5365-01-224-6003
Machine Thread Plug
5365012246003 012246003 5942951 1604-91-AC-Y
An item with a cylindrical shaped body having external threads other than pipe or hose series. It is desinged to mate into a preformed threaded component for the purpose of plugging a hole during equipment operation. It may have a head and/or internal drive and may contain a bleeder hole. See also PLUG, PROTECTIVE, DUST AND MOISTURE SEAL and CAP-PLUG, PROTECTIVE, DUST AND MOISTURE SEAL. Excludes PLUG, TUBE FITTING, THREADED. View more Machine Thread Plug
August 2023
14
Marketplace 5365-01-224-6003
Request a Quotation from participating marketplace vendors
Related Documents 5365-01-224-6003 5+ Documents (More...)
Photo 1/2 NSN 5365-01-224-6003 (Identification) 2/2 - - 1.
RQST NE Updated Every Day 5365-01-224-6003 RQST Updated Every Day 5365-01-224-6003 RQST NE Related Documents
Restrictions 5365-01-224-6003
5365-01-224-6003 is a Machine Thread Plug that does not have a nuclear hardened feature or any other critical feature such as tolerance, fit restriction or application. Demilitarization of this item has been confirmed and is not currently subject to changes. This item is considered a low risk when released from the control of the Department of Defense. The item may still be subject to the requirements of the Export Administration Regulations (EAR) and the Code of Federal Regulations (CFR). This item is not suspected to be hazardous. This item does not contain a precious metal.
End Users 5365-01-224-6003
- US Navy (N9BG)
- Effective Date:
- 1 May 2005
- Former MOE Rule:
- N9GD
- Supplementary Collaborators:
- HD
- Poland (WP01)
- Effective Date:
- 1 Jul 2004
- Brazil (YA01)
- Effective Date:
- 1 Dec 2001
- Spain (YB01)
- Effective Date:
- 1 May 1997
- Australia (ZA01)
- Effective Date:
- 21 Jun 1992
- New Zealand (ZE01)
- Effective Date:
- 1 Jun 1995
- United Kingdom (ZK01)
- Effective Date:
- 1 Apr 1991
- Turkey (ZW01)
- Effective Date:
- 1 Nov 1998
Approved Sources 5365-01-224-6003
- Part Number
- Manufacturer
- Status
- 1604-91-AC-Y
- Manufacturer
- 34662 - Robroy Industries Inc Robroy (Obsolete)
- Original Design
- Original Design
- 5942951
- 53711 - Naval Sea Systems Command (Active)
- Vendor Drawing
- Vendor Drawing
Datasheet 5365-01-224-6003
- Characteristic
- Specifications
- FIIG
- Specifications
- A208A0
- Body Core Diameter [AJFC]
- 0.700 Inches Nominal
- Body Type [AJGE]
- Cored
- Connection Style [AHNC]
- Plain
- Core Depth [AJFD]
- 0.560 Inches Nominal
- Exterior Color [ADJS]
- Gray Overall
- Flange Diameter [ABKK]
- 1.150 Inches Minimum And 1.500 Inches Maximum
- Flange Thickness [ABKU]
- 0.060 Inches Nominal
- Head Diameter [AASL]
- 0.780 Inches Nominal
- Head Height [AASU]
- 0.330 Inches Nominal
- Head Type [AJGD]
- Solid
- Material [MATT]
- Plastic Acetal Overall Or Plastic Cellulose Acetate Overall
- Nominal Thread Size [CQJX]
- 1.000 Inches External
- Material Document And Classification [MDCL]
- L-P-392,Ty 1 Fed Spec 1St Material Response Overall Or L-P-504 Fed Spec 2Nd Material Response Overall
- Overall Length [ABHP]
- 0.800 Inches Nominal
- Special Features [FEAT]
- Color Fed Std 595,Number 26270
- Thread Class [AAJD]
- 2A External
- Thread Direction [AAJF]
- Right-Hand External
- Thread Length [AASA]
- 0.470 Inches Nominal External
- Thread Series Designator [THSD]
- Unf External
Weapon Systems (WSDC) 5365-01-224-6003
DLA Procurement Analysis 5365-01-224-6003
Management Data 5365-01-224-6003
Navy
- Cognizance:
- 9B
- Navy-owned stocks of DLA material
Naval Inventory Control Point, Mechanicsburg
Similar Supply Items to 5365-01-224-6003
Freight Information 5365-01-224-6003
5365-01-224-6003 has freight characteristics managed by the Southwestern Power Administration.It has a National Motor Freight Classification (NMFC) of 095190. A Sub NMFC of Z. It has a NMFC Description of HARDWARE, NOI. 5365-01-224-6003 is rated as a variable freight class when transported by Less-Than Truckload (LTL) freight. It has a Uniform Freight Classification (UFC) number of 49790 which rates the freight between FCL and LCL. 5365-01-224-6003 has a variance between NMFC and UFC when transported by rail and the description should be consulted. It has a Water Commodity Code (WCC) of 713 for ocean manifesting and military sealift. 5365-01-224-6003 is not classified as a special type of cargo when transported by water. 5365-01-224-6003 is not a consolidation and does not exceed 84" in any dimension. It should be compatible with a standard 72" Aircraft Cargo Door when transported by air.
Packaging Data 5365-01-224-6003
- Responsible Activity
- Packaging Data Source
- Primary Inventory Control Activity (PICA)
- --
Item Pack Level (Unpackaged)
- Item Size
- Item Weight
- Characteristics
- Weight/Dimensions Category
- Fragility
- Item Preservation
- Item Weight
- --
- --
- Electrical Instrument
- 2lb or less, one dimension 2" or less, other dimensions less than 24"
- Above 110G
- No Requirement
- --
Unit Pack Level (Packaged)
- Quantity per Pack
- Unit Size
- Unit Weight
- Unit Cube
- Preservation Method
- Cleaning/Drying
- Unit Size
- 1
- --
- --
- --
- Physical Protection
- Any Suitable Process
- --
- Preservation Material
- Wrapping Material
- Cushioning/Dunnage
- Cushioning Thickness
- Container
- Special Marking
- Wrapping Material
- --
- --
- --
- --
- Bags made of material conforming to MIL-P-130, MIL-DTL-17667, MIL-PRF-121, or any material authorized by MIL-DTL-117. Closure may be by staples, tape, adhesive or heat seal
- No special marking
- --
Intermediate Pack Level
- Quantity of Unit Packs
- Container
- --
Contracting Technical Data File (CTDF) 5365-01-224-6003 October 2021
Criticality and Quality
- Critical Item Code:
- Flight Safety:
- Life Support:
- Certified Samples:
- Serialization:
- First Article Test (FAT):
- Certificate of Quality Compliance:
- Production Lot Testing:
- Special Testing:
- Qualified Products List (QPL):
Commercial Properties
- Government Furnished Material:
- Government Furnished Tooling:
- Government Furnished Property:
- Price Evaluation Code:
- Diminshing Manufacturing Sources:
- Warranty:
- Commerical Off The Shelf (COTS):
- End Item Application:
- Auctioning Candidate:
- Source of Procurement:
- Contract Option:
Restrictions
- Boeing Rights Guard:
- Export Controlled:
- Controlled Technical Data Package (TDP):
- Restricted Technical Data Package (TDP):
- Contains Classified Material
- Weapons System Indicator Code (WSIC):
- Z
Packaging Requirements
- Packaging Determination Table:
- Packaging Review Code:
- Special Packaging Instruction Number (SPIN):
- Special Packaging Instruction Number Revision:
- Special Packaging Instruction Number Date:
- Pallet Reference Number Required:
