5825-01-516-8038

Satellite Signals Navigation Set

5825015168038 015168038 822-1873-001 AN/PSN-13 10084781

A fixed number of components and/or items that acquire and track signals from a constellation of orbital satellites to obtain time and three-dimensional position and velocity directly or in conjunction with sub systems of the host vehicle. Excludes stand alone navigation systems, such as inertial navigation set. View more Satellite Signals Navigation Set

Managed by United States

NSN Created on 21 Jan 2004

Data Last Changed
May 2023

NATO Update Count
21

NATO Data Quality

5825-01-516-8038 NAVIGATION SET,SATELLITE SIGNALS 5825015168038 015168038 1/1 — 5825-01-516-8038 Photo 1/1

Marketplace 5825-01-516-8038

Need Help?
Request a Quotation from participating marketplace vendors

Updated Every Day

5825-01-516-8038 RQST NE

Restrictions 5825-01-516-8038

IUID Required

5825-01-516-8038 is a Satellite Signals Navigation Set that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. The Demilitarization Program Office (DDPO) will provide instructions for demilitarization of this item. This item is not suspected to be hazardous. This item does not contain a precious metal.

Import and Export 5825-01-516-8038

Schedule B: Subscribe to View Schedule B
HTS Code: Subscribe to View HTS Code

End Users 5825-01-516-8038

US Army (A551)
Effective Date:: 1 Mar 2004
Supplementary Receivers:: AZCTBF; AMC 0 AMSC 0 AMSC 3 IMC E DSOR CN

US Air Force (FGG4)
Effective Date:: 1 Jan 2004; AMC 0 AMSC 0 AMSC P IMC D DSOR CN

US Marine Corps (MF5S)
Effective Date:: 1 Jan 2005; AMC 0 AMSC 0 AMSC 3 IMC E DSOR CN

US Navy (NSGS)
Effective Date:: 1 Sep 2004
Supplementary Receivers:: GG; AMC 0 AMSC 0 AMSC 3 IMC E DSOR CN

Latvia (VD01)
Effective Date:: 1 Mar 2007

Finland (WF01)
Effective Date:: 1 Oct 2009

Romania (WR01)
Effective Date:: 1 Jul 2011

Spain (YB01)
Effective Date:: 1 Jul 2007

Australia (ZA01)
Effective Date:: 1 Aug 2006

Canada (ZC01)
Effective Date:: 1 Sep 2004

New Zealand (ZE01)
Effective Date:: 1 Apr 2010

Germany (ZG01)
Effective Date:: 1 Jan 2015

United Kingdom (ZK01)
Effective Date:: 1 Jun 2011

Netherlands (ZN01)
Effective Date:: 1 Dec 2006

Denmark (ZS01)
Effective Date:: 1 Nov 2006

NATO Maintenance and Supply Agency (ZX01)
Effective Date:: 1 Feb 2011

Approved Sources 5825-01-516-8038

Part Number
Manufacturer
Status
822-1873-001: 13499 - Rockwell Collins, Inc. (Active); Primary Buy; RNCC 3 RNVC 2 DAC 3
AN/PSN-13: 80058 - Joint Electronics Type Designation (Active); Secondary Buy; RNCC 5 RNVC 2 DAC 3
10084781: A486G - Nimikkeistokeskus Ncb Finland (Active); NATO Reference; RNCC 6 RNVC 9 DAC 9

Datasheet 5825-01-516-8038

Characteristic
Specifications
FIIG: T198-B
End Item Identification [AGAV]: Navstar
Furnished Items [AFJH]: With Memory Battery And Lithium Prime Power Batteries
Functional Description [FTLD]: The Defense Advanced Global Positioning System (Gps) Receiver (Dagr) Is A Self-Contained Hand Held Receiver That Processes Gps Signals And Provides Position, Velocity And Time Information After Receiving Signals From Gps Satellites. It Will Receive Spread Spectrum Signals From An Antenna At Freq Of 1575.42 And 1227.60 Mhz And Demodulate These Signals To Provide Processed Data To The User
Joint Electronics Type Designation System Item Name [AKWA]: An/Psn-13
Receiver Frequency Rating [APWN]: 1227.6 Megahertz Nominal And 1575.4 Megahertz Nominal
Special Features [FEAT]: Hand Held Or Hard Mounted Config;Material Polycarbonate/Pbt Polyester Blend;Ht 6.37 In;Depth 1.6 In;Width 3.48 In;Weight 1 Lb

