5836-01-386-2964

Video Recorder

5836013862964 013862964 V-80AB-F P00071

A single component specifically designed to make a record of optic variations or optic and sonic variations on a disk or a magnetic tape. For items designed to record sonic variations only, see RECORDER, SOUND. View more Video Recorder

Managed by United States

NSN Created on 2 Feb 1994

Data Last Changed
May 2023

NATO Update Count
30

NATO Data Quality

5836-01-386-2964 RECORDER,VIDEO 5836013862964 013862964 1/1 — 5836-01-386-2964 Photo 1/1

Marketplace 5836-01-386-2964

Need Help?
Request a Quotation from participating marketplace vendors

Subscribe to View Vendor Details...

V-80AB-F RECORDER,VIDEO 1 EA NS

Subscribe to View Vendor Details...

V-80AB-F RECORDER,VIDEO 1 EA NS

Subscribe to View Vendor Details...

V80AB-F RECORDER,VIDEO 1 EA NS

Updated Every Day

5836-01-386-2964 RQST NE

Related Documents 5836-01-386-2964 5+ Documents (More...)

https//www.nsnlookup.com
/fsg-58/fsc-5836/us

5836-01-386-2964 Video Recorder 5836013862964 013862964

V-80AB-F P00071 A single component specifically designed to make a record of optic variations or optic
V-80AB-F RECORDER,VIDEO 1 EA NS Request Quotation Subscribe to View Vendor Details...
V-80AB-F RECORDER,VIDEO 1 EA NS Request Quotation Subscribe to View Vendor Details...

https//www.nsnlookup.com
/fsg-58/fsc-5836/us

5836-01-469-9751 Video Recorder 5836014699751 014699751

for $1 a day Upgrade your Account Upgrade 5836-01-469-9751Video Recorder5836014699751 014699751 V-80AB-F
Video Recorder 5836013862964 013862964 Upgrade your Account Upgrade 5836-01-386-2964Video https
for $1 a day Upgrade your Account Upgrade 5836-01-469-9751Video Recorder5836014699751 014699751 V-80AB-F

https//www.nsnlookup.com
/fsg-53/fsc-5355/uk

5355-99-404-8460 Knob 5355994048460 994048460,P00071

instructions how to enable JavaScript in your web browser . 5355-99-404-8460Knob5355994048460 994048460 P00071
More... ) https//www.nsnlookup.com /fsg-53/fsc-5355/uk 5355-99-404-8460 Knob 5355994048460994048460,P00071
Video Recorder 5836013862964 013862964 a day Upgrade your Account Upgrade 5836-01-386-2964Video

https//www.nsnlookup.com
/fsg-59/fsc-5930/us

5930-01-575-5676 Rotary Switch 5930015755676 015755676

5930/us 5930-01-575-5676 RQST NE Updated Every Day https//www.nsnlookup.com /fsg-58/fsc-5836/us 5836-01-386-2964
Video Recorder 5836013862964 013862964 Upgrade your Account Upgrade 5836-01-386-2964Video https
5930015755676015755676 Every Day 5930-01-575-5676 RQST Updated Every Day https// 5836013862964013862964 Documents 5836-01-386-2964

https//www.nsnlookup.com
/fsg-58/fsc-5836/us

5836-01-381-8813 Video Recorder 5836013818813 013818813

for $1 a day Upgrade your Account Upgrade 5836-01-381-8813Video Recorder5836013818813 013818813 V-80AB-F-NTSC
https//www.nsnlookup.com /fsg-58/fsc-5836/us 5836-01-381-8813 Video Recorder 5836013818813013818813 V-80AB-F-NTSC
Day 5836-01-381-8813 RQST NE Related Documents https//www.nsnlookup.com /fsg-58/fsc-5836/us 5836-01-386-2964

Restrictions 5836-01-386-2964

IUID Required

5836-01-386-2964 is a Video Recorder that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 5836-01-386-2964

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5836-01-386-2964

US Navy (N2R4)
Effective Date:: 1 Oct 2012; AMC 0 AMSC 0 AMSC V IMC E DSOR CP

Brazil (YA01)
Effective Date:: 1 Oct 2001

Spain (YB01)
Effective Date:: 1 Jun 2003

Singapore (YJ01)
Effective Date:: 3 Mar 1999

Australia (ZA01)
Effective Date:: 1 Aug 2001

Belgium (ZB01)
Effective Date:: 1 Oct 1997

New Zealand (ZE01)
Effective Date:: 1 May 2014

France (ZF01)
Effective Date:: 1 Mar 1998

Republic of Korea (ZH01)
Effective Date:: 1 Mar 1999

United Kingdom (ZK01)
Effective Date:: 1 Mar 2000

Netherlands (ZN01)
Effective Date:: 1 Apr 2003

Italy (ZR01)
Effective Date:: 1 Aug 2003

Greece (ZU01)
Effective Date:: 1 May 2005

Turkey (ZW01)
Effective Date:: 1 Apr 2002

Approved Sources 5836-01-386-2964

Part Number
Manufacturer
Status
V-80AB-F: 50356 - Teac America, Inc (Active); Primary Buy; RNCC 3 RNVC 2 DAC 2
P00071: 0YJB5 - General Atomics Aeronautical (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 4

Datasheet 5836-01-386-2964

Characteristic
Specifications
FIIG: T207-A
End Item Identification [AGAV]: Pacer Dawn
Case [ALFK]: Provided
Frequency Response Tolerance In Decibels [AFGR]: -3.0/+3.0
Frequency Response Range In Hertz [AFYW]: +100.0/+10000.0
Input Channel Quantity [ANWL]: 1
Input Impedance Rating In Ohms [AHTY]: 10000.0
Recording Medium For Which Designed [ANWG]: Tape
Recording Method [ANBK]: Magnetic
Overall Depth [ABFY]: 161.0 Millimeters Nominal
Overall Height [ABKW]: 120.0 Millimeters Nominal
Overall Width [ABMK]: 148.0 Millimeters Nominal
Special Features [FEAT]: Hi-8Mm & 8Mm Tape Format
Supplementary Features [SUPP]: Single Deck; Video Signal Std: Pal; Maximum Recording Time: 90 Min (Pal/Sp) & 180 Min (Pal/Lp); Pwr Rqrmt: 28Vdc; Pwr Consumption: 15 Watts At 28Vdc (45 Watts W/Heater On); Connectors: Bendix Pt02e-10-6P (Power) & Bendix Pt102e-18-32P (Control & Signals)

Management Data 5836-01-386-2964

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Nov 2013: Department of the Navy (DN); EA; Subscribe; 1

Navy

Cognizance:

7R: Bypass

Similar Supply Items to 5836-01-386-2964

Freight Information 5836-01-386-2964

5836-01-386-2964 has freight characteristics managed by the Department of Energy (DOE).It has a National Motor Freight Classification (NMFC) of 063035. A Sub NMFC of X. It has a NMFC Description of SETS RADIO/TV AND RELATED ARTICLES. 5836-01-386-2964 is rated as class 125 when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35070 which rates the freight between FCL and LCL. 5836-01-386-2964 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5836-01-386-2964 is not classified as a special type of cargo when transported by water. 5836-01-386-2964 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5836-01-386-2964

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: 8.5" H x 4.5" W x 6.0" L; --; --; --; --

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 12.5" H x 12.5" W x 14.5" L; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; --; --; PPP-B-1672, Type I, Vertical Star Cushioning in Reusable Box; No special marking

Intermediate Pack Level

Quantity of Unit Packs
Container: --; No Requirement
