5820-01-162-3402
Radio Receiver-Transmitter
5820011623402 011623402 RT-1446/URC 10085-0000
A single component capable of performing the functions of a RECEIVER, RADIO; and TRANSMITTER, RADIO. View more Radio Receiver-Transmitter
May 2023
10
Marketplace 5820-01-162-3402
Request a Quotation from participating marketplace vendors
Related Documents 5820-01-162-3402 5+ Documents (More...)
United States (US) 4. 5820-01-162-3402 Marketplace Restrictions Approved Sources Datasheet Management
5820/us 5820-01-162-3402 Radio Receiver-Transmitter 5820011623402 10085-0000RT-1446/URC A single component
Every Day 5930-15-009-3154 RQST NE Restrictions https Receiver-Transmitter Subassembly 014423689 10085-0000
Radio Receiver-Transmitter 5820011623402 5930-15-009-3154 https//www.nsnlookup.com /fsg-58/fsc-5895
5996011971688011971688 www.nsnlookup.com /fsg-58/fsc-5820/us 5820-01-162 Receiver-Transmitter 5820011623402
us 5975-01-247-4052 https//www.nsnlookup.com /fsg-58/fsc-5820/us 5820-01-162-3402 Radio Receiver-Transmitter
www.nsnlookup.com /fsg-58/fsc-5895/us 5895-01-442-3689 Receiver-Transmitter Subassembly 014423689 10085-0000
3154 RQST NE Restrictions https Receiver-Transmitter Subassembly 014423689 Receiver-Transmitter 5820011623402
Radio Receiver-Transmitter 5820011623402 /us 5975-01-247-4052 Electrical Equipment Cabinet 5975012474052
197-1688 Amplifier Subassembly 5996011971688 011971688 www.nsnlookup.com /fsg-58/fsc-5820/us 5820-01-162-3402
Restrictions 5820-01-162-3402
IUID Required
5820-01-162-3402 is a Radio Receiver-Transmitter that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is a US Munitions List or Commerce Control List Item which must be destroyed to prevent restoration or repair. Only authorized parties may possess this item. This item may be hazardous as it is in a Federal Supply Class for potentially hazardous items. A MSDS should be available from the supplier for the end user to evaluate any hazards. This item does not contain a precious metal.
Import and Export 5820-01-162-3402
- Schedule B
- Subscribe to View Schedule B
- HTS Code
- Subscribe to View HTS Code
End Users 5820-01-162-3402
- US Army (A551)
- Effective Date:
- 1 Dec 1999
- Former MOE Rule:
- A542
- US Air Force (FGG4)
- Effective Date:
- 1 Dec 1999
- Former MOE Rule:
- FAA4
- US Navy (NSGS)
- Effective Date:
- 1 Dec 1999
- Former MOE Rule:
- NSAS
- Supplementary Receivers:
- GG
- Canada (ZC01)
- Effective Date:
- 1 Apr 1991
- Norway (ZT01)
- Effective Date:
- 1 Jan 1996
- Greece (ZU01)
- Effective Date:
- 1 Jul 2005
Approved Sources 5820-01-162-3402
- Part Number
- Manufacturer
- Status
- 10085-0000
- Manufacturer
- 14304 - L3harris Technologies, Inc. (Active)
- Primary Buy
- Primary Buy
- RT-1446/URC
- 80058 - Joint Electronics Type Designation (Active)
- Secondary Buy
- Secondary Buy
- 10085-0000
- 14872 - Communication Associates Inc (Obsolete)
- Canceled/Obsolete
- Canceled/Obsolete
Datasheet 5820-01-162-3402
- Characteristic
- Specifications
- FIIG
- Specifications
- T199-D
- Electrical Power Source Relationship [AKWC]
- Operating
- End Item Identification [AGAV]
- Pacer Bounce
- Ac Voltage Rating [ACYN]
- 110.0 Volts Nominal
- Dc Voltage Rating [ACYR]
- 28.0 Volts Nominal
- Frequency Rating [ACZB]
- 50.0 Hertz Minimum And 400.0 Hertz Minimum
- Output Frequency Rating [APTS]
- 1.600 Megahertz Minimum And 29.999 Megahertz Maximum
- Input Frequency Rating [APTQ]
- 1.600 Megahertz Minimum And 29.999 Megahertz Maximum
- Internal Battery Accommodation [ALSF]
- Not Included
- Joint Electronics Type Designation System Item Name [AKWA]
- Receiver-Transmitter,Radio
- Joint Electronics Type Designation System Item Type Number [AKWB]
- Rt-1446/Urc
- Power Output [AMMS]
- 100.000 Watts Nominal
- Receiver Channel Quantity [AMKQ]
- 99
- Receiver Emission Type [BCXP]
- A3j And A2j Continuous Wave,Audiblefreq Shift Keying;A3h Compatible Am;A9j Secure Voice
- Overall Height [ABKW]
- 8.750 Inches Nominal
- Overall Length [ABHP]
- 19.500 Inches Nominal
- Overall Width [ABMK]
- 16.750 Inches Nominal
- Phase [FAAZ]
- Single
- Transmitter Emission Type [BCXN]
- A3j And Continuous Wave,Audible Freq Shift Keying;Compatible Am(A3h);Secure Voice(A9j)
