5841-00-073-4662

Radar Modulator

5841000734662 000734662 8644482-501 26A219010

An electronic device which produces a succession of short energy pulses for triggering a transmitter tube in a radar set. Excludes GENERATOR, PULSE; CODER, RADIO BEACON; and OSCILLATOR (as modified). View more Radar Modulator

Managed by United States

NSN Created on 1 Jan 1963

Data Last Changed
May 2023

NATO Update Count
17

NATO Data Quality

5841-00-073-4662 MODULATOR,RADAR 5841000734662 000734662 1/3 — 5841-00-073-4662 Photo 1/3

5841-00-073-4662 MODULATOR,RADAR 5841000734662 000734662 2/3 — 5841-00-073-4662 Photo 2/3

5841-00-073-4662 MODULATOR,RADAR 5841000734662 000734662 3/3 — 5841-00-073-4662 Photo 3/3

Marketplace 5841-00-073-4662

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

5841-00-073-4662 MODULATOR,RADAR RQST NS

Updated Every Day

5841-00-073-4662 RQST NE

Restrictions 5841-00-073-4662

IUID Required

5841-00-073-4662 is a Radar Modulator that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.

End Users 5841-00-073-4662

US Air Force (FGG4)
Effective Date:: 1 Apr 1991
Supplementary Receivers:: SU; AMC 0 AMSC 0 AMSC F IMC E IMCACTY TG DSOR FR

Republic of Korea (ZH01)
Effective Date:: 1 Apr 1991

Greece (ZU01)
Effective Date:: 1 Mar 2008

Turkey (ZW01)
Effective Date:: 1 Nov 2005

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Nov 2003

Approved Sources 5841-00-073-4662

Part Number
Manufacturer
Status
8644482-501: 11447 - L3 Technologies, Inc. (Active); Primary Buy; RNCC 3 RNVC 2 DAC 6
26A219010: 98738 - Herley Chicago (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 2
8644482-501: 49671 - Lockheed Martin Corporation (Obsolete); Canceled/Obsolete; RNCC 5 RNVC 9 DAC X

Datasheet 5841-00-073-4662

Characteristic
Specifications
FIIG: A32200
End Item Identification [AGAV]: An/Apn-155

Management Data 5841-00-073-4662

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2022: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2021: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2020: Department of the Air Force (DF); EA; Subscribe; 1
Oct 2019: Department of the Air Force (DF); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Air Force (DF): L; R; Refer To Net Price 1427.67; NET PRICE 1427.67

Similar Supply Items to 5841-00-073-4662

Freight Information 5841-00-073-4662

5841-00-073-4662 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 061700. A Sub NMFC of X. It has a NMFC Description of ELEC APPLIANCES/INSTRUMENTS NOI. 5841-00-073-4662 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 34580 which rates the freight between FCL and LCL. 5841-00-073-4662 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 658 for ocean manifesting and military sealift. 5841-00-073-4662 is not classified as a special type of cargo when transported by water. 5841-00-073-4662 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5841-00-073-4662

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: --; --; --; --; --

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 10.5" H x 10.5" W x 12.5" L; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; --; --; PPP-B-1672, Type I, Vertical Star Cushioning in Reusable Box; ESD sensitive electronic device requirements of MIL-STD-129 apply

Intermediate Pack Level

Quantity of Unit Packs
Container: --; No Requirement
