point
- Resistance Tolerance At A Specified Temp In Percent [AEJF]
- -18.5/+18.5 9Th Resistance-Temperature Point
- Resistance Tolerance At A Specified Temp In Percent [AEJF]
- -20.0 To 20.0 10Th Resistance-Temperature Point
- Resistance Tolerance At A Specified Temp In Percent [AEJF]
- -10.3/+10.3 5Th Resistance-Temperature Point
- Resistance Tolerance At A Specified Temp In Percent [AEJF]
- -12.1 To 12.1 6Th Resistance-Temperature Point
- Zero Power Resistance At Specified Temp [AEJE]
- 10.4 Ohms 2Nd Resistance-Temperature Point
- Zero Power Resistance At Specified Temp [AEJE]
- 11.3 Ohms 3Rd Resistance-Temperature Point
- Zero Power Resistance At Specified Temp [AEJE]
- 13.3 Ohms 4Th Resistance-Temperature Point
- Zero Power Resistance At Specified Temp [AEJE]
- 15.5 Ohms 5Th Resistance-Temperature Point
- Zero Power Resistance At Specified Temp [AEJE]
- 20.7 Ohms 6Th Resistance-Temperature Point
- Zero Power Resistance At Specified Temp [AEJE]
- 9.7 Ohms 1St Resistance-Temperature Point
- Zero Power Resistance Tolerance In Percent At Reference Temp [CRQJ]
- -10.0/+10.0
- Zero Power Temp Coefficient Of Resistance In Percent Per Deg Celsius [AEJC]
- 0.70
- Zero Power Resistance At Specified Temp [AEJE]
- 24.0 Ohms 7Th Resistance-Temperature Point
- Zero Power Resistance At Specified Temp [AEJE]
- 27.5 Ohms 8Th Resistance-Temperature Point
- Zero Power Resistance At Specified Temp [AEJE]
- 31.9 Ohms 9Th Resistance-Temperature Point
- Zero Power Resistance At Specified Temp [AEJE]
- 35.9 Ohms 10Th Resistance-Temperature Point
- Style Designator [STYL]
- Rod
- Temp Points For Resistance Readings At Zero Power [AEJD]
- -25.0 Deg Celsius 4Th Resistance-Temperature Point
- Temp Points For Resistance Readings At Zero Power [AEJD]
- -50.0 Deg Celsius 3Rd Resistance-Temperature Point
- Temp Points For Resistance Readings At Zero Power [AEJD]
- -75.0 Deg Celsius 1St Resistance-Temperature Point
- Temp Points For Resistance Readings At Zero Power [AEJD]
- -65.0 Deg Celsius 2Nd Resistance-Temperature Point
- Temp Points For Resistance Readings At Zero Power [AEJD]
- 0.0 Deg Celsius 5Th Resistance-Temperature Point
- Temp Points For Resistance Readings At Zero Power [AEJD]
- 100.0 Deg Celsius 8Th Resistance-Temperature Point
- Temp Points For Resistance Readings At Zero Power [AEJD]
- 125.0 Deg Celsius 9Th Resistance-Temperature Point
- Temp Points For Resistance Readings At Zero Power [AEJD]
- 150.0 Deg Celsius 10Th Resistance-Temperature Point
- Temp Points For Resistance Readings At Zero Power [AEJD]
- 50.0 Deg Celsius 6Th Resistance-Temperature Point
- Temp Points For Resistance Readings At Zero Power [AEJD]
- 75.0 Deg Celsius 7Th Resistance-Temperature Point
- Terminal Diameter [AEBT]
- 0.025 Inches Nominal
- Terminal Length [ABJT]
- 1.500 Inches Nominal
- Terminal Type And Quantity [TTQY]
- 2 Wire Lead
- Thermal Time Constant In Seconds [AEJA]
- 54.0
Weapon Systems (WSDC) 5905-00-104-0870
DLA Procurement Analysis 5905-00-104-0870
Management Data 5905-00-104-0870
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5905-00-104-0870
Freight Information 5905-00-104-0870
5905-00-104-0870 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062960. A Sub NMFC of X. It has a NMFC Description of REOSTATS/PARTS NOI. 5905-00-104-0870 is rated as class 77.5 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35140 which rates the freight between FCL and LCL. 5905-00-104-0870 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5905-00-104-0870 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 5905-00-104-0870 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