Management Data 5825-01-516-8038

Subscribe
View Prices

Effective Date: Organization; Unit of Issue; Unit Price; Qty Unit Pack
Oct 2020: Department of the Army (DA); EA; Subscribe; 1
Feb 2020: Department of the Air Force (DF); EA; Subscribe; 1
Nov 2016: US Marine Corps (DM); EA; Subscribe; 1
Apr 2015: Department of the Navy (DN); EA; Subscribe; 1
Dec 2013: Department of the Army (DA); EA; Subscribe; 1

MOE: USC; Code; Statement; Order of Use; Jump To Code; Qty Per Assy; UOM; Technical Document; Quantative Expression
Department of the Army (DA): A; F; When Exhausted Use 5825-01-590-9534
Department of the Air Force (DF): L; E; Replaced By 5825-01-590-9534
US Marine Corps (DM): M; F; When Exhausted Use 5825-01-590-9534
Department of the Navy (DN): N; H; Suitable Substitute 5825-01-526-4783
Department of the Navy (DN): N; F; When Exhausted Use 5825-01-590-9534

Army

Materiel Category and Inventory Manager:

G: Communications and Electronics Equipment, Electronics Materiel

Appropriation and Budget Activity:

P: Communications and Electronics Equipment (except Safeguard)

Management Inventory Segment:

1: Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.

Weapons System / End Item / Homogeneous Group:

T9: Other Electronics Equipment
Global Positioning Systems(GPS)

Accounting Requirements:

N: Nonexpendable item.An item of Army property coded with an ARC of N in the AMDF.Nonexpendable items require property book accountability after issue from the stock record account.Commercial and fabricated items similar to items coded N in the AMDF are considered nonexpendable items.

Air Force

Fund:

AF: HQ USAF regulated

Budget:

M: 57X3080 - Other Base Maintenance and Support Equipment

Aggregation Code:

NS: NAVSTAR GLOBAL POSITIONING SYSTEM EQUIPMENT ITEMS

Price Validation Code:

N: The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.

Expendability Recoverability Repairability:

S: Reparable. Condemn at Depot. AF Equipment Management System (AFEMS).

Navy

Cognizance:

7G

Issue, Repair, Requisition Restriction Code:

00: No Restriction

Special Material Content:

9: Non-Hazardous or Non-Sensitive Item

Marine Corps

Stores Account:

3: Appropriation Stores Account Principal Item

Combat Essentiality:

5: Critical Repair Part to a Combat Essential End Item

Echelon Management:

43

Operational Test:

: No Special Procedures

NATO Stock Numbers Related to 5825-01-516-8038

5825-17-120-7052 5825-17-123-0961 5825-37-519-4440 5825-17-125-0625 5826-14-569-7004 5825-17-124-2118 5825-99-926-4230 5826-14-472-2831 5825-14-551-3767 5826-14-568-0232 5825-21-900-9599 5825-22-623-9477 5825-22-624-1492 5825-25-161-0438 5825-14-571-8864 5825-16-006-8023 5826-14-542-8998 5825-22-621-2991

Freight Information 5825-01-516-8038

5825-01-516-8038 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062820. A Sub NMFC of Z. It has a NMFC Description of RADIO/TV TRANSMIT/RECEIVE SETS. 5825-01-516-8038 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 35080 which rates the freight between FCL and LCL. 5825-01-516-8038 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 72D for ocean manifesting and military sealift. 5825-01-516-8038 is not classified as a special type of cargo when transported by water. 5825-01-516-8038 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.

Packaging Data 5825-01-516-8038

Responsible Activity
Packaging Data Source: Primary Inventory Control Activity (PICA); --

Item Pack Level (Unpackaged)

Item Size
Item Weight
Characteristics
Weight/Dimensions Category
Fragility
Item Preservation: 6.3" H x 3.8" W x 2.0" L; --; --; Over 10lb; Less than 85G; No Requirement

Unit Pack Level (Packaged)

Quantity per Pack
Unit Size
Unit Weight
Unit Cube
Preservation Method
Cleaning/Drying: 1; 8.3" H x 8.3" W x 12.3" L; --; --; --; Any Suitable Process

Preservation Material
Wrapping Material
Cushioning/Dunnage
Cushioning Thickness
Container
Special Marking: No Requirement; --; --; --; PPP-B-1672, Type I, Vertical Star Cushioning in Reusable Box; Reusable container

Intermediate Pack Level

Quantity of Unit Packs
Container: --; No Requirement