Management Data 5820-01-162-3402
- Effective Date
- Organization
- Unit of Issue
- Unit Price
- Qty Unit Pack
- Unit of Issue
- Oct 2022
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- Sep 2020
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Feb 2020
- Department of the Air Force (DF)
- EA
- Subscribe
- 1
- EA
- Apr 2018
- Department of the Army (DA)
- EA
- Subscribe
- 1
- EA
- Oct 2017
- Department of the Navy (DN)
- EA
- Subscribe
- 1
- EA
- MOE
- USC
- Code
- Statement
- Order of Use
- Jump To Code
- Qty Per Assy
- UOM
- Technical Document
- Quantative Expression
- Code
- Department of the Navy (DN)
- N
- R
- Refer To Net Price 3886.00
- NET PRICE 3886.00
- R
Army
- Materiel Category and Inventory Manager:
- G
- Communications and Electronics Equipment, Electronics Materiel
- Appropriation and Budget Activity:
- 2
- Stock Fund Secondary Items
- Management Inventory Segment:
- 1
- Repairable Items(Exclusive of Insurance and Provisioning Items)
This code will be used to identify serviceable or unserviceable items of a durable nature, which when unserviceable normally can be repaired economically by depots or lower echelons of maintenance.
- Weapons System / End Item / Homogeneous Group:
- RK
- Tactical and Strategic Communications
ESA/OBS
- Accounting Requirements:
- X
- Expendable item.An item of Army property coded with an ARC of X in the AMDF. Expendable items require no formal accountability after issue from a stock record account.Commercial and fabricated items similar to items coded X in the AMDF are considered expendable items.
Air Force
- Budget:
- L
- 57X3080 - Electronics and Telecommunications Equipment
- Aggregation Code:
- SJ
- COMMUNICATIONS
- Price Validation Code:
- N
- The current standard price in Catalog Management Data (CMD) has not analyzed or coded for LP/LM.
The price has not been analyzed or reviewed for accuracy.
ZOP or Standard price challenges are permissible but must be supported with adequate justification. However, if coded for Local Purchase (LP) or Fabrication/Manufacture as indicated with an (LM) Acquisition Advice Code of “L” or “F”, then it must be evaluated locally where purchased or fabricated.
- Expendability
Recoverability
Repairability: - S
- Reparable. Condemn at Depot. AF Equipment Management System (AFEMS).
Navy
- Cognizance:
- 7G
- Issue, Repair, Requisition Restriction Code:
- 00
- No Restriction
- Special Material Content:
- 9
- Non-Hazardous or Non-Sensitive Item
NATO Stock Numbers Related to 5820-01-162-3402
Freight Information 5820-01-162-3402
5820-01-162-3402 has freight characteristics.It has a National Motor Freight Classification (NMFC) of 062820. A Sub NMFC of A. It has a NMFC Description of RADIO/TV TRANSMIT/RECEIVE SETS SUB1. 5820-01-162-3402 is rated as class 100 when transported by Less-Than Truckload (LTL) freight. 5820-01-162-3402 is rated as class 200 when transported by Less-Than Carload (LCL) rail or ocean freight. It has a Uniform Freight Classification (UFC) number of 35080 which rates the freight between FCL and LCL. 5820-01-162-3402 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 738 for ocean manifesting and military sealift. 5820-01-162-3402 is classified as an Electrostatic Sensitive Device (ESD) when transported by water. 5820-01-162-3402 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5820-01-162-3402
- Responsible Activity
- Packaging Data Source
- Secondary Inventory Control Activity (SICA)
- Packaging Data does not meet current MIL-STD-2073-1E
- Storage Environment
- Heated General Purpose – Heated 40 F and above
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- --
- Over 10lb
- Less than 85G
- Special Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- --
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- No Requirement
- MIL-PRF-81705, Type III, Class 1, Transparent, Electrostatic Protective, Static Shielding, Barrier Material or MIL-DTL-117, Type II, Class H, Style 2 bag
- --
- --
- --
- Method 50
- MIL-PRF-81705, Type III, Class 1, Transparent, Electrostatic Protective, Static Shielding, Barrier Material or MIL-DTL-117, Type II, Class H, Style 2 bag
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
- No Requirement
